Introduzzjoni
Thank you for choosing the Bluedio H2 Active Noise Cancelling Headphones. This manual provides detailed instructions on how to set up, operate, and maintain your headphones to ensure optimal performance and longevity. Please read this manual carefully before using the product.
Karatteristiċi tal-Prodott
- Slide Control and Easy Operation: Intuitive slide control for volume, song switching, voice assistant activation, and call management. Features a built-in sensor for automatic music play/pause when worn or removed.
- Kwalità tal-Ħoss HiFi: Equipped with high-powered 57mm dynamic drivers for detailed audio, bright treble, and rich, powerful bass with low distortion.
- Għażliet ta' Konnessjoni Multipli: Supports wireless Bluetooth 5.0, 3.5mm audio cable connection for wired use, and direct music playback via an inserted SD card.
- Ħin tal-logħob estiż: Up to 40 hours of continuous music playback thanks to the efficient Bluetooth 5.0 chip and long-lasting battery.
- Disinn Lest għall-Ivvjaġġar: Includes an Airplane Audio Converter Plug, making it suitable for business travel and in-flight use.
Nibdew
Kontenut tal-Pakkett
Malli tiftaħ il-kaxxa, jekk jogħġbok ivverifika li l-oġġetti kollha elenkati hawn taħt huma preżenti:
- Bluedio H2 Headphones
- Kejbil tal-Iċċarġjar tat-Tip C
- Cable Awdjo 3.5mm
- Manwal għall-Utent
- Airplane Audio Converter Plug
Image: Bluedio H2 Headphones and their included accessories.
Iċċarġjar tal-headphones
Before first use, fully charge your Bluedio H2 headphones. Connect the provided Type-C charging cable to the headphone's charging port and the other end to a USB power source (e.g., computer USB port, wall adapter). The indicator light will show charging status and turn off when fully charged.
Qawwa mixgħul/mitfi
To power on the headphones, locate the power button and press and hold it until the indicator light illuminates. To power off, press and hold the power button again until the indicator light turns off.
Tqabbil tal-Bluetooth
- Kun żgur li l-headphones huma mitfija.
- Agħfas u żomm il-buttuna tal-qawwa sakemm id-dawl indikatur jteptep blu u aħmar alternattivament, u dan jindika l-modalità ta' tqabbil.
- Fuq l-apparat tiegħek (smartphone, tablet, kompjuter), attiva l-Bluetooth u fittex apparati disponibbli.
- Select "Bluedio H2" from the list of found devices.
- Ladarba jkun konness, id-dawl indikatur isir blu solidu.
Konnessjoni bil-fili
For a wired connection, insert one end of the 3.5mm audio cable into the headphone's audio jack and the other end into your audio device's 3.5mm output. The headphones can be used passively in wired mode even if the battery is depleted.
Daqq tal-Kard SD
The Bluedio H2 headphones support direct music playback from an SD card. Insert a compatible SD card with your music files into the designated SD card slot on the headphone. The headphones will automatically detect and begin playing music from the card.
Operazzjoni
Slide Control Functions
The Bluedio H2 features intuitive slide controls on the ear cup for various functions:
- Volum 'il fuq: Slide finger upward on the control area.
- Volum 'l isfel: Slide finger downward on the control area.
- Kanzunetta li jmiss: Slide finger forward (right) on the control area.
- Kanzunetta ta' qabel: Slide finger backward (left) on the control area.
- Play/Pawsa: Tap the center of the control area.
- Tweġiba/Tmiem Sejħa: Tap the center of the control area during an incoming call.
- Irrifjuta Sejħa: Press and hold the center of the control area during an incoming call.
- Attiva l-Assistent tal-Vuċi: Double-tap the center of the control area.
Immaġni: Dettaljata view of the slide touch controls and button layout on the Bluedio H2.
Smart Sensor Auto Play/Pause
The Bluedio H2 headphones are equipped with a built-in sensor that automatically pauses music playback when you remove the headphones and resumes playback when you put them back on. This feature enhances convenience and conserves battery life.
Kanċellazzjoni Attiva tal-Istorbju (ANC)
To activate or deactivate the Active Noise Cancellation feature, locate the ANC switch on the headphone. Toggle the switch to enable or disable noise cancellation. ANC helps reduce ambient noise for a more immersive listening experience.
Image: Bluedio H2 headphones delivering HiFi sound quality with ANC.
Manutenzjoni
Tindif
To maintain the condition of your headphones, wipe them regularly with a soft, dry cloth. Do not use abrasive cleaners, solvents, or strong chemicals, as these may damage the surface or internal components. Keep the charging port and audio jack free of dust and debris.
Ħażna
When not in use, store the headphones in a cool, dry place, away from direct sunlight and extreme temperatures. Avoid placing heavy objects on top of the headphones to prevent damage. For long-term storage, ensure the headphones are partially charged to preserve battery health.
Issolvi l-problemi
If you encounter any issues with your Bluedio H2 headphones, please refer to the following table for common problems and their solutions:
| Problema | Kawża Possibbli | Soluzzjoni |
|---|---|---|
| Il-headphones ma jixegħlux. | Il-batterija hija eżawrita. | Charge the headphones fully using the provided Type-C cable. |
| Ma tistax tqabbad permezz tal-Bluetooth. | Il-headphones mhumiex fil-modalità ta' tqabbil; il-Bluetooth tal-apparat huwa mitfi; wisq 'il bogħod mill-apparat. | Kun żgur li l-headphones huma fil-modalità ta' tqabbil (iteptipu aħmar/blu). Ixgħel il-Bluetooth fuq l-apparat tiegħek. Mexxi l-headphones eqreb lejn l-apparat (fi żmien 10 metri). |
| L-ebda ħoss fil-modalità Bluetooth. | Volum baxx wisq; mhux konness; output awdjo mhux korrett magħżul. | Increase headphone and device volume. Re-pair the headphones. Check audio output settings on your device. |
| Slide controls are unresponsive. | Incorrect gesture; temporary software glitch. | Ensure correct slide direction. Power off and restart the headphones. |
| Music pauses unexpectedly. | Smart sensor activated (headphones removed or shifted). | Kun żgur li l-headphones jintlibsu b'mod korrett u sikur. |
| L-ANC mhux qed jaħdem b'mod effettiv. | ANC switch off; environmental noise too high. | Ensure ANC switch is on. ANC is most effective against low-frequency, constant noise. |
Speċifikazzjonijiet
| Karatteristika | Dettall |
|---|---|
| Isem tal-Mudell | H2-C |
| Teknoloġija tal-Konnettività | Bluetooth, bil-fili |
| Teknoloġija tal-Komunikazzjoni mingħajr Fili | Bluetooth 5.0 |
| Medda Bluetooth | 10 Meters |
| Headphones Jack | 3.5 mm Jack |
| Tip ta' Sewwieq Awdjo | Sewwieq Dinamika |
| Daqs tas-Sewwieq tal-Awdjo | 57 Millimetru |
| Medda ta' Frekwenzi | 20 Hz - 20,000 Hz |
| Kontroll tal-Ħoss | Kanċellazzjoni Attiva tal-Ħoss |
| Tip ta' Kontroll | Kontroll tal-Vuċi, Mess |
| Ħajja tal-batterija | Up to 40 Hours (continuous music time) |
| Tip ta 'batterija | 1 batterija tal-polimer tal-litju (inkluża) |
| Materjal | Metal, Plastic, and Synthetic Leather |
| Piż tal-oġġett | 0.52 Kilogrammi (1.14 libbra) |
| Dimensjonijiet tal-Prodott | 7.52 x 6.97 x 3.1 pulzieri |
| Tqegħid tal-widnejn | Fuq Widnejn |
| Livell ta 'Reżistenza għall-Ilma | Mhux Reżistenti għall-Ilma |
Garanzija u Appoġġ
Bluedio products are designed and manufactured to the highest quality standards. For information regarding warranty coverage and support, please refer to the warranty card included in your product packaging or visit the official Bluedio website. If you require further assistance or have questions not covered in this manual, please contact Bluedio customer support.
