Manwal tal-Utent tad-Dawl tal-Proġettazzjoni Solari ta' Barra CLY 30W 2600LM

Introduzzjoni

This manual provides comprehensive instructions for the installation, operation, and maintenance of your CLY 30W 2600LM Solar Outdoor Projector Light. This product is designed for outdoor use, featuring a high-capacity battery, multiple lighting modes, and robust weather resistance. Please read this manual thoroughly before use to ensure proper function and longevity of the product.

Karatteristiċi tal-Prodott

• 5000mAh Battery & Efficient Solar Panel: Features a split design with a 5-meter cable, allowing optimal placement of the solar panel for maximum sunlight absorption. The 25% conversion rate solar panel charges the 5000mAh battery in 8-10 hours, providing 8-20 hours of illumination.
• Temperatura tal-Kulur u Luminożità Aġġustabbli: Offers three color temperatures (Cool White 6500K, Natural White 4000K, Warm White 2700K) with stepless adjustment. Three brightness levels are available: High (8 hours), Medium (12 hours), and Low (20 hours).
• Two Dynamic Lighting Modes: Includes SMOOTH mode (gradual transition from 2700K to 6500K) and FLASH mode (current color temperature strobe), both with adjustable speed, ideal for creating various atmospheres.
• Funzjonalità tat-Tajmer: Features a forced lighting mode that keeps the light on for 2 hours regardless of day or night. Additionally, 2H/4H/6H timer options allow automatic shutdown at night.
• IP66 Waterproof & Durable: Certified IP66 waterproof, resistant to water, heat, and cold. Constructed with high-quality materials and designed for efficient heat dissipation, ensuring a lifespan of up to 50,000 hours.
• Smart Indicators & 360° Remote Control: Equipped with power, brightness, charging, and battery level indicators. The 360° remote control has a 12-meter range for easy mode changes.
• Installazzjoni versatili: Can be wall-mounted with provided screws or inserted into the ground using a stake, suitable for garages, porches, gardens, pathways, and more.

Kontenut tal-Pakkett

Jekk jogħġbok iċċekkja l-pakkett għall-oġġetti li ġejjin:

• CLY 30W Solar Projector Light unit
• Solar Panel with 5-meter cable
• Kontroll mill-bogħod
• Mounting Hardware (screws, wall plugs, ground stake)
• Manwal għall-Utent (dan id-dokument)

Setup u Installazzjoni

The CLY Solar Projector Light offers two primary installation methods: wall mounting or ground insertion.

1. Tqegħid ta' Pannelli Solari

The solar panel should be installed in a location that receives direct sunlight for 8-10 hours daily to ensure optimal charging. The 5-meter cable allows for flexible placement away from the light unit itself.

Deskrizzjoni tal-Immaġni: This image illustrates the split design of the solar projector, showing the solar panel and the light unit with their respective dimensions. A 5-meter cable connects the two components, highlighting the charging process from the sun to the 5000mAh battery. It also shows the ON/OFF button and brightness adjustment on the light unit.

Deskrizzjoni tal-Immaġni: This diagram visually explains the solar light's operation: the solar panel charges the 5000mAh battery during the day (8-10 hours), and the light automatically illuminates at night (8-20 hours). It also indicates a memory function, where the light resumes the last set mode upon activation.

2. Immuntar mal-Ħajt

1. Choose a suitable wall location for the light unit, ideally 2-4 meters (6.56-13.12 feet) high for optimal beam angle (60°).
2. Mark the drilling points using the light unit's bracket as a template.
3. Drill toqob u daħħal plugs tal-ħajt.
4. Secure the light unit to the wall using the provided screws.
5. Connect the solar panel cable to the light unit.

3. Ground Insertion

1. Attach the ground stake to the light unit.
2. Select a soft ground area in your garden or pathway.
3. Insert the stake firmly into the ground.
4. Adjust the angle of the light unit to illuminate the desired area.
5. Connect the solar panel cable to the light unit.

Deskrizzjoni tal-Immaġni: This image demonstrates the two versatile installation options for the CLY solar light: mounting it on a wall, suitable for areas like garages or porches, and inserting it into the ground, ideal for illuminating gardens, trees, or pathways.

Istruzzjonijiet Operattivi

The CLY Solar Projector Light can be operated using the integrated buttons on the light unit or the included 360° remote control.

Funzjonijiet ta 'Kontroll mill-bogħod

Deskrizzjoni tal-Immaġni: This image displays the remote control for the CLY solar light, with various buttons clearly labeled. Functions include ON/OFF, brightness adjustment (High, Medium, Low), color temperature selection (2700K, 4000K, 6500K), dynamic modes (SMOOTH, FLASH), and timer settings (2H, 4H, 6H).

• ON/OFF: Jixgħel jew jitfi d-dawl.
• Aġġustament tal-luminożità: Select between High, Medium, or Low brightness levels.
  • High Brightness: Approximately 8 hours of illumination.
  • Medium Brightness: Approximately 12 hours of illumination.
  • Low Brightness: Approximately 20 hours of illumination.
• Għażla tat-Temperatura tal-Kulur: Choose between Warm White (2700K), Natural White (4000K), or Cool White (6500K). Use the +/- buttons for stepless color temperature adjustment.
• Modi dinamiċi:
  • LIXX: Gradually cycles through color temperatures from 2700K to 6500K.
  • FLASH: The current selected color temperature will strobe.
  Use the +/- buttons to adjust the speed of dynamic modes.
• Funzjoni Timer:
  • Forced Lighting (2H button): Activates the light for 2 hours, regardless of ambient light conditions (day or night).
  • Night Timer (2H/4H/6H buttons): Sets the light to automatically turn off after 2, 4, or 6 hours of operation at night.

Deskrizzjoni tal-Immaġni: This visual guide showcases the three available color temperatures: Warm White (2700K), Natural White (4000K), and Cool White (6500K), demonstrating their appearance in an outdoor setting. Below, it illustrates the three brightness levels (High, Medium, Low) and their corresponding illumination durations (8H, 12H, 20H).

Deskrizzjoni tal-Immaġni: This image illustrates the two dynamic lighting modes: SMOOTH, which shows a gradual cyclic gradient of color temperatures from 2700K to 6500K, and FLASH, which depicts a strobing effect of the current color temperature. Both modes offer dynamic speed adjustment.

Deskrizzjoni tal-Immaġni: This image demonstrates the timer functions, showing the light automatically turning off after 2, 4, or 6 hours at night. It also illustrates the forced lighting mode, where the light can be activated for 2 hours during the day or night.

Dwal Indikaturi

Deskrizzjoni tal-Immaġni: This diagram highlights the smart indicator lights on the CLY solar projector. It details the working indicator (green for normal power), brightness indicator (green for low, yellow for medium, red for high), charging indicator (red when charging), and battery indicator (30%-70%-100% levels).

• Indikatur ta' Ħidma: A green light indicates normal power supply.
• Brightness Indicator: Green for low brightness, yellow for medium, red for high.
• Indikatur tal-Iċċarġjar: A red light indicates the solar panel is actively charging.
• Indikatur tal-batterija: Shows battery levels at 30%, 70%, and 100%.

Manutenzjoni

To ensure the optimal performance and longevity of your CLY Solar Projector Light, follow these maintenance guidelines:

• Tindif tal-Panew Solari: Imsaħ il-pannell solari regolarment b'ċarruta ratba u damp drapp biex tneħħi t-trab, il-ħmieġ, u l-fdalijiet. Pannell nadif jiżgura l-akbar assorbiment tad-dawl tax-xemx u effiċjenza tal-iċċarġjar.
• Light Unit Cleaning: Clean the light unit's surface and lens periodically to maintain optimal light output.
• Kura tal-batterija: The integrated lithium-polymer battery is designed for long life. Avoid prolonged storage in a completely discharged state. If storing for an extended period, ensure the battery is partially charged.
• Reżistenza għat-temp: The IP66 rating ensures resistance to water, heat, and cold. However, avoid submerging the unit in water or exposing it to extreme physical impact.

Deskrizzjoni tal-Immaġni: This image illustrates the IP66 waterproof rating of the CLY solar light, showing it functioning effectively under heavy rain. It also highlights its resistance to extreme temperatures, indicating usability in both hot and cold weather conditions, such as summer and winter.

Issolvi l-problemi

If you encounter issues with your CLY Solar Projector Light, please refer to the following common problems and solutions:

Speċifikazzjonijiet

Garanzija u Appoġġ

CLY is committed to providing high-quality products and customer satisfaction.

• Garanzija: We provide a 2-year replacement service for our product.
• Ritorni u Skambji: You can contact us via Amazon or our service email (if provided in the product packaging/manual) for returns or exchanges. We aim to respond within 24 hours.
• Riċiklaġġ: For information on recycling light bulbs, please refer to local recycling guidelines.

For further assistance, please contact CLY customer support.
