1. Introduzzjoni
Thank you for choosing the SWOFY M4 64GB MP3 Player. This device is designed to provide a versatile portable audio and media experience, featuring music playback, Bluetooth connectivity, FM radio, video playback, e-book reading, voice recording, and photo viewing. This manual provides detailed instructions to help you set up, operate, and maintain your device.
2. Kontenut tal-Pakkett
Jekk jogħġbok iċċekkja l-kontenut tal-pakkett meta tiftaħ il-kaxxa biex tiżgura li l-oġġetti kollha huma preżenti:
- SWOFY M4 64GB MP3 Player
- Earphones bil-fili
- Cable tal-Iċċarġjar tal-USB-C
- 3.5mm Audio Jack Cable
- Kawża protettiva tas-silikonju
- Manwal ta 'Istruzzjoni (dan id-dokument)
SWOFY M4 MP3 Player with included wired earphones and protective silicone case.
Fuq view of the SWOFY M4 MP3 Player product packaging.
3. Prodott Aktarview
The SWOFY M4 features a compact design with a 2.4-inch display and intuitive controls. It includes an integrated HD speaker for direct audio playback.
Illustration of the SWOFY M4 MP3 Player's integrated HD speaker function, allowing audio playback without headphones.
Main menu interface of the SWOFY M4 MP3 Player, showcasing various functions including Music, Video, Radio, Bluetooth, E-book, Settings, Record, Folder, and Photo. The device has 64GB internal storage.
4. Setup
4.1 Iċċarġjar tal-Apparat
Before first use, fully charge the MP3 player. Connect the provided USB-C cable to the device's charging port and the other end to a USB power adapter (not included) or a computer's USB port. The device features a 300mAh Lithium Polymer battery, offering up to 50 hours of music playback on a single charge (at medium volume).
SWOFY M4 MP3 Player connected to a laptop via USB for charging, highlighting its fast charging capability and 300mAh battery for extended music playback.
4.2 Power On/Off
- Biex Tixgħel: Agħfas u żomm il-buttuna tal-Qawwa sakemm l-iskrin jixgħel.
- Biex Tifi: Press and hold the Power button until the power-off prompt appears, then confirm.
4.3 Setup Inizjali
Upon first power-on, you may be prompted to select your preferred language and set the date and time. Follow the on-screen instructions to complete these initial settings.
5. Istruzzjonijiet Operattivi
5.1 Daqq tal-Mużika
Navigate to the 'Music' icon on the main menu. You can browse your music by artist, album, genre, or folder. The device supports various audio formats. The internal storage is 64GB, and it supports external MicroSD cards up to 128GB for expanded storage.
5.2 Konnettività Bluetooth
The SWOFY M4 features Bluetooth 5.3 for stable wireless connections. To connect to Bluetooth headphones or speakers:
- Go to the 'Bluetooth' menu from the main screen.
- Turn on Bluetooth on the MP3 player.
- Ensure your Bluetooth headphones/speaker are in pairing mode.
- Agħżel it-tagħmir tiegħek mil-lista ta' tagħmir disponibbli biex tqabbad.
The SWOFY M4 MP3 Player demonstrating Bluetooth 5.3 connectivity with wireless earbuds.
5.3 Radju FM
To use the FM Radio function, connect wired earphones to the 3.5mm audio jack; they act as an antenna. Navigate to the 'Radio' icon, then scan for available stations.
The SWOFY M4 MP3 Player displaying its FM Radio interface, shown with over-ear headphones.
5.4 Other Functions (Video, E-book, Record, Photo)
The device supports various other media functions. Select the corresponding icon from the main menu to access:
- Vidjow: Play compatible video files.
- E-book: Aqra t-test files.
- Rekord: Use the built-in microphone for voice recordings.
- Ritratt: View immaġni files.
5.5 File Trasferiment
Connect the MP3 player to your computer using the USB-C cable. The device will appear as a removable disk. You can then drag and drop music, video, photo, or e-book files fil-fowlders xierqa fuq l-apparat.
SWOFY M4 MP3 Player connected to wired earphones via the 3.5mm audio jack.
6. Manutenzjoni
- Tindif: Uża drapp artab u niexef biex tnaddaf l-apparat. Evita prodotti tat-tindif likwidi jew materjali li joborxu.
- Ħażna: Aħżen l-apparat f'post frisk u niexef 'il bogħod mix-xemx diretta u minn temperaturi estremi.
- Kura tal-batterija: Biex ittawwal il-ħajja tal-batterija, evita li tiċċarġja kompletament il-batterija ta' spiss. Iċċarġja l-apparat regolarment, anke jekk ma jkunx qed jintuża għal perjodi twal.
- Protezzjoni: Use the provided silicone case to protect the device from scratches and minor impacts.
7 Issolvi l-problemi
- L-apparat ma jixgħelx: Kun żgur li l-batterija hija ċċarġjata. Qabbad l-apparat ma' ċarġer għal mill-inqas 10-il minuta, imbagħad erġa' pprova ixgħelu.
- Ma tistax tikkonnettja permezz tal-Bluetooth: Ensure Bluetooth is enabled on both the MP3 player and the target device (headphones/speaker). Make sure both devices are in pairing mode and within range. Try restarting both devices.
- Ebda ħoss: Check the volume level. Ensure headphones are properly connected or Bluetooth is successfully paired. Test with different headphones or speakers.
- Files not appearing: Tiżgura files are transferred to the correct folders on the device. Verify file formats are supported by the MP3 player.
- Device freezes or is unresponsive: Agħfas u żomm il-buttuna tal-Power għal madwar 10-15-il sekonda biex terġa' tibda.
8. Speċifikazzjonijiet
| Karatteristika | Dettall |
|---|---|
| Brand | SWOFY |
| Numru tal-Mudell | M4 |
| Ħażna Interna | 64 GB |
| Ħażna espansibbli | Up to 128 GB (MicroSD card) |
| Teknoloġija tal-Konnettività | USB, Bluetooth 5.3 |
| Daqs tal-Wiri | 2.4 pulzieri |
| Tip ta 'batterija | Polimeru tal-litju (300mAh) |
| Ħajja tal-batterija | Up to 50 hours (music playback at medium volume) |
| Dimensjonijiet tal-Prodott | 0.51 x 1.61 x 2.01 pulzieri |
| Piż tal-oġġett | 3 uqija |
| Standards Appoġġjati | MP3 (and other common audio/video/image/text formats) |
| Kulur | Griż |
9. Garanzija u Appoġġ
For warranty information or technical support, please refer to the documentation included with your purchase or contact SWOFY customer service through the retailer where the product was purchased. Keep your proof of purchase for warranty claims.
