Phomemo M110 Portable Bluetooth Label Printer

1. Introduzzjoni

This manual provides detailed instructions for the setup, operation, maintenance, and troubleshooting of your Phomemo M110 Portable Bluetooth Label Printer. Please read this manual thoroughly before using the device to ensure proper functionality and to extend the product's lifespan. The Phomemo M110 is designed for efficient and convenient label printing for various applications, including home organization, small businesses, and office use.

Figure 1.1: Phomemo M110 Label Printer in use, demonstrating its versatility for different label types.

2. Prodott Aktarview

The Phomemo M110 is a compact and portable thermal label printer that operates without ink, offering a cost-effective and clean printing solution. It connects wirelessly via Bluetooth to your mobile devices and can also connect via USB to PC/Mac for broader compatibility.

2.1. Kontenut tal-Pakkett

Malli tiftaħ il-kaxxa, jekk jogħġbok ivverifika li l-komponenti kollha huma preżenti:

• Printer tat-Tikketti Phomemo M110
• 1 Roll of Labels (40 x 30 mm, 100 pieces)
• Mikro USB Cable
• Manwal għall-Utent

Figure 2.1: Phomemo M110 package contents, including the printer, a label roll, USB cable, and manual.

2.2. Karatteristiċi ewlenin

• Stampar Termali mingħajr Linka: Utilizes direct thermal technology, eliminating the need for ink cartridges or toner.
• Disinn portabbli: Kompatt u ħfief, ideali għall-użu fuq il-go.
• Konnettività Bluetooth: Seamless connection to iOS and Android smartphones and tablets via the 'Print Master' app.
• Konnettività USB: Connects to Windows PC and Mac computers via USB (beta support).
• Ħajja twila tal-batterija: Equipped with a 1500mAh built-in lithium battery for extended use.
• Kompatibilità Wiesgħa tat-Tikketti: Supports label widths from 20mm to 50mm.
• Riżoluzzjoni Għolja: Features a 203 dpi print resolution for clear and crisp labels.
• Upgraded Printhead: Incorporates a printhead imported from Japan ROHM Company for enhanced clarity and stability.

Figure 2.2: The upgraded printhead of the Phomemo M110, highlighting improved print clarity and stability.

3. Speċifikazzjonijiet

4. Gwida ta' Setup

4.1. Iċċarġja l-Istampatur

Before first use, fully charge the Phomemo M110 printer. Connect the provided Micro USB cable to the printer's charging port and the other end to a 5V-2A power adapter (not included) or a computer's USB port. The indicator light will show charging status.

4.2. Installing the App/Software

For mobile devices (iOS/Android), download the 'Print Master' app from your device's app store. For PC/Mac, download the 'Labelife' software from the official Phomemo websit.

Figure 4.1: The Phomemo M110 supports connectivity with various devices and dedicated software.

4.3. Loading Label Rolls

1. Open the printer's top cover by gently pressing the release button or lifting the cover.
2. Insert the label roll into the compartment, ensuring the labels feed out from the top and are aligned correctly. The printable side of the label should face upwards.
3. Close the top cover firmly until it clicks into place. Ensure the label protrudes slightly from the output slot.

4.4. Konnessjoni tal-Printer

4.4.1. Bluetooth Connection (Mobile Devices)

1. Ixgħel il-printer Phomemo M110.
2. Ippermetti Bluetooth fuq it-tagħmir mobbli tiegħek.
3. Open the 'Print Master' app. The app will automatically search for and connect to the printer. Do not pair via your phone's Bluetooth settings directly.
4. Once connected, the printer icon in the app will indicate a successful connection.

4.4.2. USB Connection (PC/Mac)

1. Install the 'Labelife' software on your computer.
2. Connect the printer to your computer using the provided Micro USB cable.
3. Open the 'Labelife' software. The software should detect the connected printer.

5. Istruzzjonijiet Operattivi

5.1. Using the 'Print Master' App (Mobile)

The 'Print Master' app offers extensive features for creating and customizing labels.

• Librerija tal-Mudelli: Access over 300 pre-designed templates for various purposes (e.g., address labels, price tags, organization labels).
• Disinn tad-dwana: Create labels from scratch using text, images, barcodes (1D and QR), shapes, and icons.
• Stampar tal-lott: Efficiently print multiple labels from a single design, ideal for small businesses or large organizational tasks.

Figure 5.1: The 'Print Master' app allows for free editing and template-based label creation.

5.2. L-istampar ta' tikketta

1. Kun żgur li l-istampatur ikun mixgħul u konness mat-tagħmir tiegħek.
2. Open the 'Print Master' app or 'Labelife' software.
3. Agħżel jew oħloq id-disinn tat-tikketta mixtieq tiegħek.
4. Confirm the label size matches the roll loaded in the printer.
5. Adjust print density or other settings if necessary.
6. Tap the 'Print' button in the app/software.

Figure 5.2: The Phomemo M110 supports stable batch printing of multiple labels.

5.3. Practical Applications

The Phomemo M110 is versatile for various labeling needs:

• Negozju Żgħir: Prezz tags, product labels, ingredient lists, barcodes.
• Organizzazzjoni tad-Dar: Pantry labels, storage box labels, date labels for food.
• Użu tal-Uffiċċju: File labels, address labels, asset tagging.

Figure 5.3: Using the Phomemo M110 for home organization, specifically labeling food containers.

6. Manutenzjoni

6.1. Tindif tal-Istampar

To maintain optimal print quality, regularly clean the printhead. Use a cotton swab lightly dampened with rubbing alcohol to gently wipe the printhead surface. Ensure the printer is turned off and cool before cleaning. Allow the printhead to dry completely before closing the cover and resuming use.

6.2. Storing Label Rolls

Store unused thermal label rolls in a cool, dry place away from direct sunlight and excessive heat to prevent premature fading or damage to the thermal coating.

6.3. Kura tal-batterija

To prolong battery life, avoid fully discharging the printer frequently. If the printer will not be used for an extended period, charge it to about 50% and store it in a cool, dry place. Recharge every few months to prevent deep discharge.

7 Issolvi l-problemi

7.1. Kwistjonijiet Komuni u Soluzzjonijiet

• Il-printer mhux qed jikkonnettja permezz tal-Bluetooth:
  Ensure Bluetooth is enabled on your device and the printer is turned on. Connect through the 'Print Master' app, not directly via your phone's Bluetooth settings. Restart both the printer and your device.
• Poor print quality (faint or unclear):
  Check if the label roll is inserted correctly with the printable side facing up. Clean the printhead as described in the Maintenance section. Adjust the print density setting in the app/software. Ensure you are using genuine Phomemo thermal labels.
• Labels not feeding correctly or jamming:
  Ensure the label roll is properly seated and aligned in the compartment. Check for any obstructions in the label path. Make sure the labels are not stuck together.
• Il-printer mhux qed jixgħel:
  The battery might be depleted. Connect the printer to a power source using the USB cable and allow it to charge for at least 30 minutes before attempting to turn it on again.
• App/Software crashes or freezes:
  Ensure your app/software is updated to the latest version. Close and restart the app/software. If the issue persists, try reinstalling the app/software.

8. Garanzija u Appoġġ

Phomemo products are designed for reliability and performance. While specific warranty details are not provided in this manual, please refer to the warranty information included with your purchase or visit the official Phomemo webis-sit għall-aktar politika ta' garanzija aġġornata.

For technical support, troubleshooting assistance, or inquiries regarding spare parts and software updates, please contact Phomemo customer service through their official website or the contact information provided in your product packaging. Please note that information regarding spare parts availability and guaranteed software updates is not available at this time.

Għal aktar riżorsi u informazzjoni dwar il-prodott, tista' żżur Phomemo Brand Store on Amazon.
