Yeedi k950 Robot Vacuum and Mop Combo User Manual

1. Introduzzjoni

Thank you for choosing the Yeedi k950 Robot Vacuum and Mop Combo. This manual provides essential information for the safe operation, maintenance, and troubleshooting of your device. Please read it thoroughly before use and retain it for future reference.

The Yeedi k950 is designed to provide efficient and comprehensive floor cleaning, combining powerful vacuuming with an oscillating mopping system. Its advanced features include 3D obstacle avoidance, smart visual mapping, and automatic carpet detection.

2. Prodott Aktarview

2.1 Karatteristiċi ewlenin

• Oscillating Mopping System: Scrubs off dried-on stains from hard floors.
• Qawwa ta' ġbid ta' 3000Pa: Effectively picks up dirt from carpets and hard floors.
• Evitar ta' Ostakli 3D: Detects and navigates around common household objects.
• Smart Visual Mapping & Navigation: Creates and saves home layouts for efficient cleaning paths.
• Sejbien ta' Tapit: Avoids carpets in mopping mode and boosts suction in vacuuming mode.
• Kontroll tal-App: Customizable cleaning settings, sequence, and area selection via the yeedi app.
• Self-Empty Station Compatibility: (Optional) Automatically empties the dustbin for up to 30 days.

2.2 Komponenti tar-Robot

Immaġni: Fuq view of the Yeedi k950 robot vacuum. This image shows the overall design of the robot, including the main power button and visual sensor on top.

Immaġni: Taħt view of the Yeedi k950 robot vacuum. This image highlights the main brush, side brushes, and the oscillating mop pad module, which are crucial for cleaning.

3. Setup

3.1 Spakkjar u Tqegħid

1. Carefully remove all packaging materials from the robot and its accessories.
2. Place the charging dock against a wall in an open area, ensuring there are no obstacles within 1 meter (3 feet) to the front and 0.5 meters (1.5 feet) to the sides.
3. Qabbad l-adapter tal-enerġija mal-baċir tal-iċċarġjar u plaggha fi żbokk tad-dawl.

3.2 Iċċarġjar inizjali

Place the robot onto the charging dock, ensuring the charging contacts align. The robot will begin charging automatically. For first-time use, fully charge the robot before operation (approximately 6 hours).

3.3 Installazzjoni u Konnessjoni tal-App

1. Download the 'yeedi' app from your mobile device's app store (iOS or Android).
2. Iftaħ l-app u segwi l-istruzzjonijiet fuq l-iskrin biex toħloq kont.
3. Add your Yeedi k950 robot by scanning the QR code on the device or selecting it from the list.
4. Qabbad ir-robot man-netwerk Wi-Fi tad-dar tiegħek kif mitlub mill-app.

4. Operazzjoni

4.1 Tibda Ċiklu ta' Tindif

You can start a cleaning cycle in two ways:

• Via the Robot: Press the main power button on the robot once.
• Via the App: Open the yeedi app and tap the 'Clean' button.

4.2 Modi tat-Tindif

The Yeedi k950 supports various cleaning modes, which can be selected via the yeedi app:

• Nadif Awtomatiku: Ir-robot inaddaf id-dar kollha tiegħek b'mod intelliġenti.
• Żona Tindif: Agħżel kmamar jew żoni speċifiċi biex tnaddaf.
• Custom Clean: Draw a custom cleaning zone on the map.

Immaġni: Illustration of the Yeedi k950's oscillating mopping system. The image shows the robot actively scrubbing a floor, demonstrating its ability to remove dried stains more effectively than traditional mopping.

Immaġni: Depiction of the Yeedi k950's carpet detection feature. The robot avoids carpets in mopping mode and automatically increases suction power when vacuuming on carpets, ensuring optimal cleaning for different floor types.

4.3 Karatteristiċi Smart

• Evitar ta' Ostakli 3D: The robot uses advanced sensors to detect and avoid common household obstacles like shoes, pet bowls, and toys, reducing the need for pre-cleaning.
• Visual Mapping: The robot creates a detailed map of your home, allowing for efficient navigation and customized cleaning plans. It can save up to three maps for multi-level homes.
• Customizable Cleaning via App: Use the yeedi app to adjust vacuum power, water flow levels, set cleaning sequences for different rooms, and define no-go zones or virtual walls.

Immaġni: Visual representation of the Yeedi k950's 3D obstacle avoidance technology. The robot is shown detecting and navigating around various objects on the floor, such as shoes and toys.

Immaġni: Diagram illustrating the Yeedi k950's ability to create and save multiple maps. This feature is beneficial for homes with multiple floors, allowing the robot to adapt to different layouts.

Immaġni: Screenshots of the yeedi mobile application interface. This image demonstrates how users can set cleaning sequences, clean specific areas, and customize settings like vacuum power and water flow levels.

5. Manutenzjoni

Regular maintenance ensures optimal performance and extends the lifespan of your Yeedi k950.

5.1 Trabbin u Filtru

• Tbattil: Empty the dustbin after each cleaning cycle. If using the optional self-empty station, the dustbin will be emptied automatically.
• Tindif: Rinse the dustbin with water as needed. Allow it to air dry completely before reinserting.
• Iffiltra: Tap the filter to remove dust. Replace the high-efficiency filter every 3-6 months, depending on usage.

5.2 Pinzell Prinċipali u Pinzelli tal-Ġenb

• Pinzell Prinċipali: Remove the main brush cover and lift out the brush. Use the cleaning tool to cut and remove tangled hair. Clean the brush bearings.
• Xkupilji tal-ġenb: Check side brushes for tangled hair or debris. If damaged, replace them.

5.3 Mopping Pad and Water Tank

• Mopping Pad: Remove the mopping pad after each use and wash it. Air dry completely.
• Tank tal-Ilma: Empty any remaining water from the tank after mopping. Clean the tank regularly to prevent mold or odors.

5.4 Sensuri u Kuntatti tal-Iċċarġjar

• Wipe all sensors (cliff sensors, anti-collision sensors, visual mapping sensor) and charging contacts on both the robot and the charging dock with a clean, dry cloth.

6 Issolvi l-problemi

If your Yeedi k950 encounters an issue, refer to the following common solutions:

For more detailed troubleshooting or persistent issues, please refer to the yeedi app or contact customer support.

7. Speċifikazzjonijiet

8. Garanzija u Appoġġ

The Yeedi k950 Robot Vacuum and Mop Combo comes with a Garanzija ta' sentejn mingħajr inkwietDin il-garanzija tinkludi:

• Responsive Customer Service.
• 1-Year Free Maintenance.
• Free Replacement for Quality Issues within the warranty period.

For warranty claims, technical support, or any inquiries, please contact yeedi customer service through the yeedi app or visit the official yeedi websit.

Immaġni: Information regarding yeedi's customer support and warranty policy, highlighting responsive service, free maintenance, and replacement for quality issues.
