Manwal tal-Utent tat-Torċa LED UV Alonefire SV85 365nm

Introduzzjoni

This manual provides detailed instructions for the safe and effective use of your Alonefire SV85 365nm UV LED Flashlight. Please read this manual thoroughly before operating the device and retain it for future reference. The SV85 is a versatile ultraviolet flashlight designed for various detection and curing applications, featuring a high-quality 365nm UV LED, adjustable zoom, and convenient USB-C recharging.

Image: The Alonefire SV85 UV LED flashlight shown alongside its USB-C charging cable. This image illustrates the overall design and included accessories.

Kontenut tal-Pakkett

• Alonefire SV85 365nm UV LED Flashlight
• Rechargeable Lithium-ion Battery (pre-installed or separate)
• Cable tal-Iċċarġjar tal-USB-C
• Manwal għall-Utent (dan id-dokument)

Informazzjoni dwar is-Sigurtà

Twissija: Ultraviolet (UV) light can be harmful to eyes and skin. Always observe the following safety precautions:

• Tħarisx direttament fis-sors tad-dawl UV.
• Avoid prolonged exposure to UV light on skin.
• Żomm fejn ma jintlaħaqx mit-tfal.
• Use in a well-ventilated area if performing resin curing.

Setup

1. Installazzjoni tal-batterija: The SV85 flashlight typically comes with a rechargeable Lithium-ion battery pre-installed. If not, unscrew the tail cap, insert the battery with the positive (+) end facing the head of the flashlight, and re-screw the tail cap securely.
2. Ħlas Inizjali: Before first use, fully charge the flashlight. Connect the supplied USB-C cable to the flashlight's charging port and to a standard USB power source (e.g., computer, wall adapter).

Image: The Alonefire SV85 flashlight connected via its USB-C port to a laptop for charging. The image also shows charging indicators: red for charging, green for fully charged.

Istruzzjonijiet Operattivi

1. Power On/Off: Press the power button located on the side of the flashlight to turn the UV light on or off.
2. Adjusting Focus (Zoom): The SV85 features a telescopic zoom function. Gently push or pull the head of the flashlight to adjust the beam from a focused spotlight to a wider floodlight. This allows for versatile use across different detection or curing needs.

Image: Illustration of the Alonefire SV85 flashlight's telescopic zoom feature, showing how the beam can be adjusted from a narrow spotlight to a broad floodlight by extending or retracting the head.

3. Iċċarġjar: When the battery is low, connect the USB-C cable to the flashlight and a power source. The charging indicator light will show red during charging and turn green when fully charged. Charging typically takes 4-6 hours.

Applikazzjonijiet

The Alonefire SV85 365nm UV LED Flashlight is suitable for a wide range of applications due to its specific wavelength, which is effective for revealing fluorescent substances.

• Sejbien tat-tbajja tal-annimali domestiċi: Identify hidden pet urine stains on carpets, rugs, and upholstery that are invisible under normal light.
• Ringworm Detection: Assist in identifying ringworm on pets, as affected areas may fluoresce under 365nm UV light.
• Awtentikazzjoni tal-Munita u tad-Dokumenti: Verify the authenticity of banknotes, passports, and other official documents that incorporate UV security features.
• Sejbien ta' Scorpion: Scorpions fluoresce brightly under UV light, making them easier to spot in dark environments.
• Spezzjoni tal-Minerali u l-Ġebel Prezzjuż: Observe fluorescence in certain minerals and gemstones for identification or quality assessment.
• Tqaddid bir-Reżina: Aċċelera l-proċess ta' tqaddid ta' reżini u kolli sensittivi għall-UV.
• Sejbien ta' tnixxija: When used with UV-sensitive dyes, it can help detect leaks in HVAC systems, automotive fluids, and plumbing.

Image: A collage demonstrating various applications of the UV flashlight, showing how it reveals hidden elements like scorpions, carpet stains, pet stains, and highlights plant pollination under ultraviolet light.

Image: The UV flashlight illuminating pet urine stains on a carpet, making them visible. A dog is visible in the background.

Manutenzjoni

• Tindif: Imsaħ il-qafas tal-flashlight b'ċarruta ratba u damp cloth. Do not use abrasive cleaners or solvents. Keep the lens clean for optimal performance.
• Kura tal-batterija: To prolong battery life, avoid fully discharging the battery frequently. Recharge the battery regularly, even if not in use, to maintain its capacity.
• Ħażna: Store the flashlight in a cool, dry place away from direct sunlight and extreme temperatures. If storing for extended periods, charge the battery to about 50% and recharge every few months.

Issolvi l-problemi

Speċifikazzjonijiet

Image: A comparison illustrating the difference between 365nm and 395nm UV light. It shows that 365nm UV light provides clearer fluorescence and better identification for certain materials compared to 395nm.

Garanzija u Appoġġ

For warranty information or technical support, please refer to the product packaging or contact the retailer where the product was purchased. You may also visit the official ALONEFIRE websit għal aktar għajnuna.

Manifattur: Nar Waħdu

ASIN: B0DMF94PSW
