BELIBUY Portable Car Vacuum Cleaner YACQ-1308 User Manual

1. Istruzzjonijiet Importanti dwar is-Sigurtà

Jekk jogħġbok aqra l-istruzzjonijiet kollha bir-reqqa qabel ma tuża dan l-apparat. Jekk ma ssegwix dawn l-istruzzjonijiet, dan jista' jirriżulta f'xokk elettriku, nar, jew korriment serju.

• Sigurtà Ġenerali: Do not use this vacuum cleaner for any purpose other than its intended use. Keep the appliance away from children.
• Sigurtà Elettrika: Use only the provided Type-C charging cable. Do not attempt to modify the charger or battery. Avoid charging in extremely hot or cold environments.
• Sigurtà tal-batterija: The vacuum contains a rechargeable lithium-ion battery. Do not expose the battery to fire or high temperatures. Do not disassemble, crush, or puncture the battery.
• Restrizzjonijiet tal-Użu: Do not vacuum flammable or combustible materials (e.g., lighter fluid, gasoline). Do not vacuum hot ashes, broken glass, or sharp objects. This vacuum is designed for dry and small wet messes; avoid large liquid spills.
• Manutenzjoni: Ensure the appliance is turned off and unplugged before cleaning or performing any maintenance. Regularly clean the HEPA filter to maintain optimal suction and prevent clogging.

2. Prodott Aktarview

The BELIBUY YACQ-1308 is a versatile 4-in-1 portable cordless vacuum cleaner designed for efficient cleaning in various environments, including cars, homes, and offices. It functions as a vacuum cleaner, air duster, and air inflator.

Komponenti Inklużi:

• Portable Vacuum Cleaner Unit
• Għodda tal-Xquq
• Żennuna tal-Pinzell
• Xkupilja tal-paviment
• Blow Nozzles (various sizes)
• Filtri HEPA (2 inklużi)
• Kejbil tal-Iċċarġjar tat-Tip C
• Manwal għall-Utent

Figure 2.1: The BELIBUY YACQ-1308 Portable Car Vacuum Cleaner shown with all included accessories, including various nozzles, filters, and charging cable.

Karatteristiċi ewlenin:

• Ġbid qawwi: Equipped with an advanced motor providing up to 17000Pa suction for effective cleaning.
• Mingħajr Fili u Portabbli: Lightweight (approximately 400g) and compact design for easy handling and storage.
• Display LCD: Monitors battery level and operational status.
• Multi-funzjonali: Functions as a vacuum cleaner, air duster, and air inflator.
• Batterija rikarikabbli: Built-in 4000mAh battery (2x2000mAh) with a protective plate for safe charging and use, offering 20-30 minutes of continuous operation.
• Filtru HEPA li jista' jinħasel: Ensures effective filtration and can be cleaned for reuse.

3. Setup u Iċċarġjar

3.1 Iċċarġjar inizjali

Before first use, fully charge the vacuum cleaner. The device comes with a Type-C charging port for convenience.

1. Connect the provided Type-C charging cable to the charging port on the vacuum cleaner.
2. Plug the other end of the cable into a compatible USB power source (e.g., car charger, adapter charger, power bank, computer USB port).
3. The LCD display will indicate charging status. When fully charged, the prompt light will turn green.
4. Ċarġ sħiħ tipikament jieħu madwar 2 sigħat.

Figure 3.1: The vacuum cleaner being charged using the USB-C cable, illustrating various compatible power sources such as a car charger, adapter, power bank, and computer.

3.2 Twaħħil taż-Żennuni

The vacuum cleaner supports various nozzles for different functions. Ensure the vacuum is off before attaching or detaching accessories.

• Għall-vakwu: Attach the desired nozzle (e.g., crevice tool, brush nozzle, floor brush) to the front suction port of the vacuum cleaner.
• For Air Duster/Inflator: Attach the appropriate blow nozzle to the rear exhaust port of the vacuum cleaner.

4. Istruzzjonijiet Operattivi

The BELIBUY YACQ-1308 offers multiple cleaning modes. Familiarize yourself with the controls before operation.

4.1 Power On/Off

Press and hold the power button to turn the vacuum cleaner on or off. The LCD display will activate upon power-on.

4.2 Funzjoni tal-Vakwu

Use this function for cleaning dust, debris, and small particles from surfaces.

1. Ensure a suitable nozzle is attached to the front suction port.
2. Agħfas il-buttuna tal-qawwa biex tixgħel il-vakwu.
3. Idderieġi ż-żennuna lejn iż-żona li trid titnaddaf.
4. Move the vacuum slowly over the surface to pick up debris.

4.3 Air Duster Function

This function is ideal for blowing away dust from delicate surfaces or hard-to-reach areas.

1. Attach a blow nozzle to the rear exhaust port.
2. Agħfas il-buttuna tal-qawwa biex tixgħel l-apparat.
3. Direct the airflow towards the dust or debris you wish to remove.

4.4 Air Inflation Function

The device can also be used for air inflation with specific nozzles.

1. Attach the appropriate inflation nozzle to the rear exhaust port.
2. Press the power button to activate the airflow.
3. Use for inflating small items as needed.

Figure 4.1: The 4-in-1 functionality of the vacuum cleaner, showing its use as an air duster for keyboards, an air inflator, a vacuum cleaner for upholstery, and an air pumper for vacuum sealing.

4.5 L-Użu ta' Żennuni Differenti

• Għodda tal-qsim: Ideal for narrow gaps, corners, and hard-to-reach areas like between sofa cushions or car seats.
• Żennuna tal-Pinzell: Effective for cleaning upholstery, pet hair, and dislodging stubborn dirt from surfaces.
• Xkupilja tal-art: Suitable for larger flat surfaces such as car floors, trunks, or small rugs.
• Blow Nozzles: Various sizes for dusting keyboards, electronics, or inflating small items.

Figure 4.2: Illustration of various nozzles and their specific uses, including the HEPA filter and waste bin, suction nozzle for crevices, blow nozzle for dusting, and floor brush for larger areas.

5. Manutenzjoni

Manutenzjoni regolari tiżgura prestazzjoni ottimali u testendi l-ħajja tal-vacuum cleaner tiegħek.

5.1 Tbattil tal-landa taż-żibel

The semi-transparent dust bowl allows you to monitor the dirt level. Empty it when it appears full or after each significant use.

1. Kun żgur li l-vacuum cleaner huwa mitfi.
2. Twist or unlatch the dustbin from the main unit (refer to product diagram for specific mechanism).
3. Empty the collected debris into a trash receptacle.

5.2 Tindif tal-Filtru HEPA

The HEPA filter is washable and reusable. Clean it regularly to maintain strong suction.

1. Neħħi l-kontenitur tat-trab kif deskritt hawn fuq.
2. Carefully remove the HEPA filter from the dustbin.
3. Rinse the HEPA filter under running water until clean. Do not use detergents or hot water.
4. Allow the filter to air dry completely for at least 24 hours before reinserting it into the dustbin. Do not use the vacuum with a wet filter.
5. Reassemble the filter and dustbin, then attach them back to the main unit.

Figure 5.1: The HEPA filter and waste bin assembly, indicating how fine dust is filtered and stored.

6 Issolvi l-problemi

If you encounter issues with your BELIBUY YACQ-1308, refer to the following common problems and solutions:

7. Speċifikazzjonijiet

8. Garanzija u Appoġġ

BELIBUY products are manufactured to high-quality standards. This product comes with a standard manufacturer's warranty against defects in materials and workmanship under normal use.

For warranty claims, technical support, or any questions regarding your BELIBUY YACQ-1308 Portable Car Vacuum Cleaner, please contact our customer service team through the retailer's platform or visit the official BELIBUY store on Amazon:

Visit the BELIBUY Store on Amazon

Please have your model number (YACQ-1308) and purchase information ready when contacting support.
