DEERC 1:10 Large Brushless RC Car (Model 210E) Instruction Manual

1. Introduzzjoni

The DEERC 1:10 Large Brushless RC Car, Model 210E, is a high-performance, all-terrain remote control vehicle designed for enthusiasts aged 14 and up. Featuring a powerful brushless motor, 4X4 drive system, and durable construction, it delivers an exhilarating driving experience across various landscapes. This manual will guide you through every step from initial setup to advanced maintenance, ensuring you get the most out of your RC truck.

Figure 1.1: DEERC 1:10 Large Brushless RC Car (Model 210E) and included accessories.

2. Prekawzjonijiet tas-Sigurtà

• Always operate the RC car in open areas away from people, pets, and obstacles.
• Do not operate near public roads or in crowded areas.
• Żomm idejk, xagħar, u ħwejjeġ maħlula 'l bogħod minn partijiet li jiċċaqilqu.
• Ensure batteries are charged using the provided charger and follow all battery safety guidelines.
• The RC car is IPX4 splash-proof, but not designed for full submersion in water. Avoid deep puddles or prolonged exposure to moisture.
• Is-superviżjoni tal-adulti hija rakkomandata għal utenti taħt l-età ta' 14-il sena.

3. X'hemm fil-Kaxxa

Your DEERC 210E package includes the following items:

• DEERC 1:10 Brushless RC Car (Model 210E)
• 2.4Ghz Remote Control
• 2 x 11.4V 1500mAh Li-ion Rechargeable Batteries
• Cable tal-Iċċarġjar tal-USB
• Small Parts Bag (includes spare clips, lug nuts, drive parts, and tools)
• Manwal ta' Istruzzjoni

Figure 3.1: Package contents of the DEERC 210E RC Truck.

4. Komponenti Overview

4.1 Komponenti tal-Karozza RC

• Mutur mingħajr brushes: Provides high power for speeds over 60 KM/H, equipped with a metal heat sink for efficient cooling.
• 45A Brushless ESC: Non-inductive Electronic Speed Controller with splash-proof IPX4 water resistance, over-current protection, and low voltage cut-off.
• Dual Alloy Differential: Reduces resistance during turns, improves tire wear, and ensures smooth power output.
• Strong Shock Absorber System: Four-wheel independent suspension with metal shocks to absorb vibrations and handle various terrains.
• All-terrain Tires & Wheels: High-quality rubber tires for strong grip and long-lasting performance on diverse surfaces.
• Reinforced Car Shell: Made of scratch-resistant and flexible PVC material for enhanced durability.
• Fanali ta 'quddiem LED: Front-mounted lights for improved visibility during operation.

Figure 4.1: Key internal components of the DEERC 210E RC Truck.

Figure 4.2: Close-up of the brushless motor and its heat sink.

Figure 4.3: The 45A Brushless ESC with splash-proof and protection features.

Figure 4.4: The shock absorber system for smooth handling.

Figure 4.5: Dual Alloy Differential for enhanced stability and reduced wear.

Figure 4.6: Reinforced car shell for increased durability.

Figure 4.7: All-terrain tires for superior performance on various surfaces.

4.2 Komponenti tal-Kontroll mill-Bogħod

• 2.4Ghz Radio Control System: Ensures non-interference and non-jamming operation.
• Proportional Steering & Throttle: Allows for precise control over speed and direction.
• Swiċċ tal-veloċità: Adjusts the maximum speed of the RC car.
• Ittrimm tal-Isteering: Fine-tunes the steering alignment.

Figure 4.8: The 2.4GHz Remote Control for precise vehicle operation.

5. Setup

5.1 Iċċarġjar tal-batteriji

1. Connect the provided USB charging cable to the 11.4V 1500mAh Li-ion battery.
2. Ipplaggja l-kejbil USB ma' adapter tal-enerġija USB kompatibbli (mhux inkluż).
3. The indicator light on the USB charger will show charging status (refer to charger instructions for specific light patterns).
4. Ħalli madwar 3-4 sigħat għal ċarġ sħiħ.

Figure 5.1: The two included 11.4V 1500mAh Li-ion batteries.

Figure 5.2: Battery charging connection.

5.2 Installing Batteries in the RC Car

1. Remove the body clips and lift the car shell to access the battery compartment.
2. Carefully insert a charged 11.4V Li-ion battery into the designated slot.
3. Connect the battery's red plug to the corresponding red connector inside the car.
4. Secure the battery using the Velcro straps.
5. Replace the car shell and secure it with the body clips.

5.3 Installing Batteries in the Remote Control

1. Iftaħ l-għatu tal-kompartiment tal-batterija fuq wara tal-kontroll mill-bogħod.
2. Insert 3 x AA batteries (not included) into the compartment, ensuring correct polarity.
3. Agħlaq l-għatu tal-kompartiment tal-batterija.

6. Istruzzjonijiet Operattivi

6.1 Powering On and Binding

1. Ensure the RC car battery is connected and the car shell is secured.
2. Turn on the RC car by pressing the power button located on the chassis (refer to Components Overview for exact location). The LED headlights will illuminate.
3. Turn on the remote control. The indicator light on the remote will blink, then become solid once successfully bound to the car.

6.2 Kontrolli Bażiċi

• Quddiem/Lura: Pull the trigger on the remote control to move forward, push it forward to move backward.
• Tmexxija: Turn the steering wheel on the remote control left or right to steer the car.

6.3 Aġġustament tal-veloċità

The remote control features a speed switch to adjust the maximum speed of the RC car. This is useful for beginners or for operating in smaller spaces.

Figure 6.1: The DEERC 210E demonstrating its high-speed performance.

6.4 All-Terrain Operation

The DEERC 210E is designed for all-terrain dominance, capable of handling sand, gravel, grass, and even small streams thanks to its robust build and powerful 4X4 system.

Figure 6.2: The DEERC 210E performing on diverse terrains.

6.5 Reżistenza għall-Ilma (IPX4)

The electronic speed controllers (ESC) and receiver are splash-proof with IPX4 water resistance. This means the car can handle water splashes from all directions and small puddles. However, it is not meant for full submersion. Avoid operating in deep water to prevent damage.

Video 6.1: Official product video demonstrating the DEERC 210E's performance and durability on various surfaces, including wet conditions.

7. Manutenzjoni

• Tindif: After each use, especially in dusty or muddy conditions, use the provided brush or a soft cloth to clean the car's chassis, wheels, and suspension components.
• Kura tal-batterija: Always disconnect batteries after use. Store them in a cool, dry place. Do not overcharge or over-discharge batteries.
• Kontroll tal-Komponent: Regularly inspect all screws, nuts, and moving parts for looseness or damage. Tighten as needed. Replace any broken or worn-out parts using the provided spares or ordering new ones from DEERC.
• Lubrikazzjoni: Periodically apply a small amount of silicone grease to moving parts like differentials and drive shafts to ensure smooth operation and reduce wear.

8 Issolvi l-problemi

9. Speċifikazzjonijiet

• Mudell: 210E
• Skala: 1:10 Large Scale
• Sistema tas-sewqan: 4X4 (Four-Wheel Drive)
• Mutur: Brushless 2845A 4-pole motor
• ESC: 45A Brushless ESC (IPX4 waterproof)
• L-ogħla Veloċità: 60+ KM/H (approx. 37+ MPH)
• Batteriji: 2 x 11.4V 1500mAh Li-ion (included)
• Ħin tal-logħob: 40+ minutes (with two batteries)
• Frekwenza tal-Kontroll mill-bogħod: 2.4Ghz
• Dimensjonijiet tal-Prodott: 14.17 x 11.81 x 5.91 pulzieri
• Piż tal-oġġett: 4.84 liri
• Età Rakkomandata: 14 snin 'il fuq

Figure 9.1: Dimensions of the DEERC 210E RC Truck.

10. Garanzija u Appoġġ

For any questions, technical support, or warranty inquiries regarding your DEERC 1:10 Large Brushless RC Car (Model 210E), please contact DEERC customer service. Refer to the contact information provided on the product packaging or the official DEERC websit għall-għajnuna.

DEERC is committed to providing high-quality products and excellent customer service. Please retain your proof of purchase for any warranty claims.
