1. Introduzzjoni
Thank you for choosing the TOMLOV P30 Digital Microscope. This handheld microscope is designed to provide an engaging and educational experience for users of all ages, especially children, allowing for detailed observation of the micro-world. With its dual magnification levels, HD camera, and portable design, the P30 is an excellent tool for scientific exploration at home, outdoors, or in educational settings.
This manual provides comprehensive instructions for setting up, operating, and maintaining your TOMLOV P30 Digital Microscope to ensure optimal performance and longevity.
2. Prodott Aktarview
2.1 Karatteristiċi ewlenin
- Livelli ta' Tkabbir Doppju: Offers 1-100X standard magnification for general observation and 500-1000X high magnification for detailed examination of slides. Includes 4X digital zoom.
- HD Camera & Video: Equipped with a 16MP camera for capturing high-resolution photos and 1080P video recording. A 16GB SD card is included for storage.
- Skrin LCD ta' 2 pulzieri: Provides a clear, visible display for live viewing and instant replay of captured discoveries, facilitating easy sharing.
- Portable & Lightweight Design: Weighing just 6 oz, it is ideal for outdoor exploration and easy handling by children.
- Ħajja twila tal-batterija: Built-in 800mAh rechargeable battery offers up to 3 hours of continuous use.
- Included P10 Magnifying Glass: Comes with an additional pocket magnifying glass for broader exploration.
2.2 Komponenti u Aċċessorji
The TOMLOV P30 package includes the following items:
- TOMLOV P30 Digital Microscope
- TOMLOV P10 Pocket Magnifying Glass
- Cable tal-Iċċarġjar tal-USB
- Karta Micro SD ta' 16GB (installata minn qabel jew inkluża separatament)
- Manwal għall-Utent
2.3 Dijagramma tal-Prodott
Figure 2.3.1: The TOMLOV P30 Digital Microscope (pink, right) and the TOMLOV P10 Pocket Magnifying Glass (grey, left). The P30 features a screen at the top, a power button, and a ribbed grip, with a clear base for viewing. The P10 is a handheld magnifying glass with a screen and control buttons.
Figura 2.3.2: Close-up view of the TOMLOV P10 Pocket Magnifying Glass, held in a hand, showing its screen displaying a magnified view of plant material and its control buttons.
3. Setup
3.1 Iċċarġjar tal-Apparat
Before first use, fully charge the TOMLOV P30 microscope. Connect the included USB charging cable to the microscope's charging port and the other end to a standard USB power adapter (not included) or a computer USB port. The charging indicator light will show the charging status and turn off when fully charged. A full charge provides up to 3 hours of use.
Figure 3.1.1: Two children are shown outdoors, one holding the pink TOMLOV P30 microscope. An icon indicates "3H Battery working time," emphasizing the device's long battery life for outdoor exploration.
3.2 Daħħal il-Mikro SD Card
The TOMLOV P30 comes with a 16GB Micro SD card for storing photos and videos. Locate the Micro SD card slot on the side of the microscope. Gently insert the card with the gold contacts facing down until it clicks into place. To remove, push the card in slightly until it springs out.
4. Istruzzjonijiet Operattivi
4.1 Tixgħel/Jitfi
Press and hold the Power button (usually marked with a circle and vertical line) for a few seconds to turn the microscope on. The LCD screen will light up. To turn off, press and hold the Power button again until the screen shuts down.
4.2 Aġġustament tal-Ingrandiment
The P30 offers two primary magnification ranges: 1-100X for standard observation and 500-1000X for high-detail viewing. The microscope automatically adjusts focus within these ranges. For digital zoom, use the designated zoom buttons (if available) or navigate through the menu options.
Figure 4.2.1: A close-up of the TOMLOV P30 microscope's screen, displaying a highly magnified image of a bee, illustrating its capability to "Unlock Tiny Details at 1000X".
4.3 Qbid ta' Ritratti u Vidjows
While observing, press the Photo button to capture a still image. Press the Video button to start recording; press it again to stop. All captured media will be saved to the inserted Micro SD card.
Figure 4.3.1: A graphic illustrating the TOMLOV P30's capabilities: 1080P Video recording, 16MP Photo capture, and Playback functionality, with examples of magnified insects.
4.4 Viewing and Sharing Discoveries
Tista 'terġa'view your captured photos and videos directly on the 2-inch LCD screen. Navigate through your media using the directional buttons. The screen allows for easy sharing of observations with others.
Figure 4.4.1: A group of children gathered around the TOMLOV P30 microscope, looking at its 2-inch screen, highlighting its "Shareable Screen" feature for collaborative viewing.
Biex tittrasferixxi files to a computer, connect the microscope to your PC using the USB cable. The microscope will appear as a removable disk drive, allowing you to copy files. Alternatively, you can remove the Micro SD card and insert it into a card reader connected to your computer.
Figure 4.4.2: A young girl and an adult are shown at a desk, with the TOMLOV P30 microscope connected via USB to a laptop, demonstrating the ease of editing and sharing discoveries on a PC.
5. Manutenzjoni
5.1 Tindif
- Use a soft, dry cloth to clean the body of the microscope.
- For the lens and screen, use a lens cleaning cloth or a microfiber cloth specifically designed for optics. Do not use abrasive cleaners or solvents.
- Kun żgur li l-apparat ikun mitfi qabel ma tnaddaf.
5.2 Ħażna
Store the TOMLOV P30 in a cool, dry place away from direct sunlight and extreme temperatures. Keep it in its original packaging or a protective case when not in use to prevent dust accumulation and damage.
6 Issolvi l-problemi
| Problema | Kawża Possibbli | Soluzzjoni |
|---|---|---|
| L-apparat ma jixgħelx. | Batterija baxxa. | Iċċarġja l-apparat bis-sħiħ billi tuża l-kejbil USB ipprovdut. |
| L-iskrin huwa vojt jew iffriżat. | Żball fis-softwer. | Press and hold the Power button for 10 seconds to force a restart. |
| Ma nistax insalva r-ritratti/vidjows. | SD card full or not inserted correctly. | Check if the SD card is properly inserted. Delete old files or replace the SD card if full. |
| L-immaġni hija mċajpra. | Incorrect distance from object or dirty lens. | Adjust the distance between the microscope lens and the object. Clean the lens if necessary. |
7. Speċifikazzjonijiet
- Mudell: P30
- Ditta: TOMLOV
- Tkabbir: 1-100X (Standard), 500-1000X (High)
- Żum diġitali: 4X
- Riżoluzzjoni tal-kamera: 16MP
- Riżoluzzjoni tal-vidjo: 1080P
- Daqs tal-iskrin: LCD ta '2 pulzieri
- Tip ta' Sors tad-Dawl: LED
- Sors tal-Enerġija: Imħaddem bil-batterija (batterija rikarikabbli integrata ta' 800mAh)
- Ħajja tal-batterija: Sa 3 sigħat
- Materjal: Plastik
- Kulur: Roża
- Piż: Madwar 6 oz
- Ħażna: Jappoġġja kard Micro SD (16GB inkluża)
- ASIN: B0DM94LXT8
- Data L-Ewwel Disponibbli: 7 ta’ Novembru, 2024
8. Garanzija u Appoġġ
TOMLOV products are designed for reliability and performance. For specific warranty information, please refer to the warranty card included with your product or visit the official TOMLOV website. If you encounter any issues or have questions regarding your TOMLOV P30 Digital Microscope, please contact TOMLOV customer support through their official channels or the retailer from whom you purchased the product.
Għal aktar għajnuna, tista' żżur il- TOMLOV Store on Amazon.
