1. Introduzzjoni
This manual provides essential information for the safe operation, maintenance, and troubleshooting of your Lefant LS1 Pro Robot Vacuum Cleaner. Please read it thoroughly before using the product and retain it for future reference.
1.1 Prodott Fuqview
The Lefant LS1 Pro is an intelligent robot vacuum cleaner designed to automate floor cleaning. It features LDS navigation for precise mapping, strong suction, and smart controls via an app or voice assistants.
Image: The Lefant LS1 Pro robot vacuum cleaner, black, shown next to a smartphone displaying its mapping and control application.
1.2 Karatteristiċi ewlenin
- LDS Navigation: Precision mapping for efficient cleaning paths.
- 3200Pa Suction: Powerful cleaning for various floor types.
- Mappatura ta' diversi sulari: Stores maps for different levels of your home.
- Kontroll tal-App u l-Vuċi: Manage cleaning via the Lefant app, Amazon Alexa, or Google Assistant.
- Muturi bla brushes: Equipped with multiple brushless motors for enhanced durability and performance.
- Batterija tal-Litju-Ħadid Fosfat: Designed for extended lifespan and consistent power.
- Disinn kompatt: Thin profile to clean under furniture.
Image: Visual representation of key features including stable suction, OTA online upgrades, voice reminders, and multi-floor mapping capabilities.
Immaġni: Interna view of the Lefant LS1 Pro, highlighting its six brushless motors and a lithium iron phosphate battery designed for extended machine life.
Image: A comparison illustrating the thinner design of the Lefant LS1 Pro, allowing it to cover more areas compared to standard robot vacuums.
1.3 Kontenut tal-Pakkett
Ivverifika li l-komponenti kollha huma preżenti fil-pakkett:
- Lefant LS1 Pro Robot Vacuum Cleaner
- Charging Base and Power Adapter
- 520ML Dustbin
- Pinzell tat-tindif
- Manwal għall-Utent
- 2 Filtri HEPA
- 4 Xkupilji tal-Ġnub
2. Istruzzjonijiet tas-Sigurtà
Before using this product, please read and follow all safety instructions to prevent injury or damage.
- Do not use the robot in wet environments or near liquids.
- Keep the robot away from open flames and heat sources.
- Kun żgur li l-bażi tal-iċċarġjar titqiegħed mal-ħajt fuq wiċċ livellat.
- Do not allow children or pets to operate the robot.
- Neħħi kejbils maħlula, oġġetti żgħar, u oġġetti fraġli miż-żona tat-tindif qabel l-operazzjoni.
- Do not use the robot to clean sharp objects, burning materials, or liquids.
- Only use the original power adapter and charging base provided.
3. Setup
3.1 Iċċarġjar tar-Robot
- Place the charging base against a wall in an open area, ensuring no obstacles within 1 meter to the sides and 1.5 meters in front.
- Qabbad l-adapter tal-enerġija mal-bażi tal-iċċarġjar u plaggha fi żbokk tad-dawl.
- Place the robot on the charging base. Ensure the charging contacts align. The indicator light will show charging status.
- Fully charge the robot before first use (approximately 4-5 hours).
3.2 App Connection and Initial Mapping
- Download the "Lefant" app from your mobile app store.
- Irreġistra kont u illoggja.
- Follow the in-app instructions to add your LS1 Pro robot vacuum. Ensure your Wi-Fi network is 2.4 GHz.
- For initial mapping, allow the robot to complete a full cleaning cycle of your home without interruption. This will create an accurate map in the app.
Image: A smartphone displaying the Lefant app interface, showing cleaning schedules, suction control, real-time map, area cleaning, and no-go zone settings.
4. It-tħaddim tar-Robot
4.1 Modi tat-Tindif
- Nadif Awtomatiku: The robot automatically plans the most efficient cleaning path.
- Spot Clean: Tnaddaf żona speċifika b'mod aktar intensiv.
- Tindif tat-Tarf: Tnaddaf tul il-ħitan u t-truf tal-għamara.
- Tindif Skedat: Set cleaning times via the app.
4.2 Navigazzjoni u Mappatura LDS
The LS1 Pro uses LDS (Laser Distance Sensor) navigation to create precise maps of your home. This allows for efficient cleaning paths and multi-floor mapping capabilities.
Image: The Lefant LS1 Pro robot vacuum emitting laser beams for navigation, illustrating its ability to detect objects up to 12 meters away.
Image: An illustration of the Lefant LS1 Pro's Freemove 3.0 and LDS Navigation Technology, showing its advanced mapping capabilities.
4.3 Virtual Walls, No-Go Zones, and Area Cleaning
Using the Lefant app, you can define virtual walls or no-go zones on your map to restrict the robot from entering certain areas. You can also select specific areas for cleaning.
Image: A floor plan displayed on a screen, indicating a "No-Go Zone" marked in red and a "Partial Cleaning" zone marked in blue, with the robot vacuum shown below.
Image: A series of illustrations demonstrating the robot's features: virtual forbidden zones, precise positioning for cleaning, partial zone cleaning, and automatic charging with cleaning resumption.
4.4 Kontroll tal-Vuċi
The LS1 Pro is compatible with Amazon Alexa and Google Assistant. Link your Lefant account to your voice assistant app to control the robot with voice commands.
Example command: "Alexa, turn on LS1."
Image: The Lefant LS1 Pro robot vacuum next to a smart speaker, illustrating its compatibility with Alexa and Google Assistant for voice control.
5. Manutenzjoni
Manutenzjoni regolari tiżgura prestazzjoni ottimali u testendi l-ħajja tal-vacuum cleaner robot tiegħek.
5.1 Tindif tal-Landa taż-Żibel u l-Filtru
- Agħfas il-buttuna tar-rilaxx tad-dustbin u neħħi d-dustbin.
- Iftaħ l-għatu tal-kontenitur tat-trab u vojta l-kontenut tiegħu ġo kontenitur taż-żibel.
- Remove the HEPA filter and primary filter. Tap them gently to remove dust. Do not wash HEPA filters with water.
- Rinse the dustbin with water if necessary, ensuring it is completely dry before reinstallation.
- Reassemble the filters and dustbin, then reinsert into the robot.
5.2 Tindif tal-Pinzell tal-Ġenb
Periodically check the side brushes for tangled hair or debris. Remove and clean them using the provided cleaning tool or a soft cloth. Replace worn brushes as needed.
5.3 Tindif tas-Sensor
Wipe the cliff sensors, wall sensors, and charging contacts with a clean, dry cloth to ensure proper function.
6 Issolvi l-problemi
| Problema | Kawża Possibbli | Soluzzjoni |
|---|---|---|
| Robot ma jixgħelx. | Batterija baxxa. | Place the robot on the charging base and ensure it is fully charged. |
| Robot ma jistax jikkonnettja mal-Wi-Fi. | Password tal-Wi-Fi mhux korretta; netwerk ta' 5GHz użat; robot wisq 'il bogħod mir-router. | Ivverifika l-password; żgura netwerk ta' 2.4GHz; mexxi r-robot eqreb lejn ir-router. |
| Ir-robot jeħel spiss. | Obstacles (cables, rugs, furniture). | Clear the cleaning area of obstacles. Use no-go zones for problematic areas. |
| Prestazzjoni fqira tat-tindif. | Full dustbin; dirty filters; worn brushes. | Empty dustbin; clean/replace filters; clean/replace side brushes. |
7. Speċifikazzjonijiet
- Ditta: XELLUG
- Numru tal-Mudell: LS1 (Y79)
- Dimensjonijiet tal-Prodott: 32 x 32 x 9.5 ċm
- Piż: 4.34 kg
- Kapaċità tat-Trin: 520 ml
- Qawwa: 46 Watts
- Livell ta' Storbju: 55 dB
- Ħin tal-Batterija: Sa 150 minuta (2 sigħat u 30 minuti)
- Tip ta' filtru: Filtru HEPA
- Tip ta' Kontroll: APP Control (2.4 GHz WiFi), Alexa & Google Assistant Control, Button Control
- Rakkomandazzjoni tal-wiċċ: Twapet, Pavimenti iebes
- Karatteristiċi Speċjali: Pet hair brush, hard floor brush, suitable for pet hair
8. Garanzija u Appoġġ
For warranty information and customer support, please refer to the official Lefant webis-sit jew ikkuntattja lis-servizz tal-konsumatur tagħhom direttament. Żomm l-irċevuta tax-xiri tiegħek bħala prova tax-xiri.
Ħajja tal-batterija: The battery has an estimated lifespan of 2 years.
