Manwal tal-Utent tal-Modulu ta' Espansjoni tal-Istazzjon Analogu tat-Telefon 30 tal-Avaya IPO 500

1. Introduzzjoni

This manual provides essential instructions for the installation, operation, and maintenance of the Avaya IPO IP500 EXP MOD-PHONE 30 Analog Station Expansion Module (Model 700426224). This module is designed to expand the analog station capacity of your Avaya IP Office 500 phone system. Please read this manual thoroughly before proceeding with installation or configuration to ensure proper functionality and safety.

2. Prodott Aktarview

The Avaya IPO IP500 EXP MOD-PHONE 30 is an expansion card designed to integrate seamlessly with the Avaya IP Office 500 phone system. It provides 30 additional analog station ports, allowing for the connection of standard analog telephones, fax machines, or modems to the IP Office system.

Figura 2.1: Angolat view of the Avaya IPO IP500 EXP MOD-PHONE 30 module, showing the top and front panels with port labels.

Figura 2.2: Quddiem view of the Avaya IPO IP500 EXP MOD-PHONE 30 module, clearly displaying the 30 analog station ports.

Figura 2.3: Wara view of the Avaya IPO IP500 EXP MOD-PHONE 30 module, displaying the power input, serial port, and an Ethernet port.

Figure 2.4: The Avaya IPO IP500 EXP MOD-PHONE 30 module shown with its included power adapter and an Ethernet cable.

Figure 2.5: The brown cardboard packaging box for the Avaya IP Office product, featuring the Avaya logo.

3. Setup

The Avaya IPO IP500 EXP MOD-PHONE 30 is an internal expansion module for the Avaya IP Office 500 system. Installation should be performed by qualified personnel.

3.1 Prekawzjonijiet tas-Sigurtà

• Ensure the Avaya IP Office 500 system is powered off and disconnected from all power sources before installation.
• Ilbes ċinga tal-polz anti-statika biex tevita ħsara lill-komponenti minn skarika elettrostatika (ESD).
• Handle the module by its edges; avoid touching circuit board components.

3.2 Passi ta' Installazzjoni

1. Carefully open the chassis of the Avaya IP Office 500 control unit according to its specific service manual.
2. Locate an available expansion slot within the IP Office 500 unit.
3. Align the Avaya IPO IP500 EXP MOD-PHONE 30 module with the expansion slot and gently press it into place until it is securely seated.
4. Secure the module with any retaining clips or screws provided by the IP Office 500 chassis design.
5. Close the IP Office 500 chassis.
6. Connect the provided power adapter to the module's power input port (refer to Figure 2.3) and then to a suitable power outlet.
7. Connect analog telephones, fax machines, or modems to the 30 analog station ports on the front of the module using standard RJ11 cables.
8. Power on the Avaya IP Office 500 system.

3.3 Konfigurazzjoni Inizjali

After physical installation, the module will need to be configured within the Avaya IP Office 500 system software. Refer to the Avaya IP Office 500 System Administrator Guide for detailed instructions on detecting new hardware, assigning extensions, and configuring analog station settings.

4. Istruzzjonijiet Operattivi

The Avaya IPO IP500 EXP MOD-PHONE 30 is an expansion module that provides connectivity for analog devices. Its operation is integrated into the overall Avaya IP Office 500 phone system. Once installed and configured, the connected analog devices will function as extensions of the IP Office system.

4.1 Analog Device Functionality

• Tagħmel Sejħiet: Use the connected analog telephone as usual to dial internal or external numbers.
• Jirċievu Sejħiet: Incoming calls to the assigned extension will ring on the connected analog telephone.
• Fax Machines: Connected fax machines will send and receive faxes according to their configuration within the IP Office system.

For advanced features, call handling, and specific dialing instructions, consult the user guide for your Avaya IP Office 500 system and the documentation for your specific analog telephone model.

5. Manutenzjoni

The Avaya IPO IP500 EXP MOD-PHONE 30 module requires minimal maintenance. Adhering to the following guidelines will help ensure its longevity and reliable performance.

5.1 Tindif

• Ensure the IP Office 500 system is powered off before cleaning.
• Use a soft, dry, lint-free cloth to wipe the exterior surfaces of the module.
• Do not use liquid cleaners, aerosol sprays, or harsh chemicals, as these can damage the components.

5.2 Konsiderazzjonijiet Ambjentali

• Operate the module within the recommended temperature and humidity ranges specified for the Avaya IP Office 500 system.
• Ensure adequate ventilation around the IP Office 500 unit to prevent overheating.
• Keep the module and the IP Office system away from direct sunlight, heat sources, and excessive dust.

6 Issolvi l-problemi

If you encounter issues with the Avaya IPO IP500 EXP MOD-PHONE 30 module, consider the following basic troubleshooting steps.

6.1 No Dial Tone on Analog Phone

• Iċċekkja l-Enerġija: Ensure the Avaya IP Office 500 system is powered on and the module's power adapter is securely connected.
• Iċċekkja l-Konnessjonijiet: Verify that the analog telephone is correctly plugged into one of the module's analog station ports.
• Konfigurazzjoni Sistema: Confirm that the analog station is properly configured and enabled within the Avaya IP Office 500 system software.

6.2 Module Not Detected by IP Office System

• Reseat Module: Power off the IP Office 500 system, open the chassis, and carefully reseat the expansion module to ensure it is fully connected to the expansion slot.
• Kompatibilità tal-Firmware: Ensure the IP Office 500 system's firmware is compatible with the expansion module. Consult Avaya documentation for compatibility matrices.

For more complex issues, refer to the Avaya IP Office 500 System Administrator Guide or contact Avaya technical support.

7. Speċifikazzjonijiet

8. Garanzija u Appoġġ

Specific warranty details for the Avaya IPO IP500 EXP MOD-PHONE 30 (Model 700426224) are not provided within this document. For information regarding product warranty, technical support, and service options, please refer to the official Avaya website or contact your authorized Avaya reseller. It is recommended to register your product with Avaya to ensure access to the latest support resources and updates.
