1. Introduzzjoni
The Losi Mini-T 2.0 1/18th-scale 2WD Truck is a reinvention of the original Mini-T, incorporating modern technology and Team Losi Racing engineering. This model offers features and options previously unavailable in its class. With updated suspension geometry derived from the TLR 22 platform and the inclusion of waterproof electronics with a 2.4Ghz radio system, the Mini-T 2.0 sets a new standard for mini RC vehicles.
Designed for RC enthusiasts seeking a compact vehicle with the performance characteristics of a 1/10 scale model, the Mini-T 2.0 features a mid-motor configuration for improved balance, oil-filled shocks, an aluminum chassis, and a comprehensive range of option parts. It comes as a total ready-to-run package, delivering TLR engineering and performance in a 1/18th size.
For detailed information on waterproof standards, please refer to the complete product instruction manual available as a PDF: Losi Mini-T 2.0 User Manual PDF.
2. Informazzjoni dwar is-Sigurtà
TWISSIJA:
Aqra l-manwal tal-istruzzjonijiet KOLLU biex tiffamiljarizza ruħek mal-karatteristiċi tal-prodott qabel ma tħaddem. Jekk il-prodott ma jitħaddemx b'mod korrett, dan jista' jirriżulta fi ħsara lill-prodott, lill-proprjetà personali u jikkawża korriment serju. Dan huwa prodott sofistikat għal passatemp. Għandu jitħaddem b'kawtela u b'sens komun u jeħtieġ xi kapaċità mekkanika bażika. Jekk dan il-Prodott ma jitħaddemx b'mod sikur u responsabbli, dan jista' jirriżulta fi korriment jew ħsara lill-prodott jew proprjetà oħra. Dan il-prodott mhuwiex maħsub għall-użu mit-tfal mingħajr is-superviżjoni diretta ta' adult. Tużax ma' komponenti inkompatibbli jew tbiddilx dan il-prodott b'xi mod barra mill-istruzzjonijiet ipprovduti minn Horizon Hobby, LLC. Il-manwal tal-prodott fih struzzjonijiet għas-sigurtà, it-tħaddim u l-manutenzjoni. Huwa essenzjali li taqra u ssegwi l-istruzzjonijiet u t-twissijiet kollha fil-manwal, qabel l-assemblaġġ, is-setup jew l-użu, sabiex tħaddem b'mod korrett u tevita ħsara jew korriment serju.
3. Karatteristiċi ewlenin
- Scaled Down Version: A scaled-down version of the Team Losi Racing 1/10th 22T Stadium Truck.
- Mid Motor Configuration: Provides a better-balanced chassis for improved performance on various surfaces, balancing steering and traction.
- Durable Aluminum Chassis: Enhances strength and durability while significantly improving overall performance.
- Adjustable Shocks: Injection-molded shocks feature threaded shock collars for easy preload and ride height adjustments.
- Ready-To-Run (RTR): Fully assembled and ready to operate right out of the box, with all necessary components included.
- Waterproof Electronics: Equipped with waterproof electronics for enhanced durability in various conditions.
- Full Ball Bearings: (less steering) for smooth operation and reduced friction.
- Servo Saver: Protects the steering servo from impact damage.
- BK Bar Tires with Dish Wheels: Optimized for traction and performance.
Image: The Losi Mini-T 2.0 RC Truck, showcasing its compact design and vibrant livery.
4. X'hemm fil-Kaxxa
The Losi Mini-T 2.0 RTR Truck comes as a complete package, meaning everything required to get started is included:
- (1) Losi 1/18 Mini-T 2.0 RTR Truck
- (1) 3-CH 2.4GHz Transmitter
- (1) ESC/Receiver 2.4GHz
- (1) Dynamite 7.4V 650mAh 2S 20C EC2 LiPo Hardcase Battery
- (1) Dynamite USB 2S LiPo charger
- (1) Spektrum™ SX107 Micro Metal Gear Servo
- (1) Dynamite® 47T 280 Brushed Motor
- (4) AAA batteries (for transmitter)
No additional items are needed to complete the setup and begin operation.
Image: An icon representing a USB power supply, which is included for charging the battery.
5. Gwida ta' Setup
5.1 Iċċarġjar tal-batterija
- Connect the included Dynamite USB 2S LiPo charger to a compatible USB power supply (e.g., a wall adapter, computer USB port).
- Connect the Dynamite 7.4V 650mAh 2S 20C EC2 LiPo Hardcase Battery to the charger. Ensure the connection is secure.
- Observe the charger's indicator light. It will typically show a specific color (e.g., red) during charging and change to another color (e.g., green) when charging is complete. Refer to the charger's specific instructions for light indications.
- Ladarba tkun iċċarġjata kompletament, skonnettja l-batterija mill-ċarġer.
5.2 Installing Batteries in the Transmitter
- Locate the battery compartment on the back of the 3-CH 2.4GHz Transmitter.
- Iftaħ l-għatu tal-kompartiment tal-batterija.
- Insert the four (4) included AAA batteries, ensuring correct polarity (+/-).
- Agħlaq l-għatu tal-kompartiment tal-batterija sew.
5.3 Installing the Vehicle Battery
- Kun żgur li s-swiċċ tal-enerġija tal-vettura jkun fil-pożizzjoni OFF.
- Locate the battery compartment on the Mini-T 2.0 truck.
- Carefully insert the charged LiPo battery into the compartment.
- Connect the battery to the ESC/Receiver's power connector. Ensure a firm connection.
- Secure the battery compartment cover or strap.
Image: The chassis of the Mini-T 2.0, illustrating the layout of the battery and electronic components.
6. Istruzzjonijiet Operattivi
6.1 Ixgħel u Irbit
- Ixgħel it-trasmettitur l-ewwel.
- Then, turn on the power switch on the Mini-T 2.0 truck.
- The ESC/Receiver will automatically bind with the transmitter. A solid light on the receiver indicates a successful bind.
6.2 Sewqan tal-Vettura
- Tmexxija: Use the steering wheel on the transmitter to control the direction of the truck (left/right).
- Throttle: Use the trigger on the transmitter to control speed and direction (forward/reverse/brake).
- Pull the trigger back for forward motion.
- Push the trigger forward for brake.
- Push the trigger forward again for reverse.
- Aġġustamenti tat-Trim: Use the steering trim and throttle trim dials on the transmitter to fine-tune the vehicle's straight-line tracking and neutral throttle position.
6.3 Waterproof Electronics
The Mini-T 2.0 is equipped with waterproof electronics, allowing for operation in damp conditions. However, it is important to note that "waterproof" does not mean the vehicle can be submerged. Avoid operating in standing water or extreme wet conditions. After running in wet conditions, always clean and dry the vehicle thoroughly to prevent corrosion and damage to components. Refer to the full instruction manual for specific waterproof standards and maintenance guidelines.
Image: The Mini-T 2.0 demonstrating its capability on a dirt track, highlighting its performance.
7. Manutenzjoni
Regular maintenance is crucial for the longevity and optimal performance of your Losi Mini-T 2.0. Perform these checks after every few runs or as needed:
- Tindif: After each use, especially in dusty or dirty environments, clean the vehicle using a soft brush or compressed air to remove debris. Avoid using water directly on non-waterproof components.
- Inspecting Fasteners: Check all screws and nuts for tightness. Vibrations during operation can loosen fasteners.
- Kontroll tas-Sospensjoni: Inspect the shocks for leaks and ensure smooth operation. Check suspension arms for any damage or cracks.
- Spezzjoni tas-Sistema ta' Trasmissjoni: Check the gears for wear or damage. Ensure the motor pinion and spur gear mesh is correct.
- Wheel and Tire Check: Ensure wheels are securely attached and tires are not excessively worn or damaged.
- Kura tal-batterija: Always store LiPo batteries at a storage charge (around 3.8V per cell) if not using for extended periods. Never fully discharge or overcharge LiPo batteries.
Immaġni: Dettaljata view of the front wheel and suspension, emphasizing components that require regular inspection.
8 Issolvi l-problemi
| Problema | Kawża Possibbli | Soluzzjoni |
|---|---|---|
| Vehicle does not turn on. | Battery not charged or connected; ESC/Receiver switch off; Transmitter batteries dead. | Charge vehicle battery; Ensure battery is connected; Turn on ESC/Receiver switch; Replace transmitter batteries. |
| L-ebda tweġiba mill-vettura. | Not bound to transmitter; Out of range; Loose wiring. | Re-bind transmitter and receiver; Operate within range; Check all wiring connections. |
| Steering not straight. | Steering trim incorrect; Damaged steering linkage/servo. | Adjust steering trim on transmitter; Inspect steering components for damage. |
| Motor runs but wheels don't turn. | Stripped spur gear or pinion; Loose wheel nuts; Damaged drivetrain. | Inspect and replace gears; Tighten wheel nuts; Check axles and differentials. |
9. Speċifikazzjonijiet
| Karatteristika | Dettall |
|---|---|
| Dimensjonijiet tal-Prodott | 17.7 x 8.1 x 5 pulzieri (44.96 x 20.57 x 12.7 ċm) |
| Piż tal-oġġett | 1.8 liri (0.82 kg) |
| Numru tal-Mudell | LOS01015T3 |
| Età Rakkomandata mill-Manifattur | 14 snin 'il fuq |
| Batteriji (Inklużi) | 4 AAA batteries (for transmitter), 1 Dynamite 7.4V 2S 650mAh 20C Li-Po Battery (for vehicle) |
| Data ta' Rilaxx | 1 ta’ Settembru, 2020 |
| Manifattur | Losi |
10. Garanzija u Appoġġ
For warranty information, technical support, or replacement parts, please contact Losi customer service or refer to the official Losi website. Horizon Hobby, LLC is the manufacturer and distributor of Losi products.
You can also refer to the comprehensive user manual PDF for detailed warranty terms and contact information: Losi Mini-T 2.0 User Manual PDF.
