1. Introduzzjoni
The EazeID M950 is a versatile label maker designed for home, office, and school use. It offers two primary printing modes: direct input via its integrated QWERTY keyboard and wireless control through the 'Print Master' mobile application via Bluetooth. Featuring a rechargeable battery and a backlit LCD screen, the M950 provides convenience and clarity for all your labeling needs. This manual provides detailed instructions for setting up, operating, and maintaining your device.
2. Kontenut tal-Pakkett
Jekk jogħġbok ivverifika li l-oġġetti kollha elenkati hawn taħt huma inklużi fil-pakkett tiegħek:
- 1 x EazeID M950 Label Maker
- 1 x 3M21 Black on White Label tape (12mm*4M)
- 1 x Kejbil tad-Data tat-Tip Ċ
- 1 x Kaxxa tal-ippakkjar
- 1 x Manwal tal-Utent (dan id-dokument)
Figure 2.1: EazeID M950 Label Maker package contents.
3. Prodott Aktarview
The EazeID M950 Label Maker features a compact design with an integrated QWERTY keyboard and a backlit LCD screen for ease of use. It utilizes thermal printing technology, eliminating the need for ink or toner.
Figura 3.1: Quddiem view of the EazeID M950 Label Maker and accessories.
Figure 3.2: Key features and components of the EazeID M950 Label Maker.
4. Setup
4.1 Iċċarġjar tal-Apparat
The M950 Label Maker is equipped with a built-in 1200mAh rechargeable lithium battery. Before first use, or when the battery is low, charge the device using the provided Type-C USB cable.
- Connect the Type-C end of the cable to the charging port on the side of the label maker.
- Connect the USB-A end of the cable to a 5V-2A charging adapter (not included) or a compatible USB port.
- The device will indicate charging status on the LCD screen. A full charge typically takes 1-2 hours.
Figure 4.1: Charging the EazeID M950 Label Maker.
4.2 Installazzjoni tat-Tejp tat-Tikketti
To install or replace the label tape cassette:
- Ensure the label maker is powered off.
- Locate the tape compartment cover on the top of the device. Gently open the cover.
- Insert the label tape cassette into the compartment, ensuring it clicks into place. The tape should feed smoothly out of the slot.
- Close the tape compartment cover securely.
Figura 4.2: Intern view of the M950 label maker showing tape cassette placement.
5. Istruzzjonijiet Operattivi
5.1 Tixgħel/Jitfi
- Biex tixgħel: Agħfas u żomm il-buttuna Qawwa button (usually marked with a power symbol) until the LCD screen illuminates.
- Biex titfi: Agħfas u żomm il-buttuna Qawwa Agħfas il-buttuna mill-ġdid sakemm l-iskrin jintefa.
5.2 Direct Printing via QWERTY Keyboard
The M950 features an ergonomic QWERTY keyboard for direct label creation.
- Qawwa Mixgħul: Ixgħel il-magna tat-tikketti.
- Input Text: Use the QWERTY keyboard to type your desired label text. The text will appear on the backlit LCD screen.
- Formatting Options: Use the function keys (e.g., Fn, Simbolu, Tappijiet, Aċċent) to access various fonts, sizes, symbols, and other formatting options.
- Stampa: Agħfas il- Stampa button to generate the label.
- Aqta': Use the built-in cutter to cleanly separate the printed label from the tape roll.
Figure 5.1: Using the QWERTY keyboard for direct label printing.
5.3 Bluetooth App Printing (Print Master App)
For advanced features and customization, connect your M950 to the 'Print Master' app via Bluetooth.
- Niżżel l-App: Download the 'Print Master' app from your device's app store (available on Android and iOS).
- Power On & Bluetooth: Turn on the label maker and ensure Bluetooth is enabled on both the label maker and your smartphone.
- Qabbad: Open the 'Print Master' app. The app will search for nearby EazeID label makers. Select 'EazeID M950' from the list to connect.
- Design Label: Use the app's interface to create your label. The app offers a vast library of customizable templates, over 1000 patterns, 100+ frames, 100+ fonts, barcodes, and QR codes.
- Stampa: Once your label is designed, tap the 'Print' icon in the app.
- Aqta': Use the built-in cutter on the label maker to separate the printed label.
Figure 5.2: The EazeID M950 supports both keyboard and Bluetooth app printing modes.
Figure 5.3: Connecting to the 'Print Master' app via Bluetooth.
6. Manutenzjoni
6.1 Tindif tal-Apparat
To ensure optimal performance and longevity of your label maker:
- Itfi l-apparat qabel it-tindif.
- Use a soft, dry cloth to wipe the exterior of the label maker.
- For the print head, gently wipe with a cotton swab lightly dampImxarrab bl-alkoħol isopropiliku. Ħallih jinxef kompletament qabel l-użu.
- Tużax tindif jew solventi li joborxu.
6.2 Kura tal-Batterija
Biex timmassimizza l-ħajja tal-batterija:
- Evita li tiċċarġja l-batterija kompletament ta' spiss.
- Charge the device regularly, even if not in constant use.
- Aħżen l-apparat f'post frisk u niexef meta ma jkunx qed jintuża għal perjodi twal.
7 Issolvi l-problemi
If you encounter issues with your EazeID M950 Label Maker, refer to the following common problems and solutions:
| Problema | Kawża Possibbli | Soluzzjoni |
|---|---|---|
| L-apparat ma jixgħelx | Batterija baxxa; Ħsara fl-apparat | Charge the device for at least 30 minutes. If still unresponsive, contact support. |
| No print or faint print | Tape installed incorrectly; Print head dirty; Low battery | Reinstall tape cassette. Clean the print head. Charge the device. |
| Il-konnessjoni Bluetooth tfalli | Bluetooth off; App not updated; Device too far | Ensure Bluetooth is enabled on both devices. Update 'Print Master' app. Move label maker closer to smartphone. Restart both devices. |
| Labels are difficult to peel | Specific label tape characteristic | Ensure you are using genuine EazeID label tape. Try bending the label backing slightly to separate. |
8. Speċifikazzjonijiet
Technical specifications for the EazeID M950 Label Maker:
- Isem tal-Mudell: EazeID M950 Label Maker
- Teknoloġija tal-Istampar: Termali
- Riżoluzzjoni tal-Istampar: 203 DPI
- Konnettività: Bluetooth, USB Tip Ċ
- Daqs Massimu tal-Midja: 12mm (0.47 pulzieri)
- Batterija: 1200mAh Lithium Ion (rechargeable, included)
- Metodu ta' Kontroll: App (Print Master), QWERTY Keyboard
- Karatteristiċi Speċjali: Backlit LCD Screen, Built-in Cutter, Portable
- Dimensjonijiet tal-Prodott: Madwar 1 x 1 x 1 pulzieri
- Piż tal-oġġett: 1.06 liri
- Komponenti Inklużi: Label maker, tape, USB-C cable, user manual
Figure 8.1: EazeID M950 Label Maker dimensions and key features.
9. Garanzija u Appoġġ
The EazeID M950 Label Maker comes with a limited warranty. For specific warranty terms and conditions, please refer to the warranty card included in your product packaging or visit the official EazeID websit.
For technical support, troubleshooting assistance, or inquiries about replacement parts and accessories, please contact EazeID customer service through the contact information provided on the official webis-sit jew il-pjattaforma tax-xiri tiegħek.
