1. Prodott Aktarview
The HIMOJO Zigbee Wireless Smart Scene Switch is designed to enhance your smart home experience by providing convenient control over your Tuya Zigbee smart devices. This wireless switch allows you to create and activate custom scenes with a single touch, integrating seamlessly into your smart home automation system. It operates wirelessly and is powered by batteries, offering flexible placement without complex wiring.
Image 1.1: The HIMOJO Zigbee Wireless Smart Scene Switch, a 4-gang device, shown alongside its product packaging.
2. Setup u Installazzjoni
2.1. Gateway and Battery Requirements
This smart scene switch requires a Ċentru Tuya ZigBee (sold separately) for operation. It cannot function independently. Additionally, the device is powered by a Batterija CR2430 3V, which is not included and must be purchased separately.
Image 2.1: Visual representation highlighting the need for a CR2430 3V battery and a Zigbee gateway for the smart switch to function.
2.2. Installazzjoni Fiżika
The HIMOJO wireless switch is designed for easy installation without complex wiring. It can be mounted on a wall using the included stickers. Ensure the chosen location is within range of your Zigbee hub for optimal performance.
2.3. App Connection
- Ensure your Tuya ZigBee Hub is set up and connected to the Tuya Smart app.
- Open the Tuya Smart app on your Android or iOS device.
- Follow the app's instructions to add a new Zigbee device.
- Put the HIMOJO Smart Scene Switch into pairing mode (refer to the specific pairing instructions in the included user manual for button press sequences).
- Once detected, complete the pairing process within the app.
Image 2.2: A smartphone screen displaying the Tuya Smart app interface, illustrating the process of adding new scenarios or intelligence to control smart devices.
3. Istruzzjonijiet Operattivi
3.1. Creating Smart Scenes
The HIMOJO Smart Scene Switch allows you to create custom automation scenarios within the Tuya Smart app. Each of the four buttons on the switch can be assigned multiple functions based on different press actions.
- Ikklikkja waħda: Agħfas u rilaxx malajr.
- Ikklikkja darbtejn: Żewġ presses mgħaġġla wara xulxin.
- Stampa Twila: Agħfas u żomm il-buttuna għal ftit sekondi.
With three pairing modes per button, the 4-gang switch can achieve up to 12 unique scenes. Examples include 'away mode', 'home mode', or 'movie mode'.
Image 3.1: A visual guide demonstrating the three distinct interaction types (single click, double click, long click) available for each button on the multi-functional scene switch.
3.2. Activating Preset Scenes
Once scenes are configured in the Tuya Smart app, simply press the corresponding button on the HIMOJO Smart Scene Switch to activate the desired scenario. For instance, a single click might adjust brightness and color temperature of lights, or close smart curtains.
Image 3.2: A hand interacting with the smart scene switch to control preset room conditions, such as adjusting lighting brightness and color, and operating smart curtains.
4. Manutenzjoni
4.1. Sostituzzjoni tal-batterija
The HIMOJO Smart Scene Switch is powered by a CR2430 3V battery. When the battery level is low, the device's indicator light may signal this condition (refer to the specific indicator behavior in the included user manual). To replace the battery:
- Gently pry open the back cover of the switch.
- Remove the old CR2430 3V battery.
- Insert a new CR2430 3V battery, ensuring correct polarity.
- Agħlaq il-qoxra ta' wara sew.
5 Issolvi l-problemi
- L-apparat ma jirrispondix: Check battery level and replace if necessary. Ensure the device is within range of the Zigbee hub. Verify the Zigbee hub is powered on and connected to the network.
- Ma tistax tqabbad mal-app: Ensure the Zigbee hub is correctly set up in the Tuya Smart app. Confirm the switch is in pairing mode. Try resetting the switch (refer to the included user manual for reset procedure).
- Xeni li ma jattivawx: Verify that the scenes are correctly configured in the Tuya Smart app. Check the connectivity between the switch, hub, and target smart devices.
6. Speċifikazzjonijiet
| Karatteristika | Speċifikazzjoni |
|---|---|
| Brand | HIMOJO |
| Mudell | B0C7Z6B5LM |
| Mod ta' Operazzjoni | ON-OFF |
| Tip ta' Konnettur | Wireless |
| Tip ta 'Ċirkwit | 4-mod |
| Tip ta 'Immuntar | Mount Wall |
| Tip ta' Attwatur | Imbotta Buttuna |
| Kuntatt Materjal | Ram, Brass, Azzar Inossidabbli |
| Klassifikazzjoni tal-Protezzjoni Internazzjonali | IP54 |
| Numru ta' Pożizzjonijiet | 4 |
| Tip ta' Kontrollur | Android, iOS |
| Metodu ta' Kontroll | App, Remote, Voice |
| Protokoll tal-Konnettività | ZigBee |
| Kulur | ABJAD |
| Dimensjonijiet tal-Prodott (LxWxH) | 8.53 x 8.59 x 1.3 ċm |
| Piż tal-oġġett | 68 g |
| Sors tal-Enerġija | CR2430 3V Battery (not included) |
7. X'hemm fil-Kaxxa
- HIMOJO Smart Switch
- Stiker x 2
- Manwal għall-Utent
8. Garanzija u Appoġġ
HIMOJO provides dedicated customer support. If you have any questions or concerns regarding your Smart Scene Switch, a support team is available to assist you. Please refer to the contact information provided in the included user manual or on the official HIMOJO websit għal dettalji ta 'appoġġ.
