Kanlux Gloria Tl3011 18W Light Fixture Instruction Manual

Introduzzjoni

This instruction manual provides essential information for the safe and efficient installation, operation, and maintenance of your Kanlux Gloria Tl3011 18W light fixture. Please read this manual thoroughly before use and retain it for future reference.

Istruzzjonijiet tas-Sigurtà

Adherence to these safety instructions is crucial for preventing accidents and ensuring proper function of the device. Failure to follow these instructions may result in electric shock, fire, or injury.

Dejjem skonnettja l-enerġija mis-circuit breaker prinċipali qabel l-installazzjoni, il-manutenzjoni, jew it-tindif.
L-installazzjoni għandha titwettaq minn elettriċista kwalifikat skont il-kodiċijiet elettriċi lokali u nazzjonali kollha.
Do not modify the fixture in any way. Unauthorized modifications may void the warranty and create safety hazards.
Kun żgur li l-apparat ikun immuntat sew ma' wiċċ stabbli.
Do not expose the fixture to excessive moisture or direct water spray unless specifically rated for such conditions.
Żomm materjali fjammabbli 'l bogħod mill-apparat tad-dawl.
If the fixture or its cable is damaged, do not use it. Contact a qualified technician for repair or replacement.

Kontenut tal-Pakkett

Ivverifika li l-komponenti kollha huma preżenti u mhux imħassra meta tiftaħ il-pakkett:

Kanlux Gloria Tl3011 18W Light Fixture (1 unit)
Ħardwer tal-immuntar (viti, ankri)
Manwal ta 'Istruzzjoni (dan id-dokument)

Setup u Installazzjoni

Follow these steps for proper installation of your light fixture:

Preparazzjoni: Kun żgur li l-provvista tal-enerġija għaż-żona tal-installazzjoni tkun mitfija mis-circuit breaker.
Post tal-Immuntar: Select a suitable, flat, and stable surface for mounting. Mark the drilling points for the mounting hardware.
Tħaffir: Drill pilot holes at the marked locations. Insert wall anchors if necessary.
Wiring: Connect the fixture's electrical cable to the main power supply wiring. Ensure correct polarity (Live, Neutral, Earth) according to local electrical codes. All connections must be secure. This fixture operates on 240 Volts.
Immuntar tal-Fitture: Secure the fixture to the mounting surface using the provided screws. Ensure it is firmly attached.
Kontroll Finali: Double-check all connections and mounting security.

Kanlux Gloria Tl3011 18W light fixture, front view, showing the integrated light source and power switch. — **Figure 1: Kanlux Gloria Tl3011 18W Light Fixture.** This image displays the Kanlux Gloria Tl3011 18W light fixture. It is a long, slender, white fixture designed for surface mounting. A small toggle switch is visible on the top surface, indicating its on/off control. The light source is integrated along the length of the fixture, covered by a translucent diffuser.

Operazzjoni

Once installed and connected to the power supply, the Kanlux Gloria Tl3011 18W light fixture can be operated as follows:

Qawwa Mixgħul: Irrestawra l-enerġija fis-circuit breaker prinċipali.
Tixgħel/Jitfi: Locate the toggle switch on the top surface of the fixture (refer to Figure 1). Flip the switch to the 'ON' position to illuminate the fixture. Flip it to the 'OFF' position to turn off the light.

Manutenzjoni

Manutenzjoni regolari tiżgura l-lonġevità u l-prestazzjoni ottimali tal-apparat tad-dawl tiegħek.

Tindif: Before cleaning, ensure the power is disconnected. Use a soft, dry, or slightly damp cloth to wipe the exterior of the fixture. Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the finish.
Sors tad-Dawl: The light source in this fixture is integrated and not user-replaceable. If the light source fails, the entire fixture may need to be replaced.
Spezzjoni: Periodically inspect the fixture and its wiring for any signs of damage, wear, or loose connections. Address any issues promptly.

Issolvi l-problemi

If you encounter issues with your Kanlux Gloria Tl3011 18W light fixture, refer to the following common problems and solutions:

Problema	Kawża Possibbli	Soluzzjoni
L-apparat ma jixgħelx.	Ebda provvista ta 'enerġija. Switch is in 'OFF' position. Konnessjoni tal-wajers difettuża.	Iċċekkja circuit breaker. Ensure switch is 'ON'. Ivverifika l-konnessjonijiet tal-wajers (ikkonsulta elettriċista kwalifikat).
Id-dawl jitteptep jew huwa baxx.	Konnessjoni tal-wajers sfużi. Voltagvarjazzjoni.	Check wiring connections (consult a qualified electrician). Ikkonsulta elettriċista biex tiċċekkja l-vultaġġ tad-dartage.
Fixture makes unusual noise.	Kwistjoni ta' komponent intern.	Disconnect power immediately and contact a qualified electrician or the manufacturer.

If the problem persists after attempting these solutions, contact a qualified electrician or the manufacturer for assistance.

Speċifikazzjonijiet

Brand	Kanlux
Numru tal-Mudell	Tl3011 (ka-510)
Dimensjonijiet (L x W x H)	10 x 10 x 60 ċm
Piż	200 g
Voltage	240 Volts
Qawwa	18 Watts
Kulur	Abjad
Karatteristiċi Speċjali	Effiċjenza tal-enerġija
Tip ta' Ipplaggja	Kejbil elettriku

Garanzija u Appoġġ

Specific warranty information for the Kanlux Gloria Tl3011 18W light fixture is not provided in this manual. For details regarding warranty coverage, terms, and conditions, please refer to the documentation included with your purchase or contact Kanlux customer support directly.

For technical support, spare parts, or service inquiries, please contact the manufacturer or your retailer. Always provide the model number (Tl3011 or ka-510) when seeking support.
