1. Introduzzjoni
Thank you for choosing the Rollei Mini Digital Camera 12064. This compact and versatile camera is designed for ease of use, allowing you to capture moments in Full HD 1080p video and 2MP photos. Its vintage design, combined with modern features like an integrated LED light, color filters, audio recording, and webcam functionality, makes it a unique device for various applications. Please read this manual thoroughly to ensure proper operation and care of your camera.
2. Kontenut tal-Pakkett
Before using your camera, please verify that all items are present in the package:
- Rollei Mini Digital Camera
- USB-C Cable
- USB-C OTG Adapter (for Android devices)
- Ċinga ta 'l-għonq
- Ċinga tal-Idejn
- Keychain
- Manwal għall-Utent
Image: Contents of the Rollei Mini Digital Camera package.
3. Prodott Aktarview
The Rollei Mini Digital Camera is designed for portability and ease of use. It features a compact body, a 0.96-inch color display, and intuitive controls.
Immaġni: Quddiem view of the Rollei Mini Digital Camera.
Image: Dimensions and weight of the camera, illustrating its compact size.
Immaġni: Eżamples of how the camera can be carried due to its small size.
4. Setup
4.1. Daħħal Karta MicroSD
The camera requires a MicroSD card (not included) to store photos and videos. Locate the MicroSD card slot on the side of the camera. Gently insert the card with the gold contacts facing down until it clicks into place. To remove, press the card inward until it springs out.
4.2. Iċċarġjar tal-batterija
The camera has a built-in 200mAh battery. To charge, connect the camera to a USB power source (e.g., computer, wall adapter) using the provided USB-C cable. The charging indicator light will show the charging status. A full charge typically takes approximately 1-2 hours.
5. It-tħaddim tal-Kamera
5.1. Power On/Off
To power on the camera, press and hold the power button (usually located on the top or side) for a few seconds until the screen illuminates. To power off, press and hold the power button again until the screen turns off.
5.2. Teħid tar-Ritratti
With the camera powered on, press the shutter button (typically on the top) to capture a 2MP photo. The 0.96-inch screen will display a preview of your shot.
5.3. Reġistrar Vidjows
To record Full HD 1080p video, switch to video mode (if applicable, refer to on-screen menu) and press the shutter button to start recording. Press it again to stop. The camera records at 30 frames per second.
Immaġni: Eżamples of 2MP photo and 1080P video capture.
5.4. Using the Integrated LED Light (Flash)
The camera features an integrated LED light to illuminate subjects in low-light conditions. Activate the LED light through the camera's menu settings or a dedicated button (refer to the on-screen interface for specific controls).
Image: Camera in use with the LED light (flash) activated.
5.5. L-Applikazzjoni ta' Filtri tal-Kulur
Enhance your photos with six built-in color filters: Original, Green, Pink, Blue, Black/White, and Sepia. Access these filters through the camera's menu to apply them before capturing an image.
Image: Demonstration of various color filters available.
5.6. Reġistrazzjoni tal-Awdjo
The camera supports audio recording for voice notes. Navigate to the audio recording function in the menu and press the appropriate button to start and stop recording.
Image: Camera being used for audio recording.
5.7. Webcam Funzjonalità
Connect your Rollei Mini Digital Camera to a computer via the USB-C cable to use it as a webcam for video conferencing. Select the webcam option when prompted on your computer.
Image: Camera functioning as a webcam for a video call.
5.8. Viewing Ritratti/Vidjows
Use the 0.96-inch color screen to review your captured photos and videos. Navigate through your media using the camera's control buttons.
Image: Sample photos captured with the Rollei Mini Digital Camera.
6. Trasferiment tad-Data
You can transfer your photos and videos to other devices using two methods:
6.1. Via USB-C Cable
Connect the camera to your PC or Mac using the provided USB-C cable. The camera will appear as a removable storage device, allowing you to drag and drop files.
6.2. Via OTG Adapter (Android Only)
For direct transfer to Android smartphones, use the included USB-C OTG adapter. Connect the camera to your phone via the adapter to access your media files without a computer or Wi-Fi.
Image: Two methods for transferring data from the camera.
7. Manutenzjoni
7.1. Tindif
Uża drapp artab u niexef biex tnaddaf il-korp tal-kamera. Għal-lenti u l-iskrin, uża drapp speċjalizzat għat-tindif tal-lentijiet. Evita li tuża prodotti tat-tindif likwidi jew materjali li joborxu.
7.2. Ħażna
Store the camera in a cool, dry place away from direct sunlight and extreme temperatures. If storing for an extended period, ensure the battery is partially charged (around 50%) and remove the MicroSD card.
8 Issolvi l-problemi
If you encounter issues with your Rollei Mini Digital Camera, please refer to the following common solutions:
- Il-kamera ma tixgħel: Kun żgur li l-batterija hija ċċarġjata. Qabbad il-kamera ma' sors ta' enerġija u erġa' pprova.
- Ma nistax nieħu ritratti/nirrekordja vidjows: Check if a MicroSD card is inserted correctly and has sufficient free space.
- Kwalità fqira tal-immaġni/vidjow: Ensure the lens is clean. Check lighting conditions and use the integrated LED light if necessary.
- Computer not recognizing camera: Try a different USB-C port or cable. Ensure the camera is powered on when connected.
- L-iskrin huwa vojt jew iffriżat: Try restarting the camera by holding the power button. If unresponsive, allow the battery to drain completely and then recharge.
Għal aktar assistenza, jekk jogħġbok ikkuntattja l-appoġġ għall-klijenti.
9. Speċifikazzjonijiet
| Karatteristika | Dettall |
|---|---|
| Numru tal-Mudell | 12064 |
| Riżoluzzjoni tal-vidjo | Full HD 1080p (30 FPS) |
| Riżoluzzjoni tar-Ritratti | 2 MP |
| Wiri | LCD bil-kulur ta' 0.96 pulzieri |
| Teknoloġija tas-Sensor tal-Immaġni | SP1405 |
| Stabbilizzazzjoni tal-Immaġni | Diġitali |
| Appoġġjati File Formati | JPEG, MP4 |
| Tip ta' Kontroll ta' Espożizzjoni | Awtomatiku |
| Max WebCam Image Riżoluzzjoni | 8 MP |
| Dimensjonijiet | 5.4 x 3.1 x 2 ċm |
| Piż | 18 g |
| Batterija | 200mAh (integrated) |
| Pajjiż ta' Oriġini | Iċ-Ċina |
10. Garanzija u Appoġġ
Your Rollei Mini Digital Camera 12064 comes with a Garanzija ta' skambju ta' 24 xhur. For any questions, technical assistance, or warranty claims, our expert support team is available to assist you.
Informazzjoni ta' Kuntatt:
- Phone: +49 40 270 750 277 (Monday to Friday, 10:00 to 16:00)
- For additional support, please visit the official Rollei website or your retailer's support page.
