Frizzlife PX500-A Tankless Reverse Osmosis Water Filtration System User Manual

1. Introduzzjoni

The Frizzlife PX500-A is a tankless reverse osmosis (RO) water filtration system designed to provide clean, great-tasting water directly from your tap. This system utilizes advanced filtration technology, including an alkaline remineralization stage, to remove a wide range of contaminants while adding beneficial minerals back into the water. Its compact, tankless design saves significant under-sink space and reduces the risk of secondary contamination.

Figure 1.1: Frizzlife PX500-A System with included faucet.

2. Karatteristiċi ewlenin

• Superior Filtration Performance: Utilizes a 0.0001 micron RO membrane (ASR313-500g) to eliminate over 1000 types of contaminants (99.99%), including fluoride, chlorine, chloramine, TDS, lime, lead, and other heavy metals.
• Disinn mingħajr tank: High capacity of 500 gallons per day (GPD) eliminates the need for a traditional storage tank, saving up to 70% under-counter space and preventing secondary contamination.
• Installazzjoni faċli: Pre-loaded filters and an integrated design allow for self-installation with minimal effort. All necessary components are included.
• Filter Life Monitor & Quick Change: Integrated monitor indicates when filter replacement is needed. Filters can be replaced in approximately 2 seconds with a simple twist mechanism.
• Remineralization & Alkalization: The post-alkaline filter (ASR313-A) adds essential minerals and increases water pH to over 7.5 for improved taste and health benefits.
• Effiċjenza Għolja: Achieves a pure to drain ratio of 1.5:1, significantly reducing water waste compared to conventional RO systems.

Figure 2.1: Filtration stages of the Frizzlife PX500-A system, detailing the PPC, RO Membrane, and TC-A layers.

Figure 2.2: The compact, tankless design of the PX500-A system, saving up to 70% under-sink space.

Figure 2.3: Demonstrates the quick 3-second filter replacement feature and the pH adjustment capability of the remineralization filter.

Figure 2.4: Explanation of why alkaline water is beneficial, including properties like optimal hydration and antioxidant effects.

3. Kontenut tal-Pakkett

Verify that all components listed below are present in your package before beginning installation.

Figure 3.1: All components included in the PX500-A RO system package.

• PX500-A RO System Unit (with 3 filters loaded)
• Delicate Faucet
• Ixxotta Sarġ
• Valv tal-Ilma tal-Għalf
• Sett tal-Konvertitur
• 1/4" White Tubing
• 1/4" Red Tubing
• 3/8" White Tubing
• Tejp tal-plamer
• 1/4" Quick Fitting
• Manwal għall-Utent (dan id-dokument)

4. Konfigurazzjoni u Installazzjoni

The Frizzlife PX500-A system is designed for easy DIY installation. Follow these steps carefully. It is recommended to watch the official installation video for visual guidance.

4.1 Lista ta 'Kontroll ta' Qabel l-Installazzjoni

• Ensure you have adequate space under your sink for the unit (Dimensions: 35.56 x 12.7 x 45.72 cm).
• Ikkonferma li l-kontenut kollu tal-pakkett huwa preżenti.
• Gather necessary tools: adjustable wrench, drill (if drilling a new faucet hole), screwdriver, utility knife.
• Itfi l-provvista tal-ilma kiesaħ għas-sink tiegħek.

4.2 Passi ta' Installazzjoni

1. Install the RO Faucet: If you don't have an existing hole, drill a 1-inch hole in your countertop or sink. Secure the new faucet using the provided hardware.
2. Connect the Feed Water Adapter: Locate your cold water supply line under the sink. Install the feed water adapter (T-valve) to divert water to the RO system. Ensure a tight seal using plumber's tape.
3. Install the Drain Saddle: Choose a suitable location on the drain pipe (above the P-trap). Drill a 1/4-inch hole and secure the drain saddle.
4. Qabbad it-tubi:
   • Qabbad il- tubi ħomor from the feed water adapter to the "IN" port on the PX500-A unit.
   • Qabbad il- white tubing (1/4") from the "RO" port on the unit to the RO faucet.
   • Qabbad il- black tubing from the "DRAIN" port on the unit to the drain saddle.
5. Place the PX500-A Unit: Position the unit upright under the sink.
6. Qabbad l-Enerġija: Ipplaggja l-adapter tal-enerġija fi żbokk elettriku standard.
7. Laħlaħ is-Sistema: Turn on the cold water supply. Open the RO faucet and let the water run for 15-30 minutes to flush the system and remove any carbon fines. Close the faucet.

Figure 4.1: Comprehensive diagram illustrating the connection points for the Frizzlife PX500-A system, including the RO faucet, kitchen faucet, drain saddle, feed water adapter, and power connection. Optional connections for an ice maker (IMC-1) and mini water tank (MWT3) are also shown.

For a detailed visual guide, please refer to the official Frizzlife installation video available on their websit: www.frizzlife.com

Figure 4.2: Optional mini tank connection (MWT3, sold separately) to provide more stable water flow and eliminate initial lag.

5. Operazzjoni

5.1 Tqassim tal-Ilma

To dispense purified water, simply open the dedicated RO faucet. The system will automatically activate and begin producing water. The flow rate is approximately 0.4 GPM (gallons per minute) at 60 psi.

5.2 Dwal Indikaturi

The control panel on the front of the unit features indicator lights to provide system status and filter life information:

• Dawl Blu: Indicates normal operation and good filter status.
• Dawl aħmar: Indicates that a filter needs replacement. The system may also emit an audible beep.

Figure 5.1: The filter life monitor on the PX500-A unit, showing blue for good status and red for filter change required.

6. Manutenzjoni

6.1 Skeda ta' Sostituzzjoni tal-Filtru

Regular filter replacement is crucial for maintaining optimal system performance and water quality. The system's filter life monitor will alert you when a filter change is necessary.

6.2 Kif Tissostitwixxi l-Filtri

Filter replacement is a quick and simple process:

1. Turn off the water supply to the RO system at the feed water adapter.
2. Skonnettja l-adapter tal-enerġija mis-sokit elettriku.
3. Locate the filter cartridge to be replaced.
4. Dawwar il-kartuċċa tal-filtru l-qadima kontra l-arloġġ biex tiftaħha u tneħħiha.
5. Insert the new filter cartridge, aligning the arrows, and twist clockwise to lock it into place.
6. Ixgħel il-provvista tal-ilma u daħħal l-adapter tal-enerġija.
7. Flush the new filter by running water from the RO faucet for a few minutes as per the filter's specific instructions.

Figura 6.1: Aktarview of the quick filter change process and estimated filter lifespans for ASR 311, ASR 312-500G, and ASR 313-A filters.

7 Issolvi l-problemi

This section addresses common issues you might encounter with your Frizzlife PX500-A system. If the problem persists, please contact customer support.

8. Speċifikazzjonijiet tal-Prodott

Figure 8.1: Comparison of Frizzlife RO systems, highlighting the PX500-A's specifications.

9. Garanzija u Appoġġ

Frizzlife is committed to providing high-quality products and customer satisfaction. For warranty information, technical support, or to purchase replacement filters, please visit the official Frizzlife websit jew ikkuntattja lit-tim tas-servizz tal-konsumatur tagħhom.

Websit: www.frizzlife.com

Please have your model number (PX500-A) and purchase date ready when contacting support.
