1. Introduzzjoni
Thank you for choosing the WIOONI WLAN Indoor Motion Detector. This device is designed to enhance your home security and smart automation experience by detecting motion and sending real-time notifications to your smartphone. It integrates seamlessly with Smart Life and Tuya Smart applications, allowing for intelligent linkages with other smart devices.
This manual provides detailed instructions on how to set up, operate, and maintain your motion detector. Please read it thoroughly before use to ensure proper functionality and safety.
Image 1.1: WIOONI WLAN Indoor Motion Detector and its corresponding mobile application interface.
2. Informazzjoni dwar is-Sigurtà
- Dan l-apparat huwa għal użu fuq ġewwa biss. Do not expose it to water, moisture, or extreme temperatures.
- Żomm l-apparat 'il bogħod mix-xemx diretta, minn sorsi ta' sħana, u minn kampi elettromanjetiċi qawwija.
- Uża biss it-tip ta' batterija speċifikat (AAA) u kun żgur li l-polarità tkun korretta waqt l-installazzjoni.
- Tippruvax iżarma jew isewwi l-apparat lilek innifsek. Ikkuntattja l-appoġġ tal-klijent għall-assistenza.
- Żomm fejn ma jintlaħaqx mit-tfal u l-annimali domestiċi.
3. Kontenut tal-Pakkett
Il-pakkett jinkludi l-oġġetti li ġejjin:
- 2 x WIOONI WLAN Indoor Motion Sensor
- 4 x AAA Batteries (2 per sensor)
- Mounting Accessories (e.g., double-sided adhesive tapes, hanging ropes)
- Manwal għall-Utent
4. Prodott Aktarview
The WIOONI motion detector features a compact design with an infrared PIR sensor for detecting human movement. It includes a small LED indicator for status and a button for pairing. The device is powered by AAA batteries for wireless operation.
Image 4.1: The WIOONI motion sensor discreetly installed in a home environment, demonstrating its role as a security device.
5. Setup
5.1. Installazzjoni tal-batterija
- Gently open the back cover of the motion detector.
- Daħħal iż-żewġ batteriji AAA, waqt li tiżgura l-polarità korretta (+/-).
- Remove the battery insulation strip (if present) to activate the device.
- Agħlaq il-qoxra ta' wara sew.
Image 5.1: Step-by-step guide for initial setup, including battery activation and app pairing.
5.2. Tniżżil u Installazzjoni tal-App
The WIOONI motion detector is compatible with the Smart Life and Tuya Smart applications. Choose one to manage your device.
- Scan the QR code provided in Image 5.1 or search for "Smart Life" or "Tuya Smart" in your mobile app store (App Store for iOS, Google Play Store for Android).
- Niżżel u installa l-applikazzjoni.
- Irreġistra kont ġdid jew idħol jekk diġà għandek wieħed.
You can also download the Smart Life app directly from: https://smartapp.tuya.com/smartlife
5.3. Tqabbil/Konnessjoni tal-Apparat
- Ensure your smartphone is connected to a 2.4GHz Wi-Fi network. (5GHz networks are not supported).
- Iftaħ l-app Smart Life jew Tuya Smart.
- Ippermetti Bluetooth u Wi-Fi fuq it-telefon tiegħek.
- In the app, tap "Add Device" or the "+" icon in the top right corner.
- The app may automatically discover the device. If not, select "Security & Sensor" > "Motion Sensor (Wi-Fi)" or similar.
- Follow the on-screen instructions to connect the device. This usually involves pressing the pairing button on the sensor until the LED indicator flashes, then confirming in the app.
- Ladarba żżidu b'suċċess, tista' tbiddel isem l-apparat u tassenjah ma' kamra speċifika.
6. Joperaw
6.1. Basic Motion Detection
The WIOONI motion detector uses Passive Infrared (PIR) technology to detect changes in infrared radiation caused by moving objects, such as people. When motion is detected within its range, the device will trigger an alert.
Image 6.1: Illustration of PIR motion detection and instant notification to your smartphone.
6.2. App Features
- Monitoraġġ f'ħin reali: View the current status of the motion detector (e.g., "No motion detected," "Motion detected") directly from the app, no matter where you are.
- Notifiki Instant: Receive push notifications on your smartphone immediately when motion is detected, keeping you informed of any activity.
- Reġistru tal-Attività: Review a history of detected movements with timestamps.
- Awtomazzjoni Intelliġenti: Create intelligent scenarios (routines) to link the motion detector with other Smart Life/Tuya Smart devices. For example, you can set up a rule to turn on lights automatically when motion is detected in a room.
6.3. Sharing Functions
You can share control of the motion detector with family members or trusted individuals through the Smart Life/Tuya Smart app. This allows multiple users to receive notifications and manage the device.
Image 6.2: Sharing device control with family members for collaborative home security management.
7. Installazzjoni / Immuntar
The WIOONI motion detector offers flexible mounting options:
- Mdendlin: The top of the detector has a hanging hole. You can use the provided rope to hang it in a suitable location.
- Immuntar adeżiv: Use the included double-sided adhesive tapes to securely attach the sensor to any flat surface, such as a wall or furniture.
- Pjazzament: Simply place the sensor on a shelf, table, or any elevated surface within the desired detection area.
Consider the detection angle and distance when choosing a mounting location to ensure optimal coverage.
Immaġni 7.1: Eż.amples of suitable installation locations for the motion sensor.
8 Issolvi l-problemi
| Problema | Kawża Possibbli | Soluzzjoni |
|---|---|---|
| Apparat mhux qed jikkonnettja mal-Wi-Fi | Incorrect Wi-Fi band (5GHz not supported); Weak Wi-Fi signal; Incorrect password; Device not in pairing mode. | Ensure your router is set to 2.4GHz. Move the device closer to the router. Re-enter Wi-Fi password carefully. Press the pairing button on the sensor to enter pairing mode (LED flashing). |
| No motion detected / False alarms | Incorrect placement; Obstructions; Environmental factors (e.g., drafts, direct sunlight, pets). | Ensure the sensor has a clear line of sight to the detection area. Avoid placing near vents, windows, or areas with rapid temperature changes. Adjust placement to avoid pets. |
| Notifiki mhux riċevuti | App notification settings disabled; Phone's notification settings disabled; App not running in background. | Check notification settings within the Smart Life/Tuya Smart app. Verify your phone's system notification settings for the app. Ensure the app is allowed to run in the background. |
| Ħajja qasira tal-batterija | Frequent detections; Low-quality batteries. | Reduce the number of unnecessary detections by optimizing placement. Use high-quality alkaline AAA batteries. |
9. Speċifikazzjonijiet
Image 9.1: Detailed specifications as listed on the product packaging.
| Karatteristika | Dettall |
|---|---|
| Numru tal-Mudell | HWTCQ0627 |
| Dimensjonijiet | 8.99 x 6.68 x 2.59 ċm |
| Piż | 68 gramma |
| Sors tal-Enerġija | 4 x Batteriji AAA (inklużi) |
| Teknoloġija ta 'Sejbien | PIR infrared |
| Angolu ta 'skoperta | 130° |
| Distanza ta' Sejbien | 2~12 meters (Note: Detection angle and distance values may vary by location.) |
| Konnettività bla fili | Wi-Fi 802.11b/g/n (2.4GHz only) |
| Kompatibilità | Smart Life App, Tuya Smart App |
| Tip ta 'Immuntar | Wall Mount / Hanging / Placement |
10. Garanzija u Appoġġ
WIOONI products are designed for reliability and performance. For any technical support, troubleshooting, or warranty inquiries, please contact your retailer or the WIOONI customer service team.
Jekk jogħġbok żomm il-prova tax-xiri tiegħek għal skopijiet ta' garanzija.
Manufacturer: WIOONI
Address: Huizhouhbosiyunkeijiyouxiangongsi, Room 03, 21st Floor, Section A, Block 2, GanghuiXintiandic Huizhou, Huicheng, Guangdong, 516001, CN
