Tristar KA-5819 Smart Electric Convector Heater User Manual

1. Istruzzjonijiet Importanti dwar is-Sigurtà

Jekk jogħġbok aqra dawn l-istruzzjonijiet bir-reqqa qabel ma tuża l-apparat u żommhom għal referenza futura. Jekk ma ssegwix dawn l-istruzzjonijiet, dan jista' jirriżulta f'xokk elettriku, nar, jew korriment serju.

• Tiżgura l-voltagIl-volum indikat fuq it-tikketta tal-klassifikazzjoni jaqbel mal-volum tal-provvista tal-elettriku tiegħektage.
• Tkoprix il-heater biex tevita li ssaħħan iżżejjed.
• Tużax dan il-heater fil-viċinanza immedjata ta’ banju, doċċa jew pixxina.
• Żomm materjali fjammabbli bħal għamara, purtieri, u oġġetti kombustibbli oħra mill-inqas metru (3 piedi) 'il bogħod minn quddiem u l-ġnub tal-heater.
• Dejjem aqla l-heater meta ma tkunx qed tuża.
• Tħaddimx il-heater b'korda jew plagg bil-ħsara, jew wara li l-heater ma jkunx qed jaħdem sew jew ikun waqa' jew ikun ġarrab ħsara b'xi mod.
• Dan l-apparat mhuwiex maħsub għall-użu minn persuni (inklużi tfal) b’kapaċitajiet fiżiċi, sensorji jew mentali mnaqqsa, jew nuqqas ta’ esperjenza u għarfien, sakemm ma jkunux ingħataw superviżjoni jew istruzzjoni dwar l-użu tal-apparat minn persuna responsabbli għas-sigurtà tagħhom.
• It-tfal għandhom ikunu sorveljati biex jiżguraw li ma jilagħbux bl-apparat.

2. Prodott Aktarview

The Tristar KA-5819 is a smart electric convector heater designed for efficient room heating. It offers multiple control options and safety features.

Karatteristiċi ewlenin:

• Output tal-Enerġija: Up to 2000W with 3 adjustable heat settings (750W, 1250W, 2000W).
• Għażliet ta' Kontroll: Manual via integrated digital LCD screen, remote control, or smartphone app (Tuya Smart).
• Funzjoni Timer: Programmable timer from 1 to 24 hours.
• Modalità Kontra l-iffriżar: Automatically activates 2000W heating when ambient temperature is too low.
• Sigurtà: Overheating protection and stable integrated feet.
• Konnettività: Compatible with 2.4 GHz WiFi networks for smart control.

Figura 1: Ġenb view of the Tristar KA-5819 convector heater. This image highlights the main power switch, air vents, and the sturdy integrated feet that provide stability. The power cord is visible at the bottom right.

3. Setup

3.1 Disimballaġġ

Carefully remove the heater from its packaging. Retain the packaging for future storage or disposal. Check for any damage during transit. The package should include the convector heater, a remote control (with CR2032 battery), and this user manual.

3.2 Tqegħid

• Place the heater on a firm, level surface. The integrated feet ensure stability.
• Ensure there is at least 1 meter (3 feet) of clear space around the heater from walls, furniture, and other objects to allow for proper air circulation and prevent fire hazards.
• Do not place the heater directly below a power socket.
• Avoid placing the heater in areas where it could be easily knocked over or where children or pets might come into contact with it.

3.3 Konnessjoni tal-Enerġija

Plug the power cord into a suitable 240V electrical outlet. Ensure the outlet is properly grounded and can handle the heater's 2000W power consumption.

4. Istruzzjonijiet Operattivi

4.1 Qawwa Inizjali

Flip the main power switch located on the side of the unit to the 'ON' position. The digital LCD screen will illuminate.

4.2 Manual Control (Digital LCD Screen)

Use the control buttons on the heater's digital LCD screen to adjust settings. The screen displays the current ambient temperature and selected settings.

• Issettjar tal-Enerġija: Select between 750W, 1250W, or 2000W for desired heat output.
• Termostat: Set the desired room temperature. The heater will automatically regulate its operation to maintain this temperature.
• Timer: Activate the timer function to set the heater to operate for a specific duration (1 to 24 hours).

4.3 Operazzjoni tal-Kontroll mill-bogħod

The included remote control allows convenient adjustment of settings from a distance. Ensure the CR2032 battery is correctly installed. Point the remote control towards the heater's display panel.

• Buttuna tal-Qawwa: Turn the heater ON/OFF.
• Mode/Heat Setting Button: Cycle through 750W, 1250W, and 2000W power levels.
• Buttuni għat-Titjib/Tnaqqis tat-Temperatura: Adjust the desired thermostat temperature.
• Buttuna tat-Tajmer: Set or adjust the operating timer.

4.4 Smart Control (Tuya Smart App)

For advanced control and remote operation, download the free Tuya Smart app from the Apple App Store or Google Play Store.

1. Niżżel l-App: Fittex għal "Tuya Smart" in your device's app store and install it.
2. Reġistrazzjoni/Idħol: Oħloq kont jew idħol fil-kont Tuya Smart eżistenti tiegħek.
3. Żid Apparat: Follow the in-app instructions to add the Tristar KA-5819 heater. Ensure your smartphone is connected to a 2.4 GHz WiFi network during the pairing process.
4. Kontroll: Once paired, you can control all heater functions (power, heat settings, thermostat, timer, anti-freeze mode) from your smartphone, even when away from home.

4.5 Modalità kontra l-iffriżar

The anti-freeze function automatically activates the 2000W heating mode if the ambient temperature drops below a certain threshold (typically around 5°C / 41°F) to prevent freezing. This mode can usually be enabled or disabled via the digital display or the Tuya Smart app.

5. Manutenzjoni

5.1 Tindif

• Dejjem aqla’ l-heater u ħallih jiksaħ kompletament qabel ma tnaddfu.
• Imsaħ l-uċuħ ta 'barra b'artab, damp drapp. Tużax tindif jew solventi li joborxu.
• Tgħaddasx il-heater fl-ilma jew tħallix l-ilma jqattar ġewwa l-heater.
• Periodically clean the air intake and outlet grilles with a vacuum cleaner to remove dust and lint.

5.2 Ħażna

When not in use for extended periods, store the heater in a cool, dry place. It is recommended to store it in its original packaging to protect it from dust and damage.

6 Issolvi l-problemi

7. Speċifikazzjonijiet

8. Garanzija u Appoġġ

For warranty information, please refer to the warranty card included with your product or visit the official Tristar website. If you encounter any issues or require technical assistance, please contact Tristar customer support. Keep your purchase receipt as proof of purchase.

• Manifattur: Tristar
• Websit: www.tristar.eu
