Introduzzjoni
Thank you for choosing the TRUSTECH Evaporative Air Cooler. This portable unit is designed to provide a comfortable and cool environment by combining the functions of an air cooler and a humidifier. With its bladeless design, multiple speed settings, and convenient timer, it offers an efficient and safe cooling solution for your home or office.
Please read this manual thoroughly before operating the appliance and retain it for future reference.
Istruzzjonijiet tas-Sigurtà
Biex tiżgura tħaddim sikur u tevita ħsara, jekk jogħġbok osserva l-prekawzjonijiet ta' sigurtà li ġejjin:
- Always place the unit on a stable, level surface to prevent tipping and water leakage.
- Tgħaddix l-apparat, korda, jew plagg fl-ilma jew likwidi oħra.
- Skonnettja l-unità mis-sokit tal-enerġija qabel ma tnaddafha, timlaha, jew tagħmel xi manutenzjoni.
- Keep the unit out of reach of children and pets. The bladeless design enhances safety, but supervision is always recommended.
- Do not block the air inlets or outlets. Ensure adequate space around the unit for proper airflow.
- Uża biss ilma nadif tal-vit jew ilma distillat fit-tank tal-ilma.
- Do not use the appliance if the power cord or plug is damaged. Contact customer support for assistance.
- Evita li tpoġġi l-unità ħdejn sorsi ta’ sħana jew fid-dawl tax-xemx dirett.
Prodott Overview
Familiarize yourself with the components of your TRUSTECH Evaporative Air Cooler.
Figure 1: Main unit of the TRUSTECH Evaporative Air Cooler, showing its sleek design, remote control, and included ice packs.
Panel tal-Kontroll u Display
Figure 2: The clear screen display and touch-sensitive buttons on the top of the unit for easy control.
The intuitive control panel located on the top of the unit allows for easy operation. It includes buttons for Cooler, Swing, Timer, Speed, and On/Off functions. An LED display indicates current settings.
Kontroll mill-bogħod
Figure 3: The remote control allows convenient operation from up to 26.25 feet away.
The included remote control provides convenient access to all functions from a distance of up to 26.25 feet (8 meters).
Setup
- Spakkjar: Neħħi l-apparat li jkessaħ l-arja mill-imballaġġ tiegħu bir-reqqa. Żomm il-materjali kollha tal-imballaġġ għal ħażna jew trasport fil-futur.
- Pjazzament: Place the unit on a firm, level surface in the desired location. Ensure there is sufficient space around the unit for optimal airflow.
- Mili tat-Tank tal-Ilma:
Figure 4: Adding ice cubes and ice packs to the water tank for enhanced cooling.
Pull out the water tank located at the bottom rear of the unit. Fill the 4-liter water tank with clean tap water. For enhanced cooling, place the two included ice boxes (after freezing) and/or ice cubes into the water tank. Do not exceed the maximum fill line. Carefully push the water tank back into place until it clicks securely.
- Konnessjoni tal-Enerġija: Ipplaggja l-korda tad-dawl fi żbokk elettriku standard ta '110V AC.
Istruzzjonijiet Operattivi
Your TRUSTECH Evaporative Air Cooler offers multiple functions for personalized comfort.
Figure 5: The air cooler offers multiple functions including cooling, swing, timer, and adjustable speed.
- Power On/Off: Agħfas il- Mixgħul/Mitfi buttuna fuq il-pannell tal-kontroll jew fuq il-kontroll remot biex tixgħel jew titfi l-unità.
- Aġġusta tal-Veloċità tal-Fan:
Figure 6: The air cooler provides three adjustable wind speeds: Low, Medium, and High.
Agħfas il- Veloċità button repeatedly to cycle through the three available wind speeds: Low, Medium, and High. The current speed setting will be indicated on the display.
- Funzjoni Swing:
Figure 7: The 360° oscillation feature helps distribute cool air evenly throughout the room.
Agħfas il- Swing button to activate the 360° oscillation feature, which helps distribute cool air more widely across the room. Press again to stop oscillation.
- L-issettjar tat-tajmer:
Figure 8: Set the timer for up to 12 hours to enjoy uninterrupted cooling throughout the night.
Agħfas il- Timer button to set the operating time. Each press increases the timer by 1 hour, up to a maximum of 12 hours. The unit will automatically turn off once the set time has elapsed.
- Modalità tat-tkessiħ: Agħfas il- Cooler button to activate the evaporative cooling function. This mode uses the water and ice in the tank to provide a cooler, humidified airflow. Press again to deactivate.
Vidjo tal-Operazzjoni tal-Prodott
Video 1: An official demonstration of the TRUSTECH Evaporative Air Cooler, showcasinil-karatteristiċi u l-operat tiegħu.
Manutenzjoni
Manutenzjoni regolari tiżgura prestazzjoni ottimali u lonġevità tal-apparat li jkessaħ l-arja tiegħek.
- Tindif ta' barra:
Figure 9: The bladeless design allows for easy and safe cleaning of the unit's interior.
Before cleaning, always unplug the unit. Wipe the exterior surfaces with a soft, damp cloth. Do not use abrasive cleaners or solvents. The bladeless design makes the interior easy to wipe clean.
- Tindif tat-Tank tal-Ilma: The water tank should be cleaned regularly (e.g., weekly) to prevent mold or mildew buildup. Pull out the water tank, empty any remaining water, and clean it with a mild detergent and water. Rinse thoroughly. While the tank is connected by wires, it can be carefully maneuvered for cleaning.
- Ħażna: If storing the unit for an extended period, ensure the water tank is completely empty and dry. Clean the unit thoroughly, then store it in a cool, dry place, preferably in its original packaging.
Issolvi l-problemi
If you encounter issues with your air cooler, refer to the following common problems and solutions:
| Problema | Kawża Possibbli | Soluzzjoni |
|---|---|---|
| L-unità ma tixgħel. | No power; power cord not properly connected. | Check if the unit is plugged in securely. Verify the power outlet is functional. |
| No cool air/cooling effect is weak. | Water tank is empty; no ice packs/cubes; room too large or humid. | Fill the water tank. Add frozen ice packs or ice cubes. Evaporative coolers are most effective in dry climates. Ensure proper ventilation. |
| Tnixxija tal-ilma. | Water tank not properly seated; unit not on a level surface; overfilled water tank. | Ensure the water tank is securely pushed in. Place the unit on a flat, stable surface. Do not overfill the water tank beyond the MAX line. |
| Storbju mhux tas-soltu. | Water pump noise (normal); foreign object in unit. | A slight trickling sound from the water pump is normal during cooling operation. If the noise is excessive or unusual, unplug the unit and inspect for any obstructions. |
Jekk il-problema tippersisti wara li tipprova dawn is-soluzzjonijiet, jekk jogħġbok ikkuntattja l-appoġġ għall-klijenti.
Speċifikazzjonijiet
- Ditta: TRUSTECH
- Isem tal-Mudell: BLE-T08FL-3
- Tip ta 'Immuntar: Freestanding
- Karatteristika Speċjali: Portable, Timer
- Kulur: Abjad u Griż
- Kontrolli tat-Tip: Remote
- Kapaċità tal-ġibjun: 4 Litri
- Komponenti Inklużi: Tagħmir li jkessaħ l-arja
- Numru ta' Veloċitajiet: 3
- Dimensjonijiet tal-Prodott: 11.1"D x 12.1"W x 31.4"H
- Ampetà: 0.59 Amps
- Voltage: 110V
- Piż tal-oġġett: 13.07 liri
- Batteries required (for remote): No (batteries for remote not specified, assuming included or standard type)
Garanzija u Appoġġ
Deskrizzjoni tal-garanzija: Dan il-prodott jiġi b'garanzija ta' 1 snin mid-data tax-xiri.
For technical support, warranty claims, or any inquiries regarding your TRUSTECH Evaporative Air Cooler, please visit the official TRUSTECH store or contact their customer service department.
