Introduzzjoni
This manual provides detailed instructions for the installation, operation, and maintenance of your WOOX R4600 Smart Indoor WiFi Camera. Please read this manual thoroughly before using the product to ensure correct usage and optimal performance. Keep this manual for future reference.
Setup
Kontenut tal-Pakkett
- WOOX R4600 Smart Indoor WiFi Camera
- Adapter tal-Enerġija
- Cable USB
- Kit tal-Immuntar (viti, tappijiet tal-ħajt)
- Manwal għall-Utent
App Installation and Device Pairing
- Download the WOOX Home App: Fittex għal 'WOOX Home' in your smartphone's app store (iOS or Android) and install the application.
- Oħloq Kont: Open the WOOX Home app and register for a new account or log in if you already have one.
- Qawwa fuq il-Kamera: Connect the camera to a power source using the provided USB cable and power adapter. The camera's indicator light will begin to flash, indicating it is ready for pairing.
- Żid Apparat: In the WOOX Home app, tap the '+' icon or 'Add Device' to begin the pairing process. Select 'Smart Camera' from the device list.
- Qabbad ma' WiFi ta' 2.4GHz: Ensure your smartphone is connected to a 2.4GHz WiFi network. The WOOX R4600 camera only supports 2.4GHz WiFi. Enter your WiFi network password in the app.
- Skennja l-Kodiċi QR: The app will generate a QR code. Hold your smartphone screen with the QR code approximately 15-20 cm (6-8 inches) in front of the camera lens. The camera will emit a sound when the QR code is successfully scanned.
- Tqabbil Komplet: Follow the on-screen prompts in the app to complete the pairing process. Once connected, you can name your camera and access its features.
WOOX R4600 Smart Camera setup process: Install Woox Home App, Add device, Go to the operation page. This image illustrates the three main steps for initial setup and connection of the camera to the mobile application.
Istruzzjonijiet Operattivi
Live View u Reġistrazzjoni
Once the camera is successfully paired, open the WOOX Home app and select your camera from the device list to access the live video feed. From the live view interface, you can manually record video, take screenshots, and access recorded footage.
Awdjo Two-Way
The WOOX R4600 camera features a built-in microphone and speaker, enabling two-way communication. Tap the microphone icon in the live view interface to speak through the camera, and listen to audio from the camera's surroundings.
WOOX R4600 Smart Camera demonstrating two-way audio conversation. A user is shown interacting with a baby via the camera's built-in microphone and speaker, controlled through the WOOX Home app on a smartphone.
Motion Detection and Smart Alerts
The camera is equipped with motion detection technology. You can enable and customize motion detection settings within the WOOX Home app. When motion is detected, the camera can send push notifications to your smartphone, allowing you to monitor activity in real-time.
WOOX R4600 Smart Camera's smart alert feature. The image depicts a motion detection event, with a red bell icon indicating an alert, and a smartphone displaying the live feed of the detected activity.
Viżjoni bil-lejl infrared
The WOOX R4600 automatically switches to infrared night vision mode in low-light conditions, providing clear black-and-white video footage even in complete darkness. This feature ensures continuous surveillance around the clock.
WOOX R4600 Smart Camera's infrared night vision device. The image shows a child sleeping in a dimly lit room, illustrating how the camera intelligently senses light changes to activate night vision mode for clear monitoring in low-light conditions.
Wide-Angolu View
The camera features a wide-angle lens designed to cover a broad area, minimizing blind spots and allowing you to monitor more of your indoor space with a single device.
WOOX R4600 Smart Camera's wide-angle lens capability. The image shows a panoramic view of a room, illustrating how the camera provides extensive coverage without blind spots, capturing every corner of the home.
Amazon Alexa Integrazzjoni
The WOOX R4600 camera is compatible with Amazon Alexa. You can link your camera to your Alexa account to view the live feed on compatible devices such as the Echo Show by using voice commands like "Alexa, show me the [camera name] camera."
WOOX R4600 Smart Camera integrated with Amazon Alexa. An Echo Show device displays the live feed from the camera, demonstrating the voice command 'Alexa, show me the living room camera'.
Ħażna Lokali
The camera supports local storage via a microSD card (up to 128GB, not included). Insert a formatted microSD card into the designated slot to enable continuous recording or event-triggered recording, which can be configured in the app.
Manutenzjoni
Tindif tal-Kamera
To maintain optimal image quality, regularly clean the camera lens and body. Use a soft, dry, lint-free cloth. Avoid using harsh chemicals, abrasive cleaners, or solvents, as these can damage the camera's surface or lens coating.
Aġġornamenti tal-Firmware
Periodically check for firmware updates through the WOOX Home app. Keeping your camera's firmware updated ensures you have the latest features, security enhancements, and bug fixes. Follow the app's instructions for any available updates.
Issolvi l-problemi
Camera Not Connecting to WiFi
- Ensure your WiFi network is 2.4GHz. The WOOX R4600 does not support 5GHz WiFi.
- Verify that your WiFi password is entered correctly in the WOOX Home app.
- Place the camera closer to your WiFi router to improve signal strength.
- Erġa' ibda r-router u l-kamera tiegħek, imbagħad erġa' pprova l-proċess ta' tqabbil.
- If the indicator light is not flashing, try resetting the camera (refer to the app for specific reset instructions).
Kwalità Fqira tal-Immaġni
- Clean the camera lens with a soft cloth to remove any dust or smudges.
- Ensure there is adequate lighting in the area, or that night vision is functioning correctly in low light.
- Iċċekkja l-veloċità tal-konnessjoni tal-internet tiegħek. Konnessjoni bil-mod tista' taffettwa l-kwalità tal-istriming.
No Motion Detection Alerts
- Verify that motion detection is enabled in the WOOX Home app settings for your camera.
- Check the sensitivity settings for motion detection; adjust if too low.
- Ensure that notification permissions are enabled for the WOOX Home app on your smartphone.
- Confirm that the camera has a stable internet connection.
Kwistjonijiet tal-Awdjo f'Żewġ Direzzjonijiet
- Ensure your smartphone's volume is turned up.
- Check that the microphone and speaker functions are enabled in the app.
- Verify that the WOOX Home app has microphone permissions on your smartphone.
Speċifikazzjonijiet
| Karatteristika | Speċifikazzjoni |
|---|---|
| Isem tal-Mudell | WOOX R4600 |
| Riżoluzzjoni ta' Reġistrazzjoni tal-Vidjo | 1080p HD |
| Teknoloġija tal-Komunikazzjoni mingħajr Fili | Wi-Fi (2.4GHz biss) |
| Fattur tal-Formola | Koppla |
| Voltage | 5 Volts (DC) |
| Konsum tal-Enerġija | 5 Watt-sigħat |
| Dimensjonijiet (L x W x H) | 5.3 x 3.2 x 11.3 ċm |
| Piż | 96 Gramm |
| Karatteristiċi Speċjali | Motion Detector, Two-Way Audio, Night Vision |
| Apparati Kompatibbli | Smartphone (iOS/Android), Amazon Alexa |
| Sors tal-Enerġija | Qawwa AC |
| Użu Rakkomandat | Sorveljanza |
| Ħażna | Karta MicroSD (sa 128GB) |
Informazzjoni dwar Garanzija
WOOX products typically come with a limited warranty. Please refer to the warranty card included in your product packaging or visit the official WOOX website for detailed warranty terms and conditions, including coverage period and claim procedures. Keep your proof of purchase for warranty service.
Appoġġ għall-Klijent
If you encounter any issues or have questions regarding your WOOX R4600 Smart Indoor WiFi Camera that are not addressed in this manual, please contact WOOX customer support. You can usually find contact information (email, phone, or support portal) on the official WOOX website or within the WOOX Home application.
Għal aktar riżorsi, żur il- WOOX Official Websit.
