MOCREO H1 Hub User Manual

1. Introduzzjoni

The MOCREO H1 Hub is designed to facilitate remote monitoring of environmental data, such as temperature and humidity, when paired with compatible MOCREO sensors. This hub acts as a bridge, connecting your sensors to the internet, allowing you to access data and receive alerts from anywhere.

2. Informazzjoni dwar is-Sigurtà

• Ensure the device is placed in a dry environment, away from water or excessive moisture.
• Use only the provided power adapter (5V 1A) to prevent damage.
• Tippruvax tiżżarma jew issewwi l-apparat int stess. Irreferi għal persunal kwalifikat għas-servizz.
• Żomm l-apparat fejn ma jintlaħaqx mit-tfal.

3. Kontenut tal-Pakkett

Ivverifika li l-oġġetti kollha huma preżenti fil-pakkett tiegħek:

• 1 x MOCREO H1 Hub
• 1 x Kejbil tal-Enerġija
• 1 x 5V 1A Power Adapter
• 1 x Manwal tal-Utent (dan id-dokument)

Note: MOCREO sensors are not included with the H1 Hub and must be purchased separately.

4. Prodott Aktarview

The MOCREO H1 Hub is a compact device designed to connect MOCREO BLE (Bluetooth Low Energy) sensors to your network. It features a sleek design and an antenna for wireless communication. The hub facilitates data transmission from sensors to the MOCREO cloud service, enabling remote access via the MOCREO application.

Kompatibilità tas-Sensor

The H1 Hub is compatible with the following MOCREO BLE sensors:

• ST5
• ST6
• ST9
• ST10
• SW2

Note: The H1 Hub is not compatible with Zigbee ST3 and ST4 sensors, despite previous product descriptions. Please ensure your sensors are BLE compatible.

5. Istruzzjonijiet ta' Setup

5.1 Rekwiżiti ta 'qabel l-installazzjoni

• A 2.4GHz Wi-Fi network (5GHz networks are not supported). If your router is dual-band, ensure the 2.4GHz band is enabled. Cellular hotspots are also supported.
• An available Ethernet port if you prefer a wired connection.
• Compatible MOCREO BLE sensors (purchased separately).
• A smartphone or tablet to install the MOCREO application.

5.2 Konfigurazzjoni Fiżika

1. Connect the power cable to the H1 Hub.
2. Plug the 5V 1A power adapter into a standard electrical outlet. The hub will power on.
3. For an Ethernet connection, connect an Ethernet cable from your router to the hub's Ethernet port.

5.3 Installazzjoni u Konfigurazzjoni tal-App

1. Download the MOCREO application from your device's app store (iOS App Store or Google Play Store).
2. Open the MOCREO app and create an account or log in.
3. Follow the in-app instructions to add your H1 Hub. This typically involves scanning a QR code on the hub or manually entering its ID.
4. If using Wi-Fi, the app will guide you through connecting the hub to your 2.4GHz network.
5. Once the hub is connected, proceed to add your MOCREO BLE sensors through the app. Ensure sensors are within range of the hub.

6. Istruzzjonijiet Operattivi

The MOCREO H1 Hub enables a remote monitoring system for your environment. It manages up to 30 BLE sensors, collecting data and transmitting it to the MOCREO server for access via your smartphone application.

6.1 Monitoraġġ mill-bogħod

After successful setup and sensor pairing, you can view real-time temperature and humidity data from your sensors through the MOCREO app, anywhere with an internet connection.

6.2 Sensor Range

The effective distance between the H1 Hub and its sensors should be kept within 65.6 feet (20 meters) in environments with obstructions. In open, unobstructed environments, the range can extend up to 131 feet (40 meters).

6.3 Alert System

The MOCREO system provides various alert types to notify you of significant changes or issues:

• Hub Beep: An audible alert directly from the H1 Hub.
• Email Alert: Notifications sent to your registered email address.
• Notifika tal-App: Push notifications sent to your smartphone via the MOCREO app.
• Anti False Alarm: Intelligent filtering to reduce unnecessary alerts.
• Follow-up Reminder: Reminders for ongoing alert conditions.
• Notifika ta' Batterija Baxxa: Alerts when sensor batteries are low.
• Hub Offline Notification: Alerts if the H1 Hub loses its internet connection.

7. Manutenzjoni

The MOCREO H1 Hub requires minimal maintenance. Keep the device clean and free from dust. Ensure proper ventilation around the hub. No user-serviceable parts are inside.

8 Issolvi l-problemi

• Il-Hub mhux qed jikkonnettja mal-Wi-Fi:
  Ensure your Wi-Fi network is 2.4GHz. If you have a dual-band router, verify that the 2.4GHz band is active and distinct from the 5GHz band. Check that the hub is within range of your Wi-Fi router.
• Sensors not connecting to the Hub:
  Verify that the sensors are compatible BLE models (ST5, ST6, ST9, ST10, SW2). Ensure sensors are within the recommended range of 65.6 feet (20 meters) from the hub. Check sensor batteries.
• App issues or errors:
  Ensure your MOCREO app is updated to the latest version. Try restarting the app or your smartphone. If issues persist, contact MOCREO customer support.
• Hub frequently goes offline:
  Check your internet connection stability. Ensure the hub is receiving consistent power. If using Wi-Fi, consider moving the hub closer to the router or using an Ethernet connection for improved stability.
• Incorrect sensor readings:
  Ensure sensors are placed in appropriate locations, away from direct heat sources or extreme drafts. Calibrate sensors if the app provides this option.

9. Speċifikazzjonijiet

10. Garanzija u Appoġġ

MOCREO provides comprehensive support for its products:

• Garanzija: 2 years free warranty.
• Appoġġ Tekniku: Appoġġ ta 'servizz tekniku tul il-ħajja.

For assistance, please refer to the contact information provided in your product packaging or visit the official MOCREO websit.
