Johgee 3 Żoni Water Timer Brass Inlet - Manwal tal-Istruzzjonijiet (Mudell YZD03-T)

1. Introduzzjoni

Thank you for choosing the Johgee 3 Zones Water Timer. This device is designed to automate your garden watering, providing flexible and efficient irrigation for lawns, plants, and other areas. It features three independently programmable outlets, rain delay functionality, and manual watering options. Please read this manual thoroughly before installation and operation to ensure proper use and longevity of the product.

2. Informazzjoni dwar is-Sigurtà

• This product is intended for outdoor use with cold water only. Do not use with hot water or in freezing conditions.
• Do not immerse the timer in water. The unit is IPX5 waterproof, meaning it is protected against low-pressure water jets, but not submersion.
• Uża biss 2 batteriji alkalini AA ta' 1.5V. Tħallatx batteriji qodma ma' batteriji ġodda, jew tipi differenti ta' batteriji.
• Remove batteries if the timer will not be used for an extended period to prevent leakage.
• Keep the device out of reach of children and pets to prevent accidental activation or damage.
• Ensure all connections are tight to prevent leaks. Use the provided sealing washer and thread seal tape.

3. Kontenut tal-Pakkett

Jekk jogħġbok ivverifika li l-oġġetti kollha huma preżenti fil-pakkett tiegħek:

• Johgee 3 Zones Water Timer Unit
• Manwal għall-Utent
• Sealing Washers (pre-installed or separate)
• Tejp tas-Siġill tal-Ħajt

4. Prodott Aktarview

Familiarize yourself with the components of your Johgee Water Timer:

Immaġni: Quddiem view of the Johgee 3 Zones Water Timer, showing the LCD display, control buttons, and rotary dial.

• Display LCD: Shows current time, program settings, and battery status.
• Dial li jdur: Used to select different programming modes (OFF, AUTO, Set Clock, Start Time, How Long, How Often).
• Zone Button: Selects which of the three output zones to program or operate manually.
• Buttuna OK: Jikkonferma selezzjonijiet u settings.
• +/- Delay Buttons: Adjusts values (time, duration, frequency) and activates rain delay.
• Buttuna Manwali: Initiates temporary manual watering.
• Brass Inlet: Connects to your garden faucet (3/4" external thread). Features a reinforced design and integrated filter.
• Water Outlets (x3): Connect to garden hoses for individual watering zones.

5. Setup

5.1 Installazzjoni tal-batterija

1. Sib il-kompartiment tal-batterija fuq wara tat-tajmer.
2. Iftaħ l-għatu tal-kompartiment.
3. Insert two (2) new 1.5V AA alkaline batteries, ensuring correct polarity (+/-).
4. Close the battery compartment cover securely to maintain the waterproof seal.

The timer features a low battery warning and an automatic shut-off valve to prevent water waste when battery levels are critically low.

5.2 Connecting the Water Timer

1. Ensure your garden faucet is turned off.
2. Inspect the brass inlet for the pre-installed sealing washer. If missing, insert one.
3. Apply thread seal tape (provided) to the threads of your garden faucet for an extra secure, leak-proof connection.
4. Screw the Johgee Water Timer onto your standard 3/4" garden faucet. Hand-tighten firmly. Do not overtighten.
5. Connect your garden hoses to the three independent water outlets at the bottom of the timer. Ensure these connections are also tight.

Image: The Johgee Water Timer connected to a garden faucet, with three hoses attached to its outlets, ready for use.

Immaġni: Dettaljata view of the reinforced brass inlet, highlighting its robust construction and integrated metal filter for preventing debris from entering the timer.

6. Istruzzjonijiet Operattivi

6.1 Setting the Current Time (Clock)

1. Dawwar l-arloġġ li jdur għal SSET L-ARLOĠĠ.
2. The hour digit will flash. Use the + or - buttuni biex taġġusta s-siegħa. Agħfas OK biex tikkonferma.
3. The minute digit will flash. Use the + or - buttuni biex taġġusta l-minuta. Agħfas OK biex tikkonferma.
4. L-arloġġ issa huwa ssettjat.

6.2 Programming Automatic Watering

The timer allows for independent programming of each of its three zones.

Image: The Johgee Water Timer connected to a faucet, with three hoses extending to different garden areas labeled Zone 1, Zone 2, and Zone 3, illustrating its multi-zone capability.

1. Dawwar l-arloġġ li jdur għal AUTO.
2. Agħfas il- ŻONA button to select the desired watering zone (1, 2, or 3) you wish to program.
3. Dawwar l-arloġġ li jdur għal ĦIN BIDU. Użu + or - to set the desired start time for watering. Press OK biex tikkonferma.
4. Dawwar l-arloġġ li jdur għal KEMM DWAR. Użu + or - to set the watering duration (1 to 360 minutes). Press OK biex tikkonferma.
5. Dawwar l-arloġġ li jdur għal KEMM TA 'Spiss. Użu + or - to set the watering frequency (e.g., every 1, 3, 6, 12 hours, or every 1 to 30 days). Press OK biex tikkonferma.
6. Repeat steps 2-5 for each zone you wish to program.
7. Once programming is complete, turn the rotary dial back to AUTO għal tħaddim awtomatiku.

Image: The LCD screen displaying options for setting start time, watering duration, and frequency, indicating the timer's programmable capabilities.

Image: An infographic detailing the customizable settings for automatic watering schedules, including setting the clock, start time, watering duration (1-360 minutes), and frequency (1 hour to 30 days).

6.3 Tisqija manwali

Manual watering allows you to water immediately without interrupting your preset automatic schedule.

1. Ensure the rotary dial is set to AUTO or OFF.
2. Agħfas il- MANWAL buttuna.
3. Uża l- + or - buttons to set the desired manual watering duration (1 to 360 minutes).
4. Agħfas OK biex tibda tisqija manwali.
5. Biex twaqqaf it-tisqija manwali, agħfas MANWAL again or turn the dial to OFF.

Image: A person using a hose to manually water a garden, demonstrating the manual watering feature of the Johgee Water Timer. The timer's display shows a manual watering countdown.

6.4 Rain Delay Function

The rain delay function allows you to temporarily suspend your watering schedule for a specified period, conserving water during rainy weather.

1. Ensure the rotary dial is set to AUTO.
2. Agħfas u żomm il- DEWMIEN button (part of the + buttuna).
3. Uża l- + or - buttons to select the desired delay duration (1 to 15 days).
4. Agħfas OK to activate the rain delay. The display will show the remaining delay time.
5. To cancel the rain delay, press and hold the DEWMIEN button again until the delay is cleared.

Image: The Johgee Water Timer shown during rainfall, with its display indicating an active rain delay. This feature helps conserve water by pausing scheduled watering during wet conditions.

6.5 Child Lock Mode

The child lock feature prevents accidental changes to your watering schedule by children or pets.

1. Biex tattiva: Agħfas u żomm il-buttuna OK button for 3 seconds until a lock icon appears on the display.
2. Biex tiddiżattiva: Agħfas u żomm il-buttuna OK button for 3 seconds until the lock icon disappears.

Image: A child's hand interacting with the Johgee Water Timer, illustrating the child lock function designed to prevent unintended changes to settings.

7. Manutenzjoni

7.1 Sostituzzjoni tal-batterija

When the low battery indicator flashes on the display, replace the batteries promptly to ensure continuous operation and prevent the timer from shutting off unexpectedly. Follow the battery installation steps in Section 5.1.

7.2 Tindif tal-Filtru

The brass inlet contains an integrated metal filter to prevent debris from entering the timer. Periodically check and clean this filter to maintain optimal water flow. To clean:

1. Turn off the water supply and disconnect the timer from the faucet.
2. Carefully remove the filter screen from the brass inlet.
3. Rinse the filter under running water to remove any accumulated debris.
4. Reinsert the clean filter and reconnect the timer to the faucet.

7.3 Ħażna tax-Xitwa

Before the first frost, disconnect the water timer from the faucet and hoses. Remove the batteries. Store the timer indoors in a dry, frost-free location to prevent damage from freezing water.

8 Issolvi l-problemi

9. Speċifikazzjonijiet

• Numru tal-Mudell: YZD03-T
• Temperatura tax-Xogħol: 4.5°C - 45°C (40.1°F - 113°F)
• Pressjoni tax-Xogħol: 0.05Mpa - 0.8Mpa (7.25 psi - 116 psi)
• Klassifikazzjoni li ma jgħaddix ilma minnha: IPX5
• Provvista tal-Enerġija: 2 x 1.5V AA Alkaline Batteries (not included)
• Konnessjoni tal-vit tal-pajp: 3/4" External Thread
• Dimensjonijiet tal-Prodott: 7 x 15 x 12 ċm
• Piż tal-oġġett: 600 g
• Materjal: Metall, plastik

Image: A technical diagram illustrating the dimensions of the Johgee Water Timer, including its height (133mm) and width (155mm).

10. Garanzija u Appoġġ

The Johgee 3 Zones Water Timer is backed by a manufacturer's warranty. For specific warranty details, including duration and coverage, please refer to the product packaging or contact the seller directly. If you encounter any issues or require technical assistance, please reach out to Johgee customer support through the retailer's platform or the contact information provided on the product packaging.

For online support and additional resources, you may visit the Johgee Store on Amazon.
