Rev-A-Shelf 33-inch Polymer Two-Tier Half Moon Susans (Model 6842-33-15-570) Instruction Manual

Introduzzjoni

This manual provides detailed instructions for the installation, operation, and maintenance of your Rev-A-Shelf 33-inch Polymer Two-Tier Half Moon Susans. This product is designed to optimize storage and accessibility within blind corner cabinets, enhancing kitchen organization.

Please read these instructions thoroughly before beginning installation to ensure proper setup and safe operation. Keep this manual for future reference.

Prodott Overview

The Rev-A-Shelf Two-Tier Half Moon Susans system consists of two almond-colored polymer shelves and a central pivot hardware assembly. It is specifically designed for blind corner cabinets, allowing the shelves to pivot in and out for easy access to stored items.

Karatteristiċi ewlenin:

Two Almond Polymer Half-Moon Shelves: Durable injection-molded plastic construction.
Pivot Hardware: Enables smooth rotation and access within blind corner cabinets.
Blind Corner Cabinet Compatibility: Designed for cabinets with a 16-1/8 inch opening, suitable for both blind left and blind right installations.
Dimensjonijiet: Approximately 18.35 inches deep x 33 inches wide x 15.94 inches high.

Komponenti Inklużi:

(2) Almond Polymer Half-Moon Shelves
Pivot Hardware Assembly (includes central pole, mounting brackets, and fasteners)

Note: Drawer slides are not included and are not required for this pivoting unit.

Image: The Rev-A-Shelf 33-inch Polymer Two-Tier Half Moon Susans, featuring two almond-colored half-moon shelves connected by a central metal pole.

Rev-A-Shelf Half Moon Susan Hardware Components

Immaġni: Dettaljata view of the pivot hardware components, including the central pole, upper and lower mounting brackets, and various fasteners required for installation.

Setup u Installazzjoni

Proper installation is crucial for the functionality and longevity of your Half Moon Susans. Follow these steps carefully.

Għodod Meħtieġa:

Tejp tal-Kejl
Lapes
Drill bi drill bits xierqa
Tornavit (ras Phillips)
Livell
Nuċċalijiet tas-Sigurtà

Passi ta' Installazzjoni:

Refer to the provided instruction sheet for detailed diagrams and measurements. The general steps are outlined below:

Rev-A-Shelf Half Moon Susan Installation Diagram

Image: A black and white diagram illustrating the installation process for the Rev-A-Shelf Half Moon Lazy Susan, showing measurements and component placement within a blind corner cabinet.

Ipprepara l-Kabinett: Ensure your blind corner cabinet has a minimum opening of 16-1/8 inches. Clear the cabinet of any obstructions.
Install Lower Mounting Bracket: Position the lower pivot bracket on the cabinet floor according to the instruction sheet's measurements. Mark and pre-drill holes, then secure the bracket with the provided screws. Ensure it is level and correctly oriented for either a blind left or blind right configuration.
Install Upper Mounting Bracket: Measure and mark the position for the upper pivot bracket on the cabinet ceiling. This bracket will support the top of the central pole. Pre-drill holes and secure it firmly.
Assemble the Pole and Shelves: Insert the central metal pole into the lower pivot bracket. Slide the two half-moon shelves onto the pole, ensuring they are oriented correctly. Adjust the height of each shelf as desired, typically with enough clearance for items on the lower shelf. Secure the shelves to the pole using the provided clips or set screws.
Assigura l-Arblu: Insert the top of the central pole into the upper pivot bracket. Ensure the entire assembly is stable and the pole is vertical.
Operazzjoni tat-Test: Gently pivot the shelves in and out of the cabinet opening to ensure smooth movement and proper clearance. Make any necessary adjustments to shelf height or bracket alignment.

Rev-A-Shelf Half Moon Susan Installed in Cabinet

Image: The Rev-A-Shelf Half Moon Susans fully installed in a kitchen blind corner cabinet, showcasing its functionality with various food items stored on the shelves.

Istruzzjonijiet Operattivi

Using your Rev-A-Shelf Half Moon Susans is straightforward:

Accessing Items: Gently pull the front edge of the half-moon shelves towards you. The entire unit will pivot out of the blind corner, bringing the stored items into full view and easy reach.
Ħażna ta' Oġġetti: Place items on the shelves, distributing weight evenly. Push the shelves back into the cabinet until they are fully retracted into the blind corner.
Kapaċità tal-piż: Avoid overloading the shelves. While durable, excessive weight can strain the pivot mechanism and potentially damage the unit or cabinet.

Manutenzjoni

Regular cleaning and occasional checks will ensure your Half Moon Susans remain in optimal condition.

Tindif: Wipe the polymer shelves with a damp cloth and mild soap. Avoid abrasive cleaners or harsh chemicals, as these can damage the polymer finish. Dry thoroughly.
Iċċekkja tal-Hardware: Periodically inspect the pivot hardware and mounting screws to ensure they are secure. Tighten any loose screws.
Lubrikazzjoni: If the pivoting action becomes stiff, a small amount of silicone-based lubricant can be applied to the pivot points of the hardware. Avoid oil-based lubricants, which can attract dust and grime.

Issolvi l-problemi

Problema	Kawża Possibbli	Soluzzjoni
Shelves do not pivot smoothly.	Misaligned hardware, loose screws, or lack of lubrication.	Check that mounting brackets are aligned and secure. Tighten any loose screws. Apply silicone lubricant to pivot points.
Shelves rub against cabinet opening.	Incorrect bracket placement or cabinet opening too small.	Verify cabinet opening meets the 16-1/8 inch requirement. Re-check bracket measurements and alignment. Adjust if possible.
Shelves are wobbly.	Loose connections between shelves and pole, or pole not securely fastened.	Ensure shelf clips/set screws are tight on the pole. Verify upper and lower pivot brackets are firmly secured to the cabinet.

Speċifikazzjonijiet

Numru tal-Mudell:	6842-33-15-570
Dimensjonijiet tal-Prodott:	18.35"D x 33"W x 15.94"H
Materjal:	Polipropilene
Kulur:	Lewż
Użi Speċifiċi:	Cabinet Organization (Blind Corner)
Piż tal-oġġett:	16 liri
Manifattur:	Rev-A-Shelf
UPC:	090713020068, 090713020044

Garanzija u Appoġġ

Rev-A-Shelf products are manufactured to high standards. For specific warranty information, please refer to the documentation included with your purchase or visit the official Rev-A-Shelf websit.

For technical assistance, replacement parts, or further inquiries, please contact Rev-A-Shelf customer support:

Websit: www.rev-a-shelf.com
Telefon: (800) 626-1126
Indirizz: 12400 Triq Earl Jones, Louisville, KY 40299
