Kit ta' Filtrazzjoni tal-Arja Intelliġenti Spider Farmer ta' 4 pulzieri bil-Manwal tal-Istruzzjonijiet tal-Kontrollur GGS

1. Introduzzjoni

Thank you for choosing the Spider Farmer 4-Inch Smart Air Filtration Kit. This comprehensive ventilation system is designed to provide optimal climate control for your grow tent or hydroponic setup. It includes a powerful inline duct fan, a high-performance carbon filter, flexible ducting, and a smart GGS controller with app control capabilities for precise temperature and humidity management.

2. Informazzjoni dwar is-Sigurtà

• Dejjem skonnettja l-enerġija qabel l-installazzjoni, it-tindif, jew il-manutenzjoni.
• Kun żgur li l-konnessjonijiet elettriċi kollha jikkonformaw mal-kodiċijiet u r-regolamenti lokali.
• Tħaddimx il-fann b'korda jew plagg bil-ħsara.
• Keep the fan and controller away from water or excessive moisture.
• Dan il-prodott huwa maħsub għall-użu fuq ġewwa biss.
• Do not insert fingers or foreign objects into the fan.

3. Kontenut tal-Pakkett

Your Spider Farmer 4-Inch Smart Air Filtration Kit includes the following components:

• 4-Inch Inline Duct Fan
• GGS Temperature Humidity Controller with App Control
• Carbon Filter (4-inch)
• Flexible Ducting (25 ft length)
• 3 Stainless Steel Clamps
• Ċineg imdendlin

4. Prodott Aktarview

The Spider Farmer Smart Air Filtration Kit is engineered for efficient and quiet operation, ensuring a healthy environment for your plants.

4.1. Inline Duct Fan

The inline duct fan features an EC motor for energy efficiency, consuming only 27 watts while delivering 205 CFM airflow. Its lightweight ABS blades enhance airflow by 40%, and it operates at a low noise level of 26.8 dB. The fan is ETL/FCC listed for safety.

Immaġni: Sezzjoni trasversali view of the inline duct fan highlighting the energy-efficient EC motor and airflow patterns.

4.2. Filtru tal-Karbonju

The heavy-duty carbon filter includes a metal housing and stainless steel flanges for durability. It utilizes RC412 activated carbon for effective odor control and air purification, with a 38mm carbon layer for enhanced absorption. A pre-filter is included to capture large particles, extending the filter's lifespan.

Immaġni: Splodiet view of the premium carbon filter, showing its layers including the pre-filter, outer mesh, charcoal bed, and inner mesh.

4.3. GGS Controller

The GGS Controller integrates app control for remote management of the fan. It includes a temperature and humidity sensor for real-time climate monitoring and automated regulation. The controller is powered via its RJ12 port from the inline fan, eliminating the need for an external power supply.

Image: Close-up of the high-precision 3-in-1 sensor, indicating its temperature and humidity measurement capabilities.

5. Setup u Installazzjoni

Follow these steps to set up your Spider Farmer Air Filtration Kit:

1. Mount the Fan and Filter: Use the provided hanging straps to secure the inline duct fan and carbon filter to the tent's support bars. Ensure the fan is positioned to draw air through the filter.
2. Qabbad il-Kanal: Attach the flexible ducting to the fan and filter using the stainless steel clamps. Ensure all connections are airtight to prevent air leaks.
3. Connect GGS Controller: Plug the RJ12 cable from the inline fan into the GGS Controller. The controller will power on automatically.
4. Qawwa Mixgħul: Connect the inline fan's power cord to a suitable power outlet.

Image: Diagram illustrating the simple and smart connection of the inline fan to the GGS controller via an RJ12 cable, showing the fan as the power source for the controller.

Image: Various installation suggestions for the ventilation system within a grow tent, showing different configurations for air intake and exhaust.

5.1. Installazzjoni Videos

6. Istruzzjonijiet Operattivi

The Spider Farmer Smart Air Filtration Kit offers flexible control options through both the GGS Controller and a dedicated mobile application.

6.1. Kontroll tal-App

Connect your GGS Controller to the Spider Farmer App to manage your ventilation system remotely. The app allows you to monitor climate conditions, adjust fan speed, and set automated programs from anywhere.

Image: Screenshot of the Spider Farmer mobile app interface, showing options for speed adjustment, timer settings, temperature mode, humidity mode, and power control for the inline fan.

6.2. GGS Controller Operation

The GGS Controller provides direct control and real-time data. Use the rotary knob to navigate through the interface, scroll or move between options, and press to confirm selections. The controller displays current temperature, humidity, and fan settings.

Image: Close-up of the GGS Controller's display and rotary knob, showing temperature, humidity, and fan settings, along with navigation instructions.

Modi Operattivi:

• Modalità Manwali: Manually set the fan speed from 0% to 100%.
• Time Slot Mode: Program the fan to start and stop at specific times, with adjustable running and standby speeds.
• Modalità Ċiklu: Set the fan to run for a specified duration and then pause for another set duration, repeating the cycle a chosen number of times.
• Environment Mode: Prioritize either temperature or humidity. The fan will automatically adjust its speed to maintain the target environmental conditions.

Image: The GGS Controller display showing scheduling options for the inline fan, including start time, end time, operation speed, and standby speed.

7. Manutenzjoni

Regular maintenance ensures optimal performance and longevity of your air filtration kit.

• Filtru tal-Karbonju: The pre-filter should be cleaned or replaced periodically depending on usage and air quality. The main carbon filter can be reversed to extend its life. Replace the carbon filter when odor control effectiveness diminishes.
• Tubi: Inspect the flexible ducting for any tears or damage that could affect airflow. Ensure clamps remain secure.
• Fann: Keep the fan blades and housing clean from dust and debris to maintain efficient airflow and quiet operation.

8 Issolvi l-problemi

• Il-Fann Mhux Mixgħul: Check if the power cord is securely plugged into an outlet and the fan. Ensure the RJ12 cable is properly connected to the GGS Controller. Verify the fan is not set to 'Off' in manual mode or within a 'standby' period in programmed modes.
• Qari mhux preċiż tat-Temperatura/Umdità: Ensure the 3-in-1 sensor is positioned correctly and not obstructed. Avoid placing the sensor directly in airflow or near heat sources.
• Poor Odor Control: Check the carbon filter for blockages or saturation. Clean or replace the pre-filter. Consider reversing the carbon filter if it hasn't been done recently.
• Kwistjonijiet ta' Konnettività tal-App: Ensure your mobile device has a stable internet connection and the GGS Controller is within Wi-Fi range. Restart the app and controller if necessary.

9. Speċifikazzjonijiet

Image: Diagram showing the physical dimensions and key specifications of the inline duct fan and associated cables.

10. Garanzija u Appoġġ

For warranty information, technical support, or any questions regarding your Spider Farmer product, please refer to the official Spider Farmer webis-sit jew ikkuntattja lis-servizz tal-konsumatur direttament. Żomm l-irċevuta tax-xiri tiegħek għal talbiet ta' garanzija.
