Manwal ta' Istruzzjoni għall-Heater Elettriku tan-Nar DUMOS ta' 26 pulzier Freestanding

1. Informazzjoni Importanti dwar is-Sigurtà

Please read all instructions carefully before using this electric fireplace heater. Failure to follow these instructions may result in fire, electric shock, or injury.

• Sigurtà Elettrika: Żgura li l-iżbokk tad-dawl jaqbel mal-voltage requirements of the heater. Do not overload circuits.
• Pjazzament: Position the heater on a firm, level surface. Maintain a minimum distance of 3 feet (0.9 meters) from combustible materials such as furniture, curtains, bedding, paper, clothes, and other objects.
• Ventilazzjoni: Do not block air vents. Ensure proper airflow around the heater.
• Protezzjoni mis-sħana żejda: This unit is equipped with an automatic overheat protection system. If the heater overheats, it will automatically shut off. Unplug the unit, allow it to cool for 15 minutes, then plug it back in. If it continues to shut off, contact customer support.
• Lock tat-tfal: The unit includes a child lock feature to prevent accidental operation. Refer to the operating instructions for activation and deactivation.
• Umdità: Tużax il-heater fl-imxarrab jew damp postijiet, bħal kmamar tal-banju jew żoni tal-ħasil tal-ħwejjeġ.
• Superviżjoni: Superviżjoni mill-qrib hija meħtieġa meta kwalunkwe heater jintuża minn jew qrib tfal jew individwi b'kapaċitajiet fiżiċi, sensorji jew mentali mnaqqsa.

2. Kontenut tal-Pakkett

Verify that all components are present and undamaged upon opening the package. If any items are missing or damaged, contact DUMOS customer support.

• DUMOS 26-inch Freestanding Electric Fireplace Heater Unit
• Kontroll mill-bogħod
• Manwal ta' Istruzzjoni
• Legs (4 pieces)
• Mounting Hardware for Legs

3. Setup u Assemblea

The DUMOS Electric Fireplace Heater requires minimal assembly. Follow these steps to prepare your unit for use:

1. Spakkjar: Neħħi l-komponenti kollha mill-imballaġġ bir-reqqa. Żomm l-imballaġġ għal ħażna jew trasport fil-futur.
2. Waħħal Saqajn: Invert the main fireplace unit. Align each of the four legs with the designated mounting points on the bottom of the unit. Secure each leg using the provided mounting hardware (screws). Ensure all screws are tightened firmly to provide stability.
3. Pożizzjonament: Place the assembled fireplace heater on a stable, level surface. Ensure it is at least 3 feet (0.9 meters) away from any walls, furniture, curtains, or other combustible materials. Do not place it directly under a wall-mounted television or other heat-sensitive electronics.
4. Konnessjoni tal-Enerġija: Plug the power cord into a grounded 120V AC outlet. Ensure the outlet is not shared with other high-wattagTagħmir elettroniku.

Figura 3.1: Quddiem view of the DUMOS Electric Fireplace Heater after assembly.

4. Istruzzjonijiet Operattivi

The DUMOS Electric Fireplace Heater can be operated using the control panel on the unit or the included remote control.

4.1 Pannell tal-Kontroll u Kontroll mill-Bogħod Fuqview

Figure 4.1: Remote control and integrated control panel on the fireplace unit.

The remote control provides convenient access to all functions. Ensure the remote has working batteries (not included, typically AAA).

• Buttuna tal-Qawwa: Ixgħel jew jitfi l-unità.
• Buttuna tal-Fjamma: Cycles through flame brightness levels.
• Buttuna tat-Tajmer: Activates and adjusts the 1-12 hour timer.
• Buttuni 'l fuq /' l isfel: Aġġusta s-settings tat-temperatura jew it-tul tat-tajmer.
• Buttuna tal-Heater: Toggles heating function ON/OFF or adjusts heat levels.

4.2 Qawwa Inizjali

1. Ensure the unit is properly plugged into a grounded outlet.
2. Locate the master power switch, usually at the bottom or rear of the unit, and switch it to the 'ON' position.
3. Press the 'Power' button on the control panel or remote control to turn on the fireplace. The flame effect will activate.

4.3 Adjusting Flame Effect

The fireplace features a 3D flame effect with adjustable brightness levels.

1. Press the 'Flame' button on the remote or control panel.
2. Each press will cycle through different brightness settings (e.g., Off, Level 1, Level 2, Level 3, Level 4). Select your desired brightness.

Figure 4.2: Visual representation of the 5 adjustable flame brightness levels.

4.4 Setting the Heat Output

The heater provides efficient warmth with adjustable temperature settings.

1. Press the 'Heater' button on the remote or control panel to activate the heating function.
2. Use the 'Up' and 'Down' buttons to adjust the desired temperature. The temperature range is typically 59°F to 95°F.
3. The heater operates at 750W or 1500W, automatically adjusting based on the selected temperature and room conditions.

Figure 4.3: The heater provides adjustable warmth within a specified temperature range.

4.5 L-Użu tat-Tajmer ta' 12 Siegħa

The integrated timer allows for automatic shut-off, promoting energy efficiency.

1. Press the 'Timer' button on the remote or control panel.
2. Use the 'Up' and 'Down' buttons to set the desired operating duration, from 1 to 12 hours.
3. L-unità titfi awtomatikament wara li jkun għadda l-ħin stabbilit.

Figure 4.4: The 12-hour timer function helps manage energy consumption.

5. Manutenzjoni

Regular maintenance ensures optimal performance and longevity of your electric fireplace heater.

• Tindif: Dejjem aqla’ l-plagg tal-ħiter qabel ma tnaddaf. Uża drapp artab u damp drapp biex timsaħ l-uċuħ ta’ barra. Tużax prodotti tat-tindif jew solventi li joborxu.
• Tneħħija tat-Trab: Periodically vacuum or wipe dust from the air intake and exhaust vents to maintain efficient airflow.
• Ħażna: If storing the heater for an extended period, unplug it and store it in a cool, dry place, preferably in its original packaging.
• L-ebda Partijiet li jistgħu jservu mill-utent: Do not attempt to open or repair the unit yourself. Refer all servicing to qualified service personnel.

6 Issolvi l-problemi

If you encounter issues with your DUMOS Electric Fireplace Heater, consult the following table before contacting customer support.

7. Speċifikazzjonijiet

8. Garanzija u Appoġġ

DUMOS products are manufactured to high-quality standards. For warranty information or technical assistance, please contact DUMOS customer support through the retailer where the product was purchased or visit the official DUMOS website. Please have your model number (FP203R-T3-P) and proof of purchase available when contacting support.
