1. Istruzzjonijiet Importanti dwar is-Sigurtà
Please read all instructions carefully before using this heater. Failure to follow these instructions may result in fire, electric shock, injury to persons, or property damage.
- Protezzjoni mis-sħana żejda: The heater is equipped with an automatic shut-off feature that activates if the internal temperature rises to approximately 105 degrees Fahrenheit (40.5 degrees Celsius) to prevent fire.
- Protezzjoni kontra l-qlib: The heater will automatically shut off if it is accidentally knocked over.
- Pjazzament: Keep combustible materials such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9 m) from the front of the heater and away from the sides and rear.
- Sigurtà Elettrika: Risk of electric shock. Do not open the heater. There are no user-serviceable parts inside.
- Tgħattix: Ensure the heater is never covered during operation to prevent overheating.
2. Prodott Aktarview
Familiarize yourself with the components and features of your TRUSTECH OH12 heater.
Figure 2.1: TRUSTECH OH12 Oil-Filled Radiator Heater (White)
This image displays the compact design of the TRUSTECH OH12 oil-filled radiator heater in white, highlighting its portability and simple controls.
Figure 2.2: Key Features of the TRUSTECH OH12 Heater
This image illustrates the main features of the heater, including an adjustable knob, overheat protection, quiet operation, instant warming, portability, convenience, and energy saving.
Komponenti tal-Prodott:
- Oil Fins: The heating elements that radiate warmth.
- Manku tal-ġarr: Manku integrat għal portabbiltà faċli.
- Dial tal-Kontroll tat-Termostat: Adjusts the desired temperature setting (Off, Low, High).
- Swiċċ tal-Enerġija: On/Off button for the unit.
- Base Feet: Detachable feet for stable placement.
3. Setup
Follow these steps to set up your heater for the first time:
- Carefully remove the heater and all packaging materials from the box.
- Turn the heater upside down on a soft, non-abrasive surface.
- Locate the two base feet included in the packaging.
- Slide each base foot onto the designated slots at the bottom of the heater until they securely click into place.
- Turn the heater to its upright position on a firm, level surface.
Figure 3.1: TRUSTECH OH12 Heater Dimensions
This image provides the dimensions of the heater: 15.1 inches (length) x 5.4 inches (width) x 12.4 inches (height), illustrating its compact size for easy placement.
4. Istruzzjonijiet Operattivi
Operating your TRUSTECH OH12 heater is simple:
- Plug the heater into a standard 120V AC electrical outlet.
- Turn the Power Switch to the 'ON' position. The indicator light will illuminate.
- Adjust the Thermostat Control Dial to your desired heat setting: 'Low' for gentle warmth or 'High' for faster heating.
- To set a specific temperature, turn the thermostat dial slowly clockwise until you hear a click. The heater will then cycle on and off to maintain the desired warmth.
- When finished, turn the Power Switch to 'OFF' and unplug the heater from the outlet.
Figure 4.1: Adjusting the Thermostat Control Dial
This image shows a hand adjusting the thermostat dial, which allows users to select between Off, Low, and High heat settings, and to set a specific temperature.
Figure 4.2: Quiet and Portable Operation
This image depicts the heater in a bedroom setting, emphasizing its quiet operation suitable for use while sleeping, and its portable design.
5. Manutenzjoni
The TRUSTECH OH12 heater is designed for low maintenance. The internal oil is permanently sealed and does not require refilling or replacement.
- Tindif: Regularly dust the exterior of the heater with a soft, dry cloth. Do not use abrasive cleaners or solvents.
- Ħażna: When not in use, store the heater in a cool, dry place, preferably in its original packaging.
6 Issolvi l-problemi
If your heater is not operating correctly, refer to the following common issues:
- Il-heater ma jixgħelx: Ensure the power cord is securely plugged into a working electrical outlet. Check if the power switch is in the 'ON' position.
- Il-ħiter jintefa bla mistenni: This may be due to the built-in overheat protection or tip-over safety features. Ensure the heater is on a stable, level surface and is not covered or obstructed. Allow it to cool down before attempting to restart.
- Sħana insuffiċjenti: Verify the thermostat control dial is set to a higher temperature or the 'High' setting. Ensure the room size is within the recommended heating coverage of 120 square feet.
Figure 6.1: Overheating Protection Feature
This image highlights the overheating protection feature, showing the heater in a living space with a child, emphasizing its safety for household use.
7. Speċifikazzjonijiet
| Attribut | Dettall |
|---|---|
| Brand | TRUSTECH |
| Numru tal-Mudell | OH12 |
| Karatteristiċi Speċjali | Noiseless, Overheat Protection, Portable |
| Kulur | Daisy (White) |
| Fattur tal-Formola | Pedestall |
| Użu fuq ġewwa/barra | Ġewwa |
| Użi Rakkomandati | Dar, Uffiċċju |
| Tip ta 'Immuntar | Stand |
| Tip ta' Kamra | Kamra tas-sodda, Uffiċċju tad-Dar, Kamra ta' Studju |
| Kopertura tat-Tisħin | 120 pied kwadru |
| Tip ta' Burner | Radjanti |
| Tip ta' Fjuwil | Elettriku |
| Voltage | 120 Volts (AC) |
| Ampetà | 5.83 Amps |
| Issettjar tat-Temperatura Max | 105 Grad Fahrenheit |
| Dimensjonijiet tal-Prodott | 15.1 x 5.4 x 12.4 pulzieri |
| Piż tal-oġġett | 8.58 liri |
| Data L-Ewwel Disponibbli | 17 ta’ Ottubru, 2021 |
Figure 7.1: Recommended Room Usage
This image suggests suitable locations for the heater, including the living room, bedroom, office, or any small room requiring supplemental heat.
8. Garanzija u Appoġġ
Specific warranty details and customer support contact information for the TRUSTECH OH12 heater are typically provided in the full product manual included with your purchase or can be found on the official TRUSTECH website. Please refer to those resources for comprehensive warranty coverage and support options.
