CAMMHD Z3 1440P Body Mounted Camera User Manual

Introduzzjoni

This manual provides detailed instructions for the operation and maintenance of your CAMMHD Z3 Body Mounted Camera. Please read this manual thoroughly before using the device to ensure proper function and to maximize its lifespan. The CAMMHD Z3 is designed for security and personal recording, featuring high-definition video, audio recording, and night vision capabilities.

Kontenut tal-Pakkett

• CAMMHD Z3 Body Mounted Camera
• USB Data Cable
• Clip ta 'l-ispalla
• Lura Clip
• Manwal għall-Utent (dan id-dokument)
• Built-in 3000mAh Battery (pre-installed)

Setup

1. Iċċarġjar Inizjali

Before first use, fully charge the camera. Connect the camera to a power source using the provided USB data cable. The charging indicator will show the charging status and turn off or change color when fully charged. A full charge provides approximately 8-10 hours of continuous recording (with infrared off at 1080p resolution).

2. Twaħħil tal-Kamera

Select either the shoulder clip or the back clip based on your preference. Attach the chosen clip to the camera and then secure it to your clothing or gear. The camera is lightweight, weighing only 0.2 pounds, ensuring comfortable wear.

3. Ħażna tal-Memorja

The CAMMHD Z3 comes with built-in memory (available in 32GB, 64GB, or 128GB options). No external SD card is required for operation. Ensure sufficient storage is available for your recording needs.

Istruzzjonijiet Operattivi

1. Power On/Off

• To power on: Press and hold the Power button until the screen illuminates.
• Biex titfi: Agħfas u żomm il-buttuna tal-Enerġija sakemm l-apparat jintefa.

2. Reġistrazzjoni tal-Vidjo

• From the main screen, press the Record button to start video recording. The recording indicator will activate.
• Agħfas il-buttuna Irrekordja mill-ġdid biex tieqaf tirrekordja.
• The camera supports 1440P resolution for high-definition video capture and a 130° wide-angle view.

3. Reġistrazzjoni tal-Awdjo

The camera records audio simultaneously with video. There may be an option in the settings to record audio only; refer to the on-screen menu for specific audio-only recording functions.

4. Viżjoni bil-lejl

• The camera features built-in infrared lights for night vision.
• Night vision can be switched manually or set to automatic mode. In automatic mode, the camera senses light levels and adjusts accordingly.
• Effective night vision range is up to 50 feet.

5. Local Playback and File Ġestjoni

Immaġni: File Viewing, Transmission, and Storage options for the CAMMHD Z3 Body Camera. This includes local playback on the device, connecting to a PC, connecting via OTG to a phone, and the internal memory card.

• The 2.0-inch display screen allows for one-key operation to playback and view irreġistrat files direttament fuq l-apparat.
• Innaviga permezz files using the camera's control buttons.

6. Konnessjoni ma' Kompjuter

• Connect the camera to a computer (Windows or macOS) using the provided USB data cable.
• The camera will appear as a removable storage device, allowing you to view, transfer, and manage recorded files.

7. Karatteristiċi Avvanzati

• Sejbien tal-Moviment: Activates recording when motion is detected. This feature can be enabled/disabled in the camera settings.
• Reġistrazzjoni Loop: When memory is full, the camera will automatically overwrite the oldest files. This ensures continuous recording without manual deletion.
• Aġġustament Indipendenti tal-Volum: Adjust audio recording levels through the camera's menu.
• Reġistrazzjoni Estiża: The camera supports extended recording sessions, ideal for long shifts or continuous monitoring.

Manutenzjoni

• Tindif: Uża drapp artab u niexef biex tnaddaf il-korp tal-kamera. Għal-lenti, uża drapp u soluzzjoni speċjalizzati għat-tindif tal-lentijiet. Evita materjali li joborxu jew kimiċi ħarxa.
• Ħażna: Aħżen il-kamera f'post frisk u niexef 'il bogħod mix-xemx diretta u minn temperaturi estremi.
• Kura tal-batterija: Biex ittawwal il-ħajja tal-batterija, evita li tiċċarġja kompletament il-batterija ta’ spiss. Iċċarġja l-kamera regolarment, anke jekk ma tkunx qed tużaha għal perjodi twal.
• Reżistenza għall-Ilma: The camera is waterproof; however, avoid submerging it beyond its rated depth or for prolonged periods. Ensure all ports are securely closed before exposure to water.

Issolvi l-problemi

• Il-kamera ma tixgħelx:
  • Ensure the battery is fully charged. Connect to a power source and try again.
  • Agħfas u żomm il-buttuna Power għal mill-inqas 5 sekondi.
• Recording issues (e.g., not recording, poor quality):
  • Check available memory. If full, loop recording should overwrite old files, but ensure it's enabled.
  • Kun żgur li l-lenti hija nadifa u ħielsa minn ostakli.
  • Verify recording settings (resolution, night vision mode).
• Ma nistax nikkonnettja mal-kompjuter:
  • Kun żgur li l-kejbil USB huwa konness sew kemm mal-kamera kif ukoll mal-kompjuter.
  • Ipprova port jew kejbil USB differenti.
  • Erġa' ibda kemm il-kamera kif ukoll il-kompjuter.
  • Kun żgur li l-kamera tkun mixgħula meta tkun imqabbda.
• Ħajja qasira tal-batterija:
  • Kun żgur li l-kamera hija kompletament iċċarġjata qabel l-użu.
  • Continuous recording at higher resolutions or with infrared night vision enabled will consume more power.
  • Check battery health; if significantly degraded, contact support.

Speċifikazzjonijiet

Image: The CAMMHD Z3 Body Camera demonstrating its versatile applications, including law enforcement, personal security, and recreational recording.

Garanzija u Appoġġ

The CAMMHD Z3 Body Mounted Camera comes with a garanzija ta 'sena from the date of purchase. Additionally, CAMMHD provides appoġġ tekniku tul il-ħajja for this product. If you encounter any issues or have questions regarding your device, please contact CAMMHD customer service for assistance.

For technical support or warranty claims, please refer to the contact information provided on the CAMMHD official webis-sit jew id-dokumentazzjoni tax-xiri tiegħek.
