Victor Headlamp Manwal għall-Utent

Introduzzjoni

Thank you for choosing the Victoper Headlamp. This super bright, rechargeable LED headlamp is designed for various outdoor activities, providing powerful illumination and versatile lighting options. This manual provides detailed instructions on its features, setup, operation, and maintenance to ensure optimal performance and longevity of your device.

Image: The Victoper Headlamp, wirjaasing its design with an adjustable strap and the multi-LED light array.

Karatteristiċi tal-Prodott

• Illuminazzjoni Super Bright: Equipped with 18,000 lumens, featuring 4 advanced XPE lamp beads, 2 T6 lamp beads, and 2 COB lamp beads for powerful and wide-ranging light.
• Batterija fit-tul: High-quality battery provides 7 to 8 hours of use on a full charge, with a fast charging time of 4 to 4.5 hours.
• 8 Modi tad-Dawl: Two independent switches control various lighting combinations, including main lights, auxiliary lights, all lights on, flashing, strong white COB, weak white COB, bright red COB, and flashing red COB.
• Kap aġġustabbli 90°: Il-lamp head can be rotated 90 degrees to direct light precisely where needed.
• Klassifikazzjoni IPX5 li ma jgħaddix ilma minnha: Designed to withstand splashes and rain, ensuring reliable performance even in wet conditions.
• Comfortable and Lightweight Design: Features super adjustable straps for maximum comfort and a balanced fit, suitable for various head sizes.

Image: Illustration demonstrating the headlamp's powerful 18,000 lumens output and a maximum beam range of 100 meters.

Immaġni: Ir-rasamp covered in water droplets, highlighting its IPX5 waterproof, snowproof, dirtproof, and shockproof capabilities.

Setup

1. Iċċarġjar tar-Rasamp

Qabel l-ewwel użu, iċċarġja r-ras kompletamentamp. Locate the charging port, typically covered by a rubber flap for protection. Connect the provided USB charging cable to the headlamp and a suitable USB power source (e.g., wall adapter, power bank, computer USB port). The charging indicator light will show the charging status. A full charge takes approximately 4 to 4.5 hours.

Immaġni: Close-up view tal-headlamp's charging port, showing the signal light and power indicator, with a green LED indicating charging status.

2. Aġġustament tal-Faxxa tar-Ras

Il-kapamp features adjustable elastic straps for a comfortable and secure fit. Place the headlamp on your head and use the adjustable buckles to tighten or loosen the straps until it fits snugly without being too tight. Ensure the light unit is centered on your forehead.

Immaġni: Dettaljata view tal-headlamp, highlighting the adjustable loop buckle for strap adjustment and the location of the switch button.

Istruzzjonijiet Operattivi

The Victoper Headlamp is equipped with two independent switches to control its various lighting modes.

1. Power On/Off

Press either the Right Switch or the Left Switch once to turn on the headlamp. Press and hold either switch for a few seconds to turn off the headlamp.

2. Qlib tal-Modi

Il-kapamp offers 8 distinct lighting modes, accessible via the two switches:

• Iswiċċ tal-lemin: Cycles through the primary white light modes. Each press changes the mode in the following sequence:
  • 2 Main Lights (T6)
  • 4 Auxiliary Lights (XPE)
  • All Lights On (2 T6 + 4 XPE)
  • Id-Dwal Kollha Jteptep
• Swiċċ tax-Xellug: Cycles through the COB (Chip-on-Board) light modes, including white and red light options:
  • 2 COB Strong White Light
  • 2 COB Weak White Light
  • 2 COB Bright Red Light
  • 2 COB Flashing Red Light

You can use both switches independently to achieve different lighting combinations or to quickly access your desired mode.

Image: A visual guide to the 8 different lighting modes available, showing how each combination of LEDs illuminates.

Immaġni: Persuna liebsa r-rasamp, accompanied by a diagram illustrating the 90-degree adjustable head feature, allowing for precise light direction.

Manutenzjoni

1. Tindif

Biex tnaddaf il-headlamp, gently wipe the exterior with a soft, damp cloth. Do not use abrasive cleaners or solvents, as these can damage the surface or internal components. Ensure the charging port cover is securely closed before cleaning to prevent water ingress.

2. Ħażna

Meta ma tkunx qed tużaha għal perjodi twal, aħżen ir-rasamp in a cool, dry place away from direct sunlight and extreme temperatures. It is recommended to charge the battery every 3-6 months to maintain its health and prevent deep discharge.

3. Kura tal-batterija

Il-kapamp uses a built-in Lithium-polymer battery. Avoid completely draining the battery frequently, as this can reduce its lifespan. Always use the provided charging cable and a compatible USB power source. Do not attempt to replace the battery yourself.

Issolvi l-problemi

• Kapamp ma jixgħelx:
  • Kun żgur li l-batterija hija ċċarġjata. Qabbadha ma' sors ta' enerġija u ċċekkja l-indikatur tal-iċċarġjar.
  • Agħfas u żomm il-buttuna tal-qawwa għal ftit sekondi biex tiżgura li mhix biss pressa mgħaġġla.
• Id-dawl huwa baxx jew jitteptep:
  • The battery might be low. Recharge the headlamp bis-sħiħ.
  • Kun żgur li l-lenti hija nadifa u ħielsa mill-ħmieġ jew mill-fdalijiet.
• Il-ħajja tal-batterija hija iqsar milli mistenni:
  • Operating in higher brightness modes consumes more power. Try using lower brightness settings for longer runtime.
  • Żgura l-headlamp huwa kompletament iċċarġjat qabel l-użu.
  • Extreme cold temperatures can temporarily reduce battery performance.
• Charging indicator does not light up:
  • Check if the charging cable is securely connected to both the headlamp u s-sors tal-enerġija.
  • Ipprova port USB differenti jew adapter tal-enerġija.
  • Ensure the charging port is clean and free of obstructions.

Speċifikazzjonijiet
