Manwal tal-Utent tal-AZDOME Mirror Dash Cam

Introduzzjoni

This manual provides detailed instructions for the installation, operation, and maintenance of your AZDOME Mirror Dash Cam. Please read this manual thoroughly before using the product to ensure proper function and safety.

Informazzjoni dwar is-Sigurtà

• Tħaddimx l-apparat waqt is-sewqan.
• Kun żgur li l-apparat huwa mmuntat sew u ma jostakolax il-vista tiegħek view.
• Use only the provided power cable. Using incompatible cables may cause malfunction or damage, including sudden power drops or abnormal speaker noise.
• Żomm l-apparat 'il bogħod minn temperaturi estremi u dawl tax-xemx dirett.
• Tippruvax iżarma jew isewwi l-apparat lilek innifsek. Ikkuntattja l-appoġġ tal-klijent għall-assistenza.

Kontenut tal-Pakkett

The image displays the main AZDOME Mirror Dash Cam unit, a 32GB SD card, a GPS module, and the rear camera. These are the primary components included in the product package.

• AZDOME Mirror Dash Cam (Main Unit)
• Kamera ta 'wara bil-Cable
• Modulu GPS
• Car Charger (Cigarette Lighter Power Cord)
• 32GB AZDOME Class10 microSD Card
• Ċineg tal-Immuntar (x4)
• Wiring Tools/Pry Tool
• Drapp tat-Tindif
• User Manual (Japanese) - Note: This document serves as an English version.
• Anti-reflection Film
• Recording Sticker (Front/Rear Recording in Progress)

This diagram illustrates the various components included in the product package, such as the main unit, rear camera, GPS antenna, power cable, mounting accessories, and documentation.

Prodott Overview

The AZDOME Mirror Dash Cam features a 12-inch touch screen display, a right-side camera optimized for right-hand drive vehicles, and voice control functionality. It records in 1080P Full HD with a 170° wide-angle lens for the front camera and includes a waterproof rear camera.

This image highlights the right-side camera lens placement, specifically designed for right-hand drive vehicles to provide an optimal field of view and accurate recording from the driver's perspective.

The image demonstrates the 11.8-inch SuperView display technology, showcasing its higher resolution (1920x440px) compared to other products, resulting in clearer and more vibrant images, and reducing glare from reflections.

This image illustrates the high-quality night vision feature, powered by the SONY-IMX415 sensor and an 8-layer glass lens, enabling bright and clear recordings even in low-light conditions.

Setup u Installazzjoni

Immuntar tad-Dash Cam

1. Attach the dash cam to your vehicle's rearview mirror using the provided rubber straps. Ensure it is securely fastened and does not obstruct your view.
2. Adjust the camera lens angle for optimal recording. The camera lens is 360° adjustable.

Qawwa tal-Konnessjoni

1. Insert the included car charger into your vehicle's cigarette lighter socket.
2. Connect the other end of the power cable to the dash cam's power input port.
3. Route the power cable neatly along the windshield and dashboard using the provided wiring tools to avoid interference with driving.

This diagram illustrates the recommended wiring path for the dash cam's power cable and rear camera cable, ensuring a tidy and safe installation within the vehicle's interior.

Installazzjoni tal-Kamera ta 'wara

1. Mount the rear camera at the back of your vehicle, typically above the license plate or inside the rear window. Ensure it has a clear view.
2. Qabbad il-kejbil tal-kamera ta' wara mal-port magħżul fuq l-unità prinċipali tal-kamera tad-dashboard.
3. Route the rear camera cable carefully to the front of the vehicle, concealing it along the vehicle's trim.

Installazzjoni tal-Modulu GPS

1. Attach the external GPS module to the dash cam.
2. Place the GPS module on the dashboard or windshield where it has a clear view tas-sema għal riċeviment ottimali tas-sinjal.

Istruzzjonijiet Operattivi

Qawwa mixgħul/mitfi

The dash cam will automatically power on and begin recording when the vehicle's ignition is turned on. It will power off automatically when the ignition is turned off.

Operazzjoni Touch Screen

The 12-inch touch screen allows for intuitive control. Swipe left/right to switch between front and rear camera views, and swipe up/down to adjust the camera angle on the screen.

This image illustrates the three available display modes: full-screen front camera view, split-screen showing both front and rear cameras simultaneously, and full-screen rear camera view. Users can easily switch between these modes via touch gestures.

Voice Control Functions

The dash cam supports 8 voice commands for hands-free operation. Speak the commands clearly near the device:

• "Monitor On" / "Monitor Off"
• "Back Camera" / "Front Camera"
• "Start Recording" / "Stop Recording"
• "Ħu Ritratt"
• "Video Lock"

This image visually represents the voice control feature, listing commands such as "Monitor On," "Monitor Off," "Front Camera," "Back Camera," "Start Recording," "Stop Recording," "Take Photo," and "Video Lock," enabling hands-free operation for enhanced driving safety.

Funzjonalità GPS

With the external GPS module connected, the dash cam records driving speed and location data along with video footage. Din id-dejta tista' tkun viewed using a dedicated PC viewer software (compatible with Windows and Mac systems) which integrates with Google Maps to display your driving trajectory.

Nota: Ensure your computer is connected to the internet before playing back recordings with GPS data.

Parking Monitoring (Requires Hardwire Kit)

The dash cam features a built-in battery for emergency recording. When the engine is off, if the device detects a collision, it will automatically start recording. These emergency recordings are automatically locked and will not be overwritten.

For continuous 24-hour parking surveillance, an optional AZDOME hardwire kit (ASIN: B08J7RYNBW) is required and sold separately.

Loop Recording and G-Sensor

The dash cam records video in seamless loops. When the memory card is full, the oldest unlocked footage will be overwritten. The built-in G-sensor detects sudden impacts or collisions and automatically locks the current video segment to prevent it from being overwritten, ensuring critical evidence is preserved.

Rear Camera Reverse Assist

When shifting into reverse, the dash cam automatically displays the rear camera view, and the angle adjusts downwards for better visibility. The adjusted angle will be saved for subsequent reverse maneuvers.

This image demonstrates the ability to toggle the rear camera view between a normal image and a mirror image, providing flexibility for different user preferences and installation types.

Manutenzjoni

• Regularly format the microSD card (at least once a month) to ensure optimal performance and prevent data corruption.
• Clean the camera lenses and screen with the provided cleaning cloth or a soft, lint-free cloth. Do not use abrasive cleaners.
• Kun żgur li l-kejbils kollha huma konnessi sew u ħielsa minn ħsara.

Issolvi l-problemi

Speċifikazzjonijiet

Garanzija u Appoġġ

AZDOME products come with a standard warranty. For specific warranty details, technical support, or service inquiries, please refer to the warranty card included in your package or visit the official AZDOME website. You can also contact AZDOME customer service directly through their Amazon store page for assistance.

AZDOME Official Store: Visit AZDOME Store on Amazon.co.jp
