1. Matulview
The UPERFECT 15.6" Portable Monitor is designed to enhance productivity and entertainment on the go. Featuring a slim, lightweight profile and vibrant 125% sRGB Full HD display, it offers versatile connectivity and an adjustable stand for optimal viewing angles. This manual provides comprehensive instructions for setting up, operating, maintaining, and troubleshooting your monitor.
Figure 1: UPERFECT Portable Monitor 15.6"
2. Kontenut tal-Pakkett
Jekk jogħġbok ivverifika li l-oġġetti kollha huma preżenti fil-pakkett:
- 15.6" 1080P Monitor
- Kejbil Mini HDMI għal HDMI
- Type C to Type C Cable
- USB to Type C Cable
- PD30W Power Adapter
- Manwal għall-Utent
- 15.6" Monitor Case
Figura 2: Kontenut tal-Pakkett Inkluż
3. Setup
3.1 Konfigurazzjoni Fiżika
The monitor features a built-in 0–180° adjustable/foldable stand for optimal viewing angles. It supports both horizontal and vertical placement. For alternative mounting, the monitor is VESA-standard compatible (75mm) allowing for wall-mount or arm-mount installations.
Figure 3: Adjustable Stand for Flexible Viewing
Figure 4: VESA Mount Compatibility and Display Modes
3.2 Konnessjonijiet
The UPERFECT Portable Monitor offers versatile connectivity options for various devices:
- USB-C (Full-featured): Connect a single USB-C cable from your compatible laptop, smartphone, or tablet to the monitor for both video signal and power.
- Mini HDMI: Use the Mini HDMI to HDMI cable to connect to devices like gaming consoles (PS4/PS5/Xbox/Steam Deck) or PCs. In this setup, power must be supplied separately via a USB-C cable connected to the PD30W Power Adapter or another power source.
Figura 5: Portijiet u Kontrolli tal-Monitor
Plug & Play: No drivers are required for most compatible devices. Simply connect the appropriate cables, and the monitor should automatically detect the signal.
Figure 6: Plug & Play Connectivity with Gaming Console
3.3 Dimostrazzjoni bil-Vidjo
Video 1: UPERFECT Portable Monitor 15.6 Inch - This video demonstrates the unboxing and basic setup of the UPERFECT 15.6 inch portable monitor, showcasing its slim design and connectivity options.
4. Istruzzjonijiet Operattivi
4.1 Power On/Off and OSD Menu
The monitor features control buttons on its side (refer to Figure 5). Use these buttons to power the monitor on or off and to navigate the On-Screen Display (OSD) menu for various settings.
4.2 Modi tal-Wiri
Depending on your connected device and operating system, you can configure the monitor to operate in different display modes:
- Modalità Estendi: Expands your desktop across both screens, providing more workspace.
- Modalità Duplikata: Mirrors the content of your primary screen onto the portable monitor.
- Modalità Vertikali: Allows the monitor to be used in a portrait orientation, ideal for reading documents or coding.
4.3 Aġġustamenti tad-Displej
Access the OSD menu using the side buttons to adjust settings such as:
- Luminożità u Kuntrast: Adjust for optimal visibility in different lighting conditions.
- Settings tal-Kulur: Irfina t-temperatura tal-kulur, il-lewn, u s-saturazzjoni.
- Volum: Control the audio output from the built-in speakers or connected headphones.
- Proporzjon tal-aspett: Select between 16:9 or other available ratios.
Figure 7: Display Features: 125% sRGB, 350 Nits, 1200:1 Contrast Ratio
5. Speċifikazzjonijiet
| Karatteristika | Speċifikazzjoni |
|---|---|
| Daqs tal-Iskrin | 15.6 pulzieri |
| Riżoluzzjoni tal-Iskrin | 1920 x 1080 Pixels (Full HD) |
| Proporzjon ta' l-aspett | 16:9 |
| Gamut tal-Kulur | 125% sRGB |
| Luminożità | 350 nits |
| Proporzjon ta' Kuntrast | 1200:1 |
| Wiċċ tal-Iskrin | Matte |
| Numru tal-Mudell tal-Oġġett | M180K01 |
| Piż tal-oġġett | 2.2 liri |
| Dimensjonijiet tal-Prodott | 0.23 x 13.9 x 8.2 pulzieri |
| Voltage | 5 Volts |
| Manifattur | UPERFETT |
6. Manutenzjoni
To ensure the longevity and optimal performance of your UPERFECT Portable Monitor, follow these maintenance guidelines:
- Tindif tal-Iskrin: Uża drapp artab u mingħajr suf biex timsaħ l-iskrin bil-mod. Għal tbajja' persistenti, nixxef ftit.ampNaddaf id-drapp bl-ilma jew b'soluzzjoni tat-tindif speċifika għall-iskrin. Evita li tuża kimiċi ħarxa, alkoħol, jew materjali li joborxu.
- Tindif tal-ġisem: Wipe the monitor's body with a soft, dry cloth.
- Ħażna: When not in use or during transport, always place the monitor in its protective sleeve to prevent scratches and impacts.
- Evita Kundizzjonijiet Estremi: Do not expose the monitor to extreme temperatures, humidity, or direct sunlight for prolonged periods.
Figure 8: Protective Sleeve for Safe Transport and Storage
7 Issolvi l-problemi
If you encounter any issues with your monitor, refer to the following common troubleshooting steps:
- Ebda Sinjal:
- Ensure all cables (USB-C or HDMI) are securely connected to both the monitor and your device.
- Verify that your device's display output is enabled and configured correctly (e.g., extended or duplicated display).
- If using HDMI, ensure the monitor is receiving power via a separate USB-C connection.
- Ebda Qawwa:
- Check if the PD30W Power Adapter is properly connected to a power outlet and the monitor's USB-C port.
- If powering via a single USB-C cable from your device, ensure your device's USB-C port supports power delivery.
- Display Issues (e.g., incorrect resolution, mirroring):
- Adjust display settings on your connected device (Windows/macOS) to select the desired resolution and display mode (extend, duplicate).
- Ensure the monitor's refresh rate is compatible with your device's output.
- Kwistjonijiet tal-Awdjo:
- Check the volume settings on both the monitor (via OSD menu) and your connected device.
- If using headphones, ensure they are properly plugged into the 3.5mm audio jack.
- Teptip jew żanżin:
- Ensure all cables are securely connected and try using different cables if available.
- Verify that the power supply is stable and sufficient.
If the issue persists after attempting these steps, please contact UPERFECT customer service for further assistance.
8. Garanzija u Appoġġ
For warranty information, please refer to the warranty card included in your product package. UPERFECT is committed to customer satisfaction. If you have any questions or require support, please contact UPERFECT customer service. Contact details can typically be found on the official UPERFECT webis-sit jew fuq il-karta tal-garanzija.
