ZunDian 6-f'1 1800 Amp Jump Starter & Power Station

Introduzzjoni

The ZunDian 6-in-1 Power Station is a versatile and essential tool for automotive emergencies, outdoor activities, and general power needs. It integrates a powerful jump starter, a 260 PSI air compressor, a 400W AC power inverter, a 12V power station, a 15W USB-A port, and a 300-lumen LED flashlight into one compact unit. Designed for convenience and reliability, it ensures you are prepared for various situations.

Informazzjoni dwar is-Sigurtà

WARNING: Read all safety instructions before use.

• Dejjem ilbes protezzjoni għall-għajnejn meta tħaddem il-jump starter.
• Ensure proper polarity connections (positive to positive, negative to negative) to avoid damage or injury. The unit features 10 intelligent protection systems for safety.
• Tesponix l-unità għax-xita jew kundizzjonijiet imxarrba.
• Żomm fejn ma jintlaħaqx mit-tfal.
• Opera f'żona b'ventilazzjoni tajba.
• Do not disassemble the unit. Refer to qualified service personnel for repairs.

Prodott Overview

The ZunDian 6-in-1 Power Station is designed for ease of use with clearly labeled controls and integrated components.

Figura 1: Quddiem view of the ZunDian 6-in-1 Power Station.

Kontrolli tal-Panew ta' Quddiem

• Gejġ tal-Pressjoni: Displays air pressure for the compressor.
• Compressor Switch: Jattiva l-kompressur tal-arja.
• Reverse Polarity Indicator: Illuminates if jumper cables are connected incorrectly.
• Swiċċ tad-Dawl: Turns the LED worklight on/off.
• DC Volts Meter: Shows the unit's battery voltage.
• Jack tal-iċċarġjar: Input for recharging the power station.
• Buttuna tal-Istatus tal-Batterija: Press to check the remaining battery charge.
• DC 12V Sockets: Two 12V outlets for powering DC devices.
• Dawl tax-xogħol LED: Provides illumination for dark environments.

Figura 2: Dettaljat view tal-kontrolli tal-pannell ta' quddiem.

Karatteristiċi tal-Panew ta 'wara

• Port USB-A: 15W output for charging mobile devices.
• Ħwienet AC: Two 110V/120V outlets (400W total) for AC devices.
• Inverter Switch: Activates the AC power inverter.
• Jumper Safety Switch: Must be turned ON for jump-starting functionality.
• Air Compressor Hose Storage: Compartment for the integrated air compressor hose.

Figura 3: Wara view of the power station showing outlets and switches.

Aċċessorji Inklużi

• Integrated heavy-duty battery booster jumper clamps.
• Integrated inflatable hose.
• 1x AC Power Adapter.
• 1x DC Power Adapter.
• 1x Manwal għall-Utent.
• 1x Car accessories (likely various nozzles for inflation).
• 1x Car Repair Tools (e.g., safety hammer).

Setup

Iċċarġjar Inizjali

Before first use, fully charge the ZunDian Power Station. It comes with a 22Ah sealed lead-acid rechargeable battery.

1. Connect the AC Power Adapter to the Charging Jack on the front panel.
2. Plug the AC Power Adapter into a standard wall outlet.
3. Allow the unit to charge until the battery indicator shows full charge.
4. Alternatively, use the DC Power Adapter to charge the unit from a 12V car outlet.

Figure 4: Charging the power station.

Istruzzjonijiet Operattivi

Aqbeż Tibda Vettura

Id-1800 Peak Amp Jump Starter can start 8.5L Gasoline Engines and 6.0L Diesel Engines for various 12V vehicles.

1. Kun żgur li l-ignition tal-vettura tkun mitfija.
2. Connect the red (positive) jumper clamp mat-terminal pożittiv (+) tal-batterija tal-vettura.
3. Connect the black (negative) jumper clamp to a clean, unpainted metal part of the vehicle's engine block or chassis, away from the battery.
4. Turn the Jumper Safety Switch on the rear panel to the 'ON' position.
5. Attempt to start the vehicle. If it doesn't start immediately, wait a few minutes and try again.
6. Once the vehicle starts, immediately turn the Jumper Safety Switch to 'OFF'.
7. Disconnect the black (negative) clamp first, then the red (positive) clamp.

Figure 5: Jump starting a vehicle.

Bl-użu tal-Kumpressur tal-Ajru

The 260 PSI air compressor can inflate tires (195/65/R15 automotive tires from 0 psi to 35 psi in 3 minutes) and other inflatables.

1. Retrieve the inflatable hose from its storage compartment on the rear panel.
2. Attach the hose securely to the tire valve stem or appropriate inflatable adapter.
3. Turn the Compressor Switch on the front panel to 'ON'.
4. Monitor the pressure gauge until the desired pressure is reached. The sensor automatically stops when proper pressure is reached.
5. Turn the Compressor Switch to 'OFF' and disconnect the hose.

Figure 6: Inflating a car tire with the air compressor.

Figure 7: Multi-purpose air compressor for vehicles, bicycles, balls, and inflatables.

Portable Power Station Functionality

The unit can power up to 6 devices simultaneously with its 400W AC inverter, USB-A port, and 12V DC sockets.

1. For AC devices, turn the Inverter Switch on the rear panel to 'ON'. Plug your 110V/120V devices into the AC outlets.
2. For USB devices, plug your USB cable into the USB-A Port on the rear panel.
3. For 12V DC devices, plug them into the DC 12V Sockets on the front panel.

Figure 8: Powering various devices with the ZunDian Power Station.

Manutenzjoni

Kura u Ħażna

• If not used for a long time, charge the battery jumper within three months to maintain battery health.
• Aħżen l-unità f'post frisk u niexef 'il bogħod mix-xemx diretta u minn temperaturi estremi.
• Żomm l-unità nadifa u ħielsa minn trab u debris.

Issolvi l-problemi

Speċifikazzjonijiet

Garanzija u Appoġġ

The ZunDian 6-in-1 Power Station comes with a 1-year warranty and friendly customer service. For any questions, issues, or to request replacement parts (e.g., lost charger or nozzle), please contact ZunDian customer support.

Informazzjoni ta' Kuntatt:

• Refer to your user manual for specific contact details or visit the official ZunDian websit.
