1. Prodott Aktarview
The AZDOME M330 is a compact 1080P Mini Dash Cam designed for vehicle security and recording. It features built-in WiFi for easy access via the AZDOME APP, smart voice control, fatigue driving reminders, and enhanced night vision capabilities. The device supports 24-hour parking mode and loop recording, ensuring continuous coverage.
Figure 1: AZDOME M330 Dash Cam and companion app.
2. X'hemm fil-Kaxxa
Upon unboxing your AZDOME M330 Dash Cam, verify that all components are present:
- AZDOME M330 Dash Cam x1
- Type-C car charger with 3.5m/12ft cable x1
- Stiker elettrostatiku x2
- Cable Clip x5
- Għodda pry x1
- Manwal għall-Utent x1
Figure 2: All components included in the AZDOME M330 package.
3. Gwida ta' Setup
3.1. Id-Daħħal tal-Kard SD
An SD card (not included) is required to store recordings. The AZDOME M330 supports up to 128GB. For reliable performance, a Class 10 or U3 micro SD card from a reputable brand like SanDisk is recommended. Format the SD card with the dash cam before first use and reformat monthly.
Figure 3: Location for SD card insertion on the dash cam.
3.2. Immuntar tad-Dash Cam
The M330 dash cam comes with a 3M sticky mount for easy installation. Choose a location on your windshield that does not obstruct your view. The rotatable mount allows for perfect angle adjustment to ensure optimal recording coverage.
Figure 4: Dash cam mounted discreetly behind the rearview mera.
Video 1: Demonstrates the installation process of the AZDOME M330 dash cam, including mounting and cable routing.
3.3. Konnessjoni tal-Enerġija
Connect the Type-C car charger to the dash cam and plug the other end into your vehicle's cigarette lighter port. The dash cam requires continuous power to operate. For 24-hour parking mode, a hardwire kit (not included) is necessary.
Figure 5: Dash cam connected to power source in a vehicle.
3.4. Installazzjoni tal-App u Konnessjoni tal-WiFi
Download the "AZDOME" app from your device's app store. The dash cam features built-in WiFi, allowing you to view, share, and download videos in real-time. Ensure your phone's cellular data is turned off when connecting to the dash cam's WiFi network to prevent connectivity issues.
Figure 6: Seamless integration with the AZDOME mobile application.
Vidjo 2: Fuqview of the AZDOME M330 dash cam's functions, including app connectivity and settings.
4. Istruzzjonijiet Operattivi
4.1. Basic Recording and Loop Recording
Once powered on, the dash cam automatically begins recording. It features loop recording, which continuously records video in segments (e.g., 1, 2, or 3 minutes). When the SD card is full, the oldest unlocked fileL-s jiġu miktuba fuqhom biex jagħmlu spazju għal reġistrazzjonijiet ġodda.
Figure 7: G-sensor and loop recording ensure important footage is captured and saved.
4.2. Kontroll tal-Vuċi Intelliġenti
The M330 dash cam supports 8 types of voice commands for hands-free operation, enhancing driving safety and convenience. Examples include "Take picture" and "Turn on WiFi".
Figure 8: Voice control allows for hands-free operation while driving.
4.3. Funzjonalità tas-Sensor-G
The built-in G-sensor detects sudden movements or collisions. In the event of an impact, the G-sensor automatically locks the current video segment to prevent it from being overwritten by loop recording. The sensitivity of the G-sensor can be adjusted via the AZDOME app settings (Low, Medium, High).
4.4. 24H Parking Mode
The M330 offers two parking modes for continuous surveillance when your vehicle is parked:
- Modalità ta' Parkeġġ ta' Sejbien ta' Ħabtiet: The G-sensor detects impacts and records video.
- Modalità ta' Parkeġġ ta' Time-Lapse: The camera records continuously for 24 hours (requires a hardwire kit, not included).
Figure 9: The 24-hour parking monitor provides continuous surveillance.
4.5. Viżjoni Super bil-Lejl
Equipped with WDR (Wide Dynamic Range) technology and a 6-glass lens, the M330 delivers clear video recordings even in low-light conditions, ensuring visibility of road signs and license plates day or night.
5. Manutenzjoni
To ensure optimal performance and longevity of your AZDOME M330 Dash Cam:
- Formattjar tal-Kard SD: Reformat your SD card monthly using the dash cam's settings to prevent data corruption and ensure smooth recording.
- Tindif: Gently wipe the lens and body of the dash cam with a soft, dry cloth. Avoid using abrasive cleaners or solvents.
- Temperatura: The dash cam is designed to operate in extreme weather conditions from -4°F to 158°F. However, prolonged exposure to direct sunlight in extremely hot conditions may affect performance.
6 Issolvi l-problemi
If you encounter issues with your AZDOME M330 Dash Cam, refer to the following common problems and solutions:
- Il-Dash Cam Mhux Tixgħel: Ensure the car charger is securely plugged into both the dash cam and the vehicle's cigarette lighter port. Check if the vehicle's power outlet is active.
- Recording Stops Unexpectedly: This can be caused by a full or corrupted SD card. Format the SD card regularly. Ensure you are using a Class 10 or U3 micro SD card.
- G-Sensor Wisq Sensittiv/Mhux Sensittiv Biżżejjed: Adjust the G-sensor sensitivity setting via the AZDOME app (Low, Medium, High) to match your driving conditions and preferences.
- Problemi ta' Konnettività tal-WiFi: When connecting to the dash cam's WiFi, ensure your phone's cellular data is temporarily disabled. This prevents your phone from trying to use mobile data instead of the dash cam's WiFi.
- Video Quality Issues (Choppy Video): Ensure your SD card is of sufficient speed (Class 10 or U3). Reformatting the card can also help.
- Tul tal-Kejbil tal-Enerġija: The included 3.5m/12ft cable is designed to be long enough for most installations, allowing for discreet routing along the headliner and A-pillar. If a longer cable is required for your specific vehicle, third-party options may be available.
7. Speċifikazzjonijiet
| Karatteristika | Dettall |
|---|---|
| Dimensjonijiet tal-Prodott | 5.51 x 2.36 x 4.72 pulzieri |
| Piż tal-oġġett | 7.4 uqija |
| Numru tal-Mudell | AZDOME M330 |
| Batteriji | 1 batteriji tal-jone tal-litju meħtieġa (inklużi) |
| Teknoloġija tal-Konnettività | Wi-Fi |
| Karatteristiċi Speċjali | G-Sensor, Parking Monitor, Voice Control, Automatic Incident Detection, Built-In GPS |
| Kulur | Iswed |
| Riżoluzzjoni tal-Qbid tal-Vidjo | 1080p |
| Tip ta 'Immuntar | Mount Windskrin |
8. Garanzija u Appoġġ
The AZDOME M330 dashboard camera includes a 12-month warranty and 24/7 technical support. If you encounter any problems with the product or require after-sales service, please email AZDOME. The R&D team aims to provide feedback within 24 working hours.
For firmware updates, PDF user manuals, and camera accessories, AZDOME provides support. Contact information can typically be found in the included user manual or on the official AZDOME websit.
