1. Introduzzjoni
The UGEARS Wolf-01 Handgun is a mechanical 3D wooden puzzle designed for assembly. This model functions as a rubber band shooter, offering an engaging building experience and interactive play. It is crafted from high-quality, laser-cut wooden pieces that fit together without the need for glue.
Image 1: The fully assembled UGEARS Wolf-01 Handgun model, shown alongside spare rubber bands and a small wooden part.
2. Informazzjoni dwar is-Sigurtà
- Protezzjoni tal-għajnejn: Always wear protective eyewear (glasses) when operating the rubber band handgun to prevent eye injury.
- Superviżjoni: Adult supervision is recommended, especially for younger users, during both assembly and operation.
- Target Safely: Never aim the rubber band handgun at people, animals, or fragile objects. Use appropriate targets in a safe environment.
- Partijiet Żgħar: This kit contains small parts that may pose a choking hazard for young children. Keep out of reach of children under 3 years old.
- Użu xieraq: Use only the recommended rubber bands (60 x 1.5 mm caliber) with this model. Do not modify the model or use other projectiles.
Image 2: Detail of the model showing the engraved safety reminder: "USE ONLY WITH GLASSES!".
3. Kontenut tal-Pakkett
The UGEARS Wolf-01 Handgun kit includes:
- Laser-cut wooden sheets with all necessary parts.
- Rubber bands (60 x 1.5 mm caliber).
- Wax for lubricating moving parts.
- Detailed assembly instructions.
Image 3: The product packaging, indicating the contents of the kit.
4. Istruzzjonijiet tal-Assemblea
Follow the step-by-step instructions provided in the kit for a smooth assembly experience. No glue is required; all parts are designed to interlock precisely. Assembly typically takes 60-90 minutes.
- Carefully detach all wooden pieces from the sheets. Use fine sandpaper (not included) if necessary to smooth edges.
- Refer to the illustrated manual for the correct sequence of assembly.
- Apply wax to moving gears and connections as indicated in the instructions to ensure smooth operation.
- Kun żgur li l-konnessjonijiet kollha huma siguri qabel ma tipproċedi għall-pass li jmiss.
Image 4: A person's hands in the process of assembling the wooden puzzle, demonstrating the interlocking pieces.
5. Istruzzjonijiet Operattivi
5.1 Loading Rubber Bands
- Ensure the safety mechanism is engaged (if applicable, refer to your specific model's instructions).
- Place the rubber bands over the designated loading points on the top of the model, stretching them towards the front.
- Secure each rubber band onto the front mechanism. The model can hold multiple rubber bands for sequential firing.
Image 5: A person's hands demonstrating how to load rubber bands onto the top of the handgun model.
5.2 Firing the Handgun
- Point the handgun at a safe target, ensuring no people or animals are in the line of fire.
- Disengage the safety mechanism.
- Gently pull the trigger to release one rubber band. The mechanical action allows for rapid, sequential firing.
Image 6: A person holding the assembled handgun, demonstrating the firing stance.
5.3 Kompartiment tal-Ħażna
The model features an integrated pull-down drawer in the handle, designed for storing extra rubber bands. To access, gently pull down the bottom part of the handle.
Image 7: The handgun with its handle compartment open, showing stored rubber bands.
5.4 Vidjo Uffiċjali tal-Prodott
Video 1: An official product video from UGEARS USA demonstrating the assembly and operation of the Wolf-01 Handgun.
6. Manutenzjoni
- Lubrikazzjoni: Periodically apply wax to moving parts, especially gears and sliding mechanisms, to maintain smooth operation.
- Tindif: Wipe the wooden surfaces with a dry, soft cloth. Avoid using water or chemical cleaners, as they can damage the wood.
- Ħażna: Store the model in a dry environment away from direct sunlight and extreme temperature changes to prevent warping or damage to the wood.
- Rubber Band Replacement: Replace worn or broken rubber bands with new ones of the correct size (60 x 1.5 mm caliber) to ensure optimal performance.
7 Issolvi l-problemi
- Partijiet Mhux Armar: If a wooden piece does not fit easily, do not force it. Check the instructions to ensure it is the correct piece and orientation. Lightly sand the edges if necessary.
- Mekkaniżmi Riġidi: If parts feel stiff or do not move smoothly, ensure adequate wax has been applied to all contact points as per the assembly instructions.
- Rubber Bands Not Firing: Check that the rubber bands are correctly loaded and seated on the firing mechanism. Ensure the trigger mechanism is fully reset.
- Partijiet bil-ħsara: In case of damaged parts during assembly, refer to the manufacturer's support information for possible replacement options.
8. Speċifikazzjonijiet
| Karatteristika | Dettall |
|---|---|
| Dimensjonijiet tal-Prodott | 14.57 x 6.69 x 1.18 pulzieri |
| Piż tal-oġġett | 14.3 uqija |
| Numru tal-Mudell | 70047 |
| Età Rakkomandata | 14 snin 'il fuq |
| Materjal | High-quality Plywood |
| Rubber Band Caliber | 60 x 1.5 mm |
9. Garanzija u Appoġġ
For warranty information, replacement parts, or additional support, please refer to the contact information provided in your product packaging or visit the official UGEARS websit. Żomm il-prova tax-xiri tiegħek għal kwalunkwe talba ta' garanzija.
