1. Introduzzjoni
The COHEALI Outdoor Solar Wall Light is an energy-efficient lighting solution designed for outdoor use. It features a COB LED array, a PIR motion sensor, and is powered by solar energy. This light automatically charges during the day and provides illumination at night, enhancing security and visibility around your home or garden.
2. Kontenut tal-Pakkett
- 1 x COHEALI Outdoor Solar Wall Light
Image: The COHEALI Outdoor Solar Wall Light packaged in its brown cardboard box.
3. Speċifikazzjonijiet
| Numru tal-Mudell | UX1B1ST20I058Q01FNOPZ |
| Sors tad-Dawl | COB LED (950lm) |
| Temperatura tal-Kulur | 5000-6500K |
| Angolu tad-Dawl | 270 grad |
| Medda tas-Sensor tal-Moviment | Sa 33 pied (10 metru) |
| Klassi ta' Protezzjoni | IP65 (Protett kontra t-trab u l-ġettijiet tal-ilma) |
| Batterija | 2 x 2200 mAh rechargeable batteries |
| Materjal | Acrylonitrile Butadiene Styrene (ABS) |
| Kulur | Iswed |
| Dimensjonijiet tal-Prodott | 11.81" T x 4.33" W x 1.97" G (30 ċm x 11 ċm x 5 ċm) |
| Piż tal-oġġett | 14.1 uqija (400 gramma) |
| It-Tistennija tal-Ħajja | 50,000 sigħat |
Image: Product dimensions of the solar wall light, showing length as 11.81 inches and width as 4.17 inches, and height as 2 inches.
Image: Key features of the light, highlighting a 270-degree lighting angle, 120-degree motion sensor angle with 33ft range, COB LED 950lm, and 2x2200 mAh battery.
4. Informazzjoni dwar is-Sigurtà
- Ensure the light is installed in a location that receives direct sunlight for at least 6-8 hours daily to ensure optimal charging and performance.
- Avoid installing the light near other strong light sources (e.g., streetlights) at night, as this may interfere with the motion sensor or cause the light to not activate.
- Do not attempt to disassemble, modify, or repair the product yourself. Contact qualified personnel for service.
- Keep the product away from open flames and extreme temperatures.
- This product is designed for outdoor use and is IP65 rated for weather resistance. However, avoid submerging it in water.
5. Setup u Installazzjoni
- Agħżel Post: Agħżel post fil-beraħ li jirċievi ample direct sunlight throughout the day. The solar panel must be exposed to sunlight for efficient charging. Ensure the chosen area is free from obstructions that might block sunlight or the motion sensor's field of view.
- Immonta d-Dawl: Use appropriate screws and wall anchors (not included) to securely mount the solar wall light to a wall or fence. The light features pre-drilled mounting holes for easy installation.
- Ħlas Inizjali: After installation, allow the light to charge in direct sunlight for at least one full day (6-8 hours) before its first use to ensure the battery is fully charged.
Image: The solar wall light installed on an outdoor wall, demonstrating its typical mounting position.
6. Operating Instructions (Lighting Modes)
The COHEALI Outdoor Solar Wall Light features a mode switch located on the underside of the unit, allowing you to select from three distinct lighting modes. Press the switch repeatedly to cycle through the modes.
- Mode 1: Medium Light Mode
The light will turn on at medium brightness automatically at dusk and stay on for approximately 4-6 hours, then turn off. This mode does not use the motion sensor. - Modalità 2: Modalità tas-Sensor tad-Dawl Baxx
The light will stay on at a dim brightness at night. When motion is detected, it will switch to super bright mode for about 15-30 seconds, then return to dim light. - Modalità 3: Modalità tas-Sensor
The light remains off at night. When motion is detected, it will turn on at super bright mode for about 15-30 seconds, then turn off completely.
Image: Visual representation of the three lighting modes: Medium Light Mode, Dim Light Sensor Mode, and Sensor Mode, showing how the light behaves with and without motion detection.
7. Manutenzjoni
- Naddaf il-Panel Solari: Imsaħ il-pannell solari regolarment b'ċarruta ratba u damp drapp biex tneħħi t-trab, il-ħmieġ, jew il-fdalijiet. Pannell nadif jiżgura l-akbar assorbiment tad-dawl tax-xemx u l-effiċjenza tal-iċċarġjar.
- Iċċekkja l-Immuntar: Periodically inspect the mounting screws and ensure the light remains securely attached to its surface.
- Lonġevità tal-batterija: The internal rechargeable batteries are designed for long-term use. If the light's performance significantly degrades over time, it may indicate the need for battery replacement by a qualified technician.
8 Issolvi l-problemi
| Problema | Kawża Possibbli | Soluzzjoni |
|---|---|---|
| Id-dawl ma jixgħelx bil-lejl. | Ċarġ solari insuffiċjenti. Mode switch is OFF or in an incorrect mode. Sensor interference from other light sources. | Ensure the solar panel receives 6-8 hours of direct sunlight daily. Check the mode switch and set it to the desired operating mode (Mode 1, 2, or 3). Irriloka d-dawl 'il bogħod minn sorsi oħra ta' dawl qawwi. |
| Id-dawl ma jindunax bil-moviment. | Is-senser tal-moviment huwa ostakolat. Light is in Mode 1 (no sensor). Motion is outside the detection range. | Neħħi kwalunkwe ostaklu mil-lenti tas-sensorju. Switch to Mode 2 or Mode 3. Ensure motion occurs within 33 ft of the sensor. |
| It-tul tad-dawl huwa iqsar milli mistenni. | Ċarġ solari insuffiċjenti. Id-degradazzjoni tal-batterija maż-żmien. | Verify the solar panel is clean and receives adequate direct sunlight. Consider replacing the internal batteries if they are old (contact support). |
9. Garanzija u Appoġġ
COHEALI products are manufactured with quality and reliability in mind. For any questions, technical support, or warranty inquiries regarding your COHEALI Outdoor Solar Wall Light, please contact COHEALI customer service through your retailer or the official COHEALI website. Please have your model number (UX1B1ST20I058Q01FNOPZ) ready when contacting support.
Għal aktar informazzjoni, żur il- COHEALI Store.
